Page 1: Product Specification
1195 NW Compton Drive Beaverton, OR 97006 PRODUCT SPECIFICATION Title: Engineering Specification: 12.1-inch AMLCD Monitor Document Number: 023-0284-00 12.1”AMLCD MONITOR PLANAR SYSTEMS INC. PART NO. 997-2584-00 Document Number: 023-0284-00 Page 1 of 27 Revision: A... -
Page 2: Table Of Contents
6.0 DISPLAY PERFORMANCE...18 Display Luminance ... 18 Display Contrast... 18 6.2.1 Room Ambient Contrast...18 6.2.2 High Ambient Contrast...18 Display Uniformity ... 18 Title: Engineering Specification: 12.1-inch AMLCD Monitor Document Number: 023-0284-00 TABLE OF CONTENTS Page Page 2 of 27 Revision: A... - Page 3 Color Coding... 22 9.0 RELIABILITY...23 Design Workload ... 23 Critical Failures... 23 Failure Definition... 23 10.0 GLOSSARY OF TER MS AND ABBREVIATIONS ...24 11.0 REVISION HISTORY...27 Title: Engineering Specification: 12.1-inch AMLCD Monitor Document Number: 023-0284-00 Page 3 of 27 Revision: A...
-
Page 4: Introduction
This document defines the electromechanical parameters and operating characteristics for a 12’1” Active Matrix Liquid Crystal Display (AMLCD) based product, hereafter referred to as the Monitor. It is intended for operation in high ambient light, outdoor environment. The Monitor has a scaleable video format capable of displaying a minimum of VGA (640 x 480) through XGA (1024 x 768) input resolution. -
Page 5: Basic Construction
Video Signal Connector The Monitor unit includes a chassis mounted 15-pin female mini D-Shell connector (AMP 748390-5 or equivalent) with socket contacts at the rear of the Monitor. It is shielded for electromagnetic interference (EMI) purposes. Refer to Section 4.1 for electrical connections. -
Page 6: Grounding
External horizontal and vertical image positioning control(s) are provided to accommodate for the undefined delay between sync and video data edge referred to as Front Porch / Back Porch in Figure 9. Title: Engineering Specification: 12.1-inch AMLCD Monitor Document Number: 023-0284-00... -
Page 7: Environmental
Reference to "room ambient" is interpreted as 20°C - 25°C [68°F -? 77°F] and applies throughout this specification unless otherwise noted. Excluding the exterior face temperature range of the Vandal Shield (Note 4), this Monitor will not be subjected to environments outside of the limits of Table 1. -
Page 8: Altitude
Altitude Maximum operating altitude is 3,000 meters [9,850 feet]. Maximum shipping and storage altitude is 12,000 meters [39,400 feet]. Mechanical Vibration and Shock Note: Tests performed with unpackaged Monitors are mounted in a Planar approved rigid retaining fixture. 3.4.1 Vibration... - Page 9 Figure 3. Monitor unit orientation Title: Engineering Specification: 12.1-inch AMLCD Monitor Page 9 of 27 Document Number: 023-0284-00 Revision: A...
-
Page 10: Video Signal Input Requirements
The Video Signal Connector consists of fifteen (15) positions wired numerically and supplied attached to the Monitor as a chassis mounted connector per definitions listed in Table 2. The "NC" positions of this connector are not used for any purpose. -
Page 11: Signal Functions
This is necessary to provide a uniform user color change on the screen in response to a uniformly stepped analog input. The Monitor must be capable of resolving a minimum color range of 262,144 displayable colors (6 bit resolution for Red, Green and Blue). This interpolates to 64 shades of gray (or color) at the Red, Green, and Blue analog video inputs. -
Page 12: Synchronization
Video modes are listed in Table 3. Video Mode IBM VGA IBM VGA IBM VGA w/Border IBM VGA IBM VGA w/Border Title: Engineering Specification: 12.1-inch AMLCD Monitor Document Number: 023-0284-00 MPUL LPUL MOST POSITIVE DOWN LEVEL LEAST POSITIVE DOWN LEVEL 5.5& volt 2.5&... -
Page 13: Signal Quality
The video signal source determines which type of display is connected to it based on the state of the Monitor Sense Lines. The Monitor will indicate to the source that it is a "color display" when Monitor Sense Line 1 (Pin 11) is physically connected to Signal Ground Reference (Pin 10) as defined by the wiring definitions of Table 2. -
Page 14: Video Signal On-Off Sequences
Vertical Active Display 12.711 ms 400 lines Vertical Sync Polarity Note: VGA border is not included in the Active Display time described above. Title: Engineering Specification: 12.1-inch AMLCD Monitor Document Number: 023-0284-00 Video Modes IBM VGA 640x480 25.175 M Hz 31.468 KHz... - Page 15 Note: For video mode 720 x 400 missing video rows and columns are allowed. This is a text mode only. Performance is acceptable if characters as defined section 1.2.1 are legible. Missing row or columns at edge of display is acceptable as long as characters remain legible. Title: Engineering Specification: 12.1-inch AMLCD Monitor Document Number: 023-0284-00 VIDEO MODES...
-
Page 16: Dc Power Input Requirements
DC Input Current: 4.3 amp maximum current draw (12.4-vdc applied) steady state conditions. Refer to Figure 12 for required current profile characteristics at “power–up” conditions. The Monitor is not damaged by input voltages ranging from 0-vdc to 12.4-vdc". Title: Engineering Specification: 12.1-inch AMLCD Monitor Document Number: 023-0284-00... -
Page 17: Power On-Off Sequences
Figure 9. Current Profile: Note 3 amp figure is incorrect; use 4.3 amp as specified above. Power On-Off Sequences The Monitor will automatically return to normal operation upon resumption of power after a power loss. Title: Engineering Specification: 12.1-inch AMLCD Monitor... -
Page 18: Display Performance
The display provides one level of luminance used for both daylight and night viewing. Minimum white-light luminance at the screen center of the Monitor face is 1500 cd/m darkened room environment with ambient light conditions less than 10 LUX [1fC] incident illumination and at room temperature. -
Page 19: Lcd Panel - Physical Image Characteristics
Green White White color is concentrated around 5600 LCD Panel - Physical Image Characteristics The Monitor incorporates a matrix display with the following features: LCD Size: Active Area: Pixel Format: Pixel Pitch: Pixel Arrangement: R,G,B vertical stripe Title: Engineering Specification: 12.1-inch AMLCD Monitor Document Number: 023-0284-00 0.142... -
Page 20: Display Cosmetics
ND filter to an unaided eye at least 45 cm [18”] away from the display surface in a dark room. Dark spots in which the dark spot area divided by the subpixel area is less than 1/3 are not counted. Title: Engineering Specification: 12.1-inch AMLCD Monitor Document Number: 023-0284-00 Max. -
Page 21: Regulatory Agency Requirements
Electromagnetic Emissions Electromagnetic Immunity RFI Emission Certification The Monitor is certified to the following emissions standards when installed in customer product configuration: FCC, Part 15, Paragraph 15.107(b) and 15.109(b), Class A RFI emissions standard. EN 55022 Class A: 1994 ? Limits and measurements of radio interference characteristics of information technology equipment. -
Page 22: Electromagnetic Energy Susceptibility Requirements
Safety standards as noted in sections 2.31 and 2.3.2. Labeling Where applicable, the Monitor complies with IEC 60417 – Graphical Symbols for Use on Equipment Color Coding Where applicable, the Monitor complies with ISO 3864 – Safety colors and Safety Signs Title: Engineering Specification: 12.1-inch AMLCD Monitor... -
Page 23: Reliability
RELIABILITY Design Workload The Monitor is capable of operating 24 hours a day, 365 days a year under the specified environmental conditions per section 3.1. Critical Failures Critical failures is defined as failures that render the Monitor inoperable to the end user. The MTBCF... -
Page 24: Glossary Of Terms And Abbreviations
(Decibel): A measure of the ratio of two signals. The dB value is 20 x log 10 x log of a power ratio. Title: Engineering Specification: 12.1-inch AMLCD Monitor Document Number: 023-0284-00 ]: The international unit of luminance (nits). - Page 25 Sync: A contraction of synchronous or synchronization. Tristimulus Value: See Chromaticity Value and Color Data . VESA: Video Electronics Standards Association VGA: Video Graphics Adapter Title: Engineering Specification: 12.1-inch AMLCD Monitor Document Number: 023-0284-00 Page 25 of 27 Revision: A...
- Page 26 White: The common usage word for high-luminance achromatic colors. XGA: Extended Graphics Adapter Title: Engineering Specification: 12.1-inch AMLCD Monitor Document Number: 023-0284-00 Page 26 of 27 Revision: A...
-
Page 27: Title: Engineering Specification: 12.1-Inch Amlcd Monitor
REVISION HISTORY 11.0 REVISION DATE DESCRIPTI0N OF CHANGE ------------------------------------------------------------------------------------------------------------------------------------------------------- 05-08-03 First release Title: Engineering Specification: 12.1-inch AMLCD Monitor Page 27 of 27 Document Number: 023-0284-00 Revision: A...
