- Page 1 19”~23.8” G-WIN Panel PC Intel® Core™ i3/ i5/ i7 Model No. R19IK7T-GCM1 W22IK7T-GCA3 W24IK7T-GCA2 GC Series Quick Start Guide Document Version 1.0 Document Part No. 91521110105N Please read these instructions carefully before using this product, and save this manual for future use.
-
Page 2: Table Of Contents
19”~23.8” G-WIN GC Series Panel PC Quick Start Guide Contents Preface Chapter 1: Introduction 1.1 Introduction 1.2 Features 1.3 Package Content 1.4 Product Overview 1.5 Physical Buttons and LED Indicators Chapter 2: Getting Started 2.1 Wiring Requirements 2.2 Turning On and Off Your Device 2.3 Connecting to Other Devices... -
Page 3: Preface
Preface Preface FCC Statement This device complies with part 15 FCC rules. Operation is subject to the following two conditions: This device may not cause harmful interference. This device must accept any interference received including interference that may cause undesired operation. This equipment has been tested and found to comply with the limits for a class "B"... - Page 4 Brand and product names are trademarks or registered trademarks of their respective owners. Disclaimer Winmate Inc. reserve the right to make changes, without notice, to any product, including circuits and/or software described or contained in this manual in order to improve design and/or performance. We...
- Page 5 Preface Advisory Conventions Four types of advisories are used throughout the user manual to provide helpful information or to alert you to the potential for hardware damage or personal injury. These are Notes, Important, Cautions, and Warnings. The following is an example of each type of advisory. Note: A note is used to emphasize helpful information Important:...
-
Page 6: Chapter 1: Introduction
19”~23.8” G-WIN GC Series Panel PC Quick Start Guide Chapter 1: Introduction This chapter gives you product overview, describes features and hardware specification. You will find all accessories that come with the panel PC in the packing list. Mechanical dimensions and drawings included in this... -
Page 7: Introduction
G-WIN GC series is designed for heavy duty applications. With rugged construction, ultimate computing power, G-WIN GC Series Panel PC are guaranteed to meet "heavy duty" needs. This series feature high computing power and user-friendly interface with projected capacitive multi-touch (PCAP) technology and support Windows®... -
Page 8: Product Overview
19”~23.8” G-WIN GC Series Panel PC Quick Start Guide 1.4 Product Overview 19”, R19IK7T-GCM1 Unit: mm ① ⑥ № Description № Description ② ⑦ Power On Button 2 x RJ45-10/100/1000 Mbps ③ Reset Button DP 1.2 ④ ⑧ 1 x RS-232/422/485, 2 x RS-232 HDMI 1.4... - Page 9 0BChapter 1: Introduction ① ⑥ № Description № Description ② ⑦ Power On Button 2 x RJ45-10/100/1000 Mbps ③ Reset Button DP 1.2 ④ ⑧ 1 x RS-232/422/485, 2 x RS-232 HDMI 1.4 ⑤ Mic in/ Line out ⑨ 12V DC IN 4 x USB 3.0 ⑩...
-
Page 10: Physical Buttons And Led Indicators
19”~23.8” G-WIN GC Series Panel PC Quick Start Guide 1.5 Physical Buttons and LED Indicators Physical buttons and LED indicators located on the rear side of the panel PC. Physical Buttons Icon Button Description Reset Press to reset the system... -
Page 11: Chapter 2: Getting Started
1BChapter 2: Getting Started Chapter 2: Getting Started This chapter tells you important information on power supply, adapter and precautions tips. Pay attention to power considerations. -
Page 12: Wiring Requirements
19”~23.8” G-WIN GC Series Panel PC Quick Start Guide 2.1 Wiring Requirements The following common safety precautions should be observed before installing any electronic device: Caution Strive to use separate, non-intersecting paths to route power and networking • wires. If power wiring and device wiring paths must cross make sure the wires are perpendicular at the intersection point. -
Page 13: Connecting To Other Devices
1BChapter 2: Getting Started Caution Use only the AC adapter (12V/ 84W) included in your package (Rating: Output 4.2 A). Using other AC adapters may damage the device. Attention Utilisez uniquement l'adaptateur secteur (12V / 50W) inclus dans votre emballage (puissance nominale: sortie 4,2 A). L'utilisation d'autres adaptateurs secteur peut endommager l'appareil. - Page 14 2.3.3 RJ45 Connector G-WIN GC Series Panel PC has two RJ45 connectors that support 10/100/1000 Mbps Ethernet interface for connecting to the internet. Pin assignment and signal name of RJ45 connector Pin №...
- Page 15 DDC_CLOCK DDC_DATA Hot Plug Detect 2.3.6 Display Port Connector G-WIN GC Series Panel PC has one DP 1.2 connector to connect the panel PC to external monitor. Pin assignment and signal name of DP 1.2 connector Pin No. Signal Name Pin No.
-
Page 16: Chapter 3: Mounting
19”~23.8” G-WIN GC Series Panel PC Quick Start Guide Chapter 3: Mounting This chapter provides mounting guide for all available mounting options. Pay attention to cautions and warning to avoid any damages. -
Page 17: Vesa Mount
2. Follow installation instructions supplied with your VESA Mount accessories. *The picture is for demonstration purposes only. VESA Mount accessories are not supplied by Winmate. 3.2 Panel Mount Panel Mount mounting solutions is suitable for many applications where Panel PC should be embedded. -
Page 18: Chapter 4: Operating The Device
19”~23.8” G-WIN GC Series Panel PC Quick Start Guide Chapter 4: Operating the Device In this chapter you will find instructions on how to operate the device. -
Page 19: Operating System
3BChapter 4: Operating the Device 4.1 Operating System The Panel PCs supports Windows 10 IoT Enterprise operating system. 4.2 Multi-Touch The touch screen supports the core gestures for Windows. Gesture Windows Usage Gesture Action Action Tap/ Click / Double-click Click or double-click Double-tap Panning with Scrolling... -
Page 20: How To Enable Watchdog
4.3 How to Enable Watchdog To enable Watchdog, you need to download Winmate Watchdog utility. Find more information on Watchdog in “Watchdog Guide” that you can download from Winmate Download Center or File Share. To enable watchdog in Watchdog AP follow the instructions below: 1. -
Page 21: Using Recovery Wizard To Restore Computer
3BChapter 4: Operating the Device 4.4 Using Recovery Wizard to Restore Computer Note: Before starting the recovery process, make sure to backup all user data. The data will be lost after the recovery process. Important: Before starting the recovery process, remove any expansion card. -
Page 22: Appendix
19”~23.8” G-WIN GC Series Panel PC Quick Start Guide Appendix Appendix A: Product Specifications Model Name R19IK7T-GCM1 W22IK7T-GCA3 W24IK7T-GCA2 Display Size/Type 19" TFT 21.5” TFT 23.8” TFT Resolution 1280 x 1024 1920 x 1080 1920x1080 Brightness 250 nits 250 nits... - Page 23 Notes _____________________________________________________________________________________ _____________________________________________________________________________________ _____________________________________________________________________________________ _____________________________________________________________________________________ _____________________________________________________________________________________ _____________________________________________________________________________________ _____________________________________________________________________________________ _____________________________________________________________________________________ _____________________________________________________________________________________ _____________________________________________________________________________________ _____________________________________________________________________________________ _____________________________________________________________________________________ _____________________________________________________________________________________ _____________________________________________________________________________________ _____________________________________________________________________________________ _____________________________________________________________________________________ _____________________________________________________________________________________ _____________________________________________________________________________________ _____________________________________________________________________________________ _____________________________________________________________________________________ _____________________________________________________________________________________ _____________________________________________________________________________________ _____________________________________________________________________________________ _____________________________________________________________________________________ _____________________________________________________________________________________ _____________________________________________________________________________________ _____________________________________________________________________________________ _____________________________________________________________________________________...
- Page 24 Winmate Inc. 9F, No.111-6, Shing-De Rd., San-Chung District, New Taipei City 24158, Taiwan, R.O.C www.winmate.com Copyright © Winmate Inc. All rights reserved.
