Winmate G-WIN Slim Series User Manual

Intel celeron n6211 (up to 3.0 ghz) with p-cap touch

Hide thumbs

page of 76

/ 76
Bookmarks

Quick Links

Download this manual

G-WIN Slim IP65

Panel PC Series

Intel® Celeron® N6211 (up to 3.0 GHz)

P-CAP Touch

Models: W10IE3S-GSH2

R10IE3S-GST2

R12IE3S-GSM2 (HB)

R15IE3S-GSC3(HB)

User Manual

Document Version 1.0

Document Part No. 91521117100O

Need help?

Do you have a question about the G-WIN Slim Series and is the answer not in the manual?

Questions and answers

Summary of Contents for Winmate G-WIN Slim Series

Page 1 G-WIN Slim IP65 Panel PC Series Intel® Celeron® N6211 (up to 3.0 GHz) P-CAP Touch Models: W10IE3S-GSH2 R10IE3S-GST2 R12IE3S-GSM2 (HB) R15IE3S-GSC3(HB) User Manual Document Version 1.0 Document Part No. 91521117100O...
Page 2 G-WIN IP65 Panel PC IE32 User Manual Contents PREFACE ..............................3 ABOUT THIS USER MANUAL ........................ 9 CHAPTER 1: GENERAL INFORMATION ..................... 10 1.1 Product Features .......................... 10 1.2 Package Contents ........................11 1.3 Product Dimensions ........................12 1.4 Physical Buttons and LED Indicators .................... 16 CHAPTER 2: GETTING STARTED .......................
Page 3 Contents 5.8 How to Enable Watchdog ......................61 5.9 Digital IO Driver ..........................63 5.10 Resistive Touch Driver for Windows 11 System................65 CHAPTER 6: MOUNTING ........................68 6.1 Cable Mounting Considerations ....................68 6.2 Safety Precautions ........................69 6.3 Mounting Guide ..........................69 6.3.1 VESA Mounting ........................
Page 4 G-WIN IP65 Panel PC IE32 User Manual Preface Copyright Notice No part of this document may be reproduced, copied, translated, or transmitted in any form or by any means, electronic or mechanical, for any purpose, without the prior written permission of the original manufacturer.
Page 5 Preface Advisory Conventions Four types of advisories are used throughout the user manual to provide helpful information or to alert you to the potential for hardware damage or personal injury. These are Notes, Important, Cautions, and Warnings. The following is an example of each type of advisory. NOTE: A note is used to emphasize helpful information IMPORTANT:...
Page 6 G-WIN IP65 Panel PC IE32 User Manual Safety Information WARNING! / AVERTISSEMENT! Always completely disconnect the power cord from your chassis whenever you work with the hardware. Do not make connections while the power is on. Sensitive electronic components can be damaged by sudden power surges.
Page 7 Preface Safety Precautions For your safety carefully read all the safety instructions before using the device. Keep this user manual for future reference. • Always disconnect this equipment from any AC outlet before cleaning. Do not use liquid or spray detergents for cleaning. Use a damp cloth. •...
Page 8 G-WIN IP65 Panel PC IE32 User Manual WARNING!/ AVERTISSEMENT! Only use the connection cords that come with the product. When in doubt, please contact the manufacturer. Utiliser seulement les cordons d’alimentation fournis avec le produit. Si vous doutez de leur provenance, contactez le manufacturier.
Page 9 Preface Important Information Countries/ Symbol This equipment complies with essential Area requirements of: Electromagnetic Compatibility Directive(2014/30/EU) Low Voltage Directive (2014/35/EU) European Restrictions of the use of certain hazardous Union substances (RoHS) Directive (2011/65/EU) FCC Part 15 Subpart B Regulations Class B Federal Communications Commission Radio Frequency Interface Statement This device complies with part 15 FCC rules.
Page 10 • EN 60950-1:2006/A11:2009/A1:2010/A12:2011/ A2:2013 ABOUT THIS USER MANUAL This User Manual provides information about using the Winmate® G-WIN Slim IP65 Panel PC (P-CAP) with Intel® Celeron® N6211 (up to 3.0 GHz) processor. This User Manual applies to the G-WIN Slim IP65 Panel PC (P-CAP) – W10IE3S-GSH2, R10IE3S-GST2, R12IE3S-GSM2 (HB), R15IE3S-GSC3(HB).
Page 11 Chapter 1: General Information Chapter 1: General Information Congratulations on purchasing Winmate® G-WIN Slim IP65 with P-CAP Panel PC. The elegantly designed, yet rugged, industrial grade G-WIN S65 series is designed for usability with brilliant true-flat screens, which offer superior readability and Projected Capacitive Multi-Touch (P-CAP) technology, available in 10.1”, 10.4”, 12.1”...
Page 12 G-WIN IP65 Panel PC IE32 User Manual 1.2 Package Contents Carefully remove the box and unpack your Panel PC device. Please check if all the items listed below are inside your package. If any of these items are missing or damaged contact us immediately.
Page 13 Chapter 1: General Information 1.3 Product Dimensions W10IE3S-GSH2 Unit: mm Dimensions: 263.28 x 172 x 40.2 № № Description Description Power Input (M12 Type) RS232 (M12 Type) LAN / USB (M12 Type) OSD Control Panel...
Page 14 G-WIN IP65 Panel PC IE32 User Manual R10IE3S-GST2 Unit: mm Dimensions: 252.41 x 197.8 x 43 № № Description Description Power Input (M12 Type) RS232 (M12 Type) LAN / USB (M12 Type) OSD Control Panel...
Page 15 Chapter 1: General Information R12IE3S-GSM2(HB) Unit: mm Dimensions: 296.2 x 226.7 x 45.5 № № Description Description Power Input (M12 Type) RS232 (M12 Type) LAN / USB (M12 Type) OSD Control Panel...
Page 16 G-WIN IP65 Panel PC IE32 User Manual R15IE3S-GSC3(HB) Unit: mm Dimensions: 363.4 x 277.86 x 45.2 № № Description Description OSD Control Panel RS232 (M12 Type) Power Input (M12 Type) LAN / USB (M12 Type)
Page 17 Chapter 1: General Information 1.4 Physical Buttons and LED Indicators Physical buttons and LED indicators (OSD Control Panel) located on the rear side of the Panel Physical Buttons Icon Button Description Reset Press to reset the system Power On/ Off Press to power on or power off the device LED Indicators LED Type...
Page 18 G-WIN IP65 Panel PC IE32 User Manual Chapter 2: Getting Started This chapter provides information on how to connect the Panel PC device to the source of power, connector pinouts and the guidelines to turn on/off the Panel PC. 2.1 Turning On and Off 2.1.1 Turning on Your Device 1.
Page 19 Chapter 2: Getting Started 2.2 Connecting to Other Devices 2.2.1 Diagram The Panel PC features M12 type connectors with protective cap and has full IP65 rating. This Panel PC comes with various interfaces located on the bottom panel. All of these connectors have been shipped with protective caps.
Page 20 G-WIN IP65 Panel PC IE32 User Manual 2.2.2 Connector Description 2.2.2.1 Power Input Connector Panel PC has M12 type 3 pin male power input connector which accepts 12V DC power input. Use IP65 power cable to connect the Panel PC to the source of power.
Page 21 Chapter 2: Getting Started 2.2.2.2 Serial Interface Connector Panel PC has M12 type 10 pin male RS-232 connector. Use IP65 serial cable to connect the Panel PC to external devices.
Page 22 G-WIN IP65 Panel PC IE32 User Manual 2.2.2.3 Giga LAN + USB 2.0 Connector Panel PC has M12 type 12 pin male Giga LAN and USB connector that supports two LAN and one USB 2.0.
Page 23 Chapter 3: Operating the Device Chapter 3: Operating the Device In this chapter you will find the instructions on how to operate the Panel PC. 3.1 Operating System G-WIN Slim IP65 (P-CAP) Panel PC supports: • Windows 11 IoT Enterprise (64 bit) (Optional) •...
Page 24 G-WIN IP65 Panel PC IE32 User Manual 3.2 Multi-Touch The touchpad supports the core gestures for Windows. Gesture Windows Gesture Action Action Usage Tap/ Click / Double- Click or double-click Double-tap click Panning with Scrolling Drag one or two fingers Inertia up and down Selection/...
Page 25 Chapter 4: Insyde H20 BIOS Setup Chapter 4: Insyde H20 BIOS Setup This chapter describes the different settings available in the INSYDE BIOS that comes with the board. This chapter offers information on the Award BIOS installation utility. 4.1 Main Menu When you enter BIOS setup, the first menu that appears on the screen is the main menu.
Page 26 G-WIN IP65 Panel PC IE32 User Manual 4.2 Advanced Select the Advanced Tab from the setup menu to enter the advanced BIOS setup screen. You can select any of the items on the left frame of the screen to go to the sub menu for the item, such as CPU Configuration.
Page 27 Chapter 4: Insyde H20 BIOS Setup 4.2.1 CPU Configuration BIOS Setting Description Setting Option Effect When enabled, a VMM can utilize the Intel (VMX) Enable or disable Intel additional hardware Virtualization Enable/Disable Virtualization Technology. capabilities provided Technology by Vanderpool Technology. Select number of core Active Processor Number of core to enable in...
Page 28 Chapter 4: Insyde H20 BIOS Setup 4.2.2 F81968 Configuration If you want to adjust the UART port type, follow below step. First, enter the UART Port1 Configuration and in Peripheral Type, you can choose between RS232/RS422/RS485.
Page 29 Chapter 4: Insyde H20 BIOS Setup 4.2.2.1 Restore On Power Loss In Restore On Power Loss, you can setup whether to restore the product automatically when the Power loss.
Page 30 G-WIN IP65 Panel PC IE32 User Manual 4.2.3 Hardware Monitor...
Page 31 Chapter 4: Insyde H20 BIOS Setup 4.2.4 PCH-IO Configuration BIOS Setting Description Setting Option Effect PCI Express PCI Express clock gating enable/disable for Enter Opens sub-menu Configuration each root port. SATA And RST Enable/ Disable SATA device Enter Opens sub-menu Configuratuion USB Configuration Selectively enable/ disable the...
Page 32 G-WIN IP65 Panel PC IE32 User Manual 4.2.5 PCI Express Configuration 4.2.6 SATA and RST Configuration...
Page 33 Chapter 4: Insyde H20 BIOS Setup 4.2.7 USB Configuration...
Page 34 G-WIN IP65 Panel PC IE32 User Manual 4.2.8 Power & Performance BIOS Setting Description Setting Option Effect CPU – Power Configure CPU – Power Enter Opens sub-menu Management Control Management parameters...
Page 35 Chapter 4: Insyde H20 BIOS Setup BIOS Setting Description Setting Option Effect Boot Performance Configure Boot -Max non-turbo Select the performance state Mode Performance Mode performance that the BIOS will set starting parameters -Max battery from reset vector -Turbo Performance Intel SpeedStep (ta) Configure Intel Enabled/ Disabled...
Page 36 G-WIN IP65 Panel PC IE32 User Manual 4.2.9 System Agent (SA) Configuration BIOS Setting Description Setting Option Effect Graphics Configure Graphics Configuration Enter Opens sub-menu Configuration parameters Vt-d Intel® Virtualization Technology for Enabled Vt-d capability Directed I/O Disabled...
Page 37 Chapter 4: Insyde H20 BIOS Setup 4.2.10 Graphics Configuration BIOS Setting Description Setting Effect Option Internal Graphics Internal Graphics Auto Keep IGFX enabled based on the setup settings Enabled options Disabled Aperture Size Select the aperture 128MB Select the aperture size size 256MB Note: Above 4MB MMIO BIOS...
Page 38 G-WIN IP65 Panel PC IE32 User Manual 4.2.11 Boot BIOS Setting Description Setting Option Effect Boot Type Boot Type UEFI Boot Type Select boot type to Dual type, Legacy type configuration or UEFI type Quick Boot Quick Boot Enabled Allows InsydeH20 to skip certain tests configuration Disabled while booting.
Page 39 Chapter 4: Insyde H20 BIOS Setup 4.2.12 Boot Type Order BIOS Setting Description Setting Option Effect Hard Disk Type Hard Disk Type configuration Enter Opens Sub-menu Others Other configuration Enter Opens Sub-menu...
Page 40 G-WIN IP65 Panel PC IE32 User Manual 4.2.13 Security BIOS Setting Description Setting Option Effect TrEE Protocol Version Choose TrEE Protocol TrEE Protovol Version: 1.0 Version or 1.1 TPM Availability TPM Availability Available When hidden don’t configuration Hidden exposes TPM to 0 TPM Operation TPM Operation Select one of the...
Page 41 Chapter 4: Insyde H20 BIOS Setup 4.2.14 Power BIOS Setting Description Setting Option Effect ACPI S3 ACPI S3 configuration Disabled Enable/ Disable ACPI Enabled S1/S3 Sleep state Auto Wake on S5 Auto Wake on S5 Disabled Auto Wake on S5, by configuration By Every Day Day or Month or fixed...
Page 42 G-WIN IP65 Panel PC IE32 User Manual 4.3 Using Recovery Wizard to Restore Computer Note: Before starting the recovery process, make sure to backup all user data. The data will be lost after the recovery process. Important: Before starting the recovery process, remove any expansion card. To enable quick one-key recovery procedure: 1.
Page 43 5.1 Chipset Driver Follow instructions below to install Chipset driver. 1. Open the Driver (Download from Winmate Download Center) and select Chipset driver. When installation window will pop up, select Next. 2. Select Accept to agree with the terms of license agreement.
Page 44 G-WIN IP65 Panel PC IE32 User Manual 3. Check the ReadMe file information, select Install to continue. 4. Wait for the driver to be installed. When installation completed, select Restart Now to restart your computer.
Page 45 Chapter 5: Driver Installation 5.2 Graphic Driver Follow instructions below to install Graphic driver. 1. Open the Driver (Download from Winmate Download Center) and select Graphic driver. 2. Installation window will pop up, select Begin installation.
Page 46 G-WIN IP65 Panel PC IE32 User Manual 3. Select I agree. 4. Select Start to install the Driver. 5. After installation is completed, click Finish.
Page 47 Chapter 5: Driver Installation...
Page 48 G-WIN IP65 Panel PC IE32 User Manual 5.3 Management Engine (ME) Follow instructions below to install Management Engine (ME) . 1. Open the Driver (Download from Winmate Download Center) and select ME driver. 2. Select Next to start the installation.
Page 49 Chapter 5: Driver Installation 3. Select Next to agree with the terms of license agreement. 4. Wait for the driver to be installed.
Page 50 G-WIN IP65 Panel PC IE32 User Manual 5. When installation completed, select Finish complete installation. 5.4 SST Driver Follow instructions below to install SST driver. 1. Update Drivers > Browse “My computer” for driver software > Next...
Page 51 When the line-out volume is turned off, HDMI will also have no audio output. If you will not use the line-in function, please keep the Winmate default setting. When you need to use the line-in function, please follow the steps below to turn on the sync output.
Page 52 G-WIN IP65 Panel PC IE32 User Manual Step 1: Step 2:...
Page 53 Chapter 5: Driver Installation 5.5 Audio Driver Follow instructions below to install Audio driver. 1. Open the Driver (Download from Winmate Download Center) and select Audio driver. 2. Select Next to continue.
Page 54 G-WIN IP65 Panel PC IE32 User Manual 3. When installation completed, select Finish complete installation. 5.6 Ethernet Driver Follow instructions below to install LAN driver. 1. Open the Driver (Download from Winmate Download Center) and select LAN driver.
Page 55 Chapter 5: Driver Installation 2. When compression is complete, select Next.
Page 56 G-WIN IP65 Panel PC IE32 User Manual 3. Read the license agreement, and then select Next. 4. Select the program you want to install and select Next.
Page 57 Chapter 5: Driver Installation 5. Confirm the installation, select Install to start the installation. 6. When installation is completed, select Finish to close the window.
Page 58 G-WIN IP65 Panel PC IE32 User Manual 5.7 Watchdog Driver For more details about Winmate Watchdog, please download Watchdog Guide from Winmate Downloads Center: Follow instructions below to install Watchdog driver. 1. Type “cmd” in the run box then the cmd.exe will appear in programs.
Page 59 Chapter 5: Driver Installation 4. Wait for installation to complete. When installation is complete, press any key to close. 5. Open the Driver and select Watchdog AP.
Page 60 G-WIN IP65 Panel PC IE32 User Manual 6. Select Next. 7. The installed storage location is displayed, select Next to continue.
Page 61 Chapter 5: Driver Installation 8. Select Next to start the installation. 9. When installation is completed, select Finish to close the window.
Page 62 5.8 How to Enable Watchdog To enable Watchdog, you need to download Winmate Watchdog utility. Find more information on Watchdog in “Watchdog Guide” that you can download from Winmate Download Center or File Share. Refer to the User Manual for more details.
Page 63 Chapter 5: Driver Installation 3. In Watchdog utility window set countdown time and periodically feed time, or disable watchdog. Setting Description The system automaticity restarts when this countdown time Watchdog Countdown Time reaches zero. Default: 10 min To set a cycle time to automatically reset watchdog timer. Periodically Feed Time Default: 9 min Enable / Disable...
Page 64 G-WIN IP65 Panel PC IE32 User Manual 5.9 Digital IO Driver For more details about Winmate Watchdog, please download Digital IO Guide from Winmate Downloads Center: Follow instructions below to install Digital IO driver. 1. Type “cmd” in the run box then the cmd.exe will appear in programs.
Page 65 Chapter 5: Driver Installation 6. Open the Driver and select Digital IO AP.
Page 66 G-WIN IP65 Panel PC IE32 User Manual 5.10 Resistive Touch Driver for Windows 11 System Follow the instructions below to install the touch driver. 1. Click setup 2. Click Next to continue...
Page 67 Chapter 5: Driver Installation...
Page 68 G-WIN IP65 Panel PC IE32 User Manual 3. Click Yes to add this controller 4. Restart the computer now and finish the setup.
Page 69 Chapter 6: Mounting Chapter 6: Mounting This chapter provides mounting guide for all available mounting options. Pay attention to cautions and warning to avoid any damages. WARNING! / AVERTISSEMENT! Follow mounting instructions and use recommended mounting hardware to avoid the risk of injury. Suivez les instructions de montage et d'utilisation recommandé...
Page 70 G-WIN IP65 Panel PC IE32 User Manual 6.2 Safety Precautions Observe the following common safety precautions before installing any electronic device: • Use separate, non-intersecting paths to route power and networking wires. If power wiring and device wiring paths must be crossed make sure the wires are perpendicular at the intersection point.
Page 71 10.4”, 15” 100x100 mm Mounting Instruction Use Philips M4x5 screws to fix the desk stand to VESA holes on the back cover of the device. *The picture is for demonstration purposes only. VESA Mounting accessories are not supplied by Winmate.
Page 72 G-WIN IP65 Panel PC IE32 User Manual 6.3.2 Panel Mounting Panel Mount mounting solutions is suitable for many applications where Panel PC should be embedded. With this mounting solution flat surface leave no bezel in the front. Size Wall Cutout, mm Screw Hole Diameter, mm 10.1”...
Page 73 Chapter 6: Mounting Chapter 7: Technical Support Winmate® provides Software Development Kit (SDK). The table below lists SDK provided by Winmate for Winmate® G-WIN Slim IP65 with P-CAP Panel PC with Intel® Celeron® N6211 processor: 7.1 Drivers The list of drivers available for the G-WIN IP65 Panel PC IE32 SBC:...
Page 74 G-WIN IP65 Panel PC IE32 User Manual Appendix A: Product Specifications Hardware Specifications Model Name W10IE3S-GSH2 R10IE3S-GST2 R12IE3S-GSM2(HB) R15IE3S-GSC3(HB) Display 10.1” TFT 10.4” 12.1” TFT 15” TFT Size/Type (Widescreen) Resolution 1280 x 800 1024 x 768 1024 x 768 1024 x 768 350 nits 350 nits 500 nits...
Page 75 Appendix A: Product Specifications Model Name W10IE3S-GSH2 R10IE3S-GST2 R12IE3S-GSM2(HB) R15IE3S-GSC3(HB) Power Specifications Power Input 9-36V DC(M12 type) 12V DC(M12 type) 9-36V DC(M12 type) 9-36V DC(M12 type) Mechanical Specifications Cooling System Fanless Design Mounting VESA Mount, Panel Mount Environment Considerations IP Rating Full IP65 Shock Operation 40g for 11 ms...
