- Page 1 19”/ 21.5”/ 23.8” G-WIN Display GC Series User Manual Document Version 1.0 Document Part No. 91521110105D Please read these instructions carefully before using this product, and save this manual for future use.
-
Page 2: Table Of Contents
19"~23.8" G-WIN GC Series Display Quick Start Guide Contents Preface Chapter 1: Introduction 1.1 Features 1.2 Package Content 1.3 Product Overview 1.4 Physical Buttons and LED Indicators Chapter 2: Getting Started 2.1 Turning On and Off Your Device 2.2 OSD Menu Navigation Chapter 3: Installation 3.1 Wiring Requirements... -
Page 3: Preface
Preface Preface Copyright Notice No part of this document may be reproduced, copied, translated, or transmitted in any form or by any means, electronic or mechanical, for any purpose, without the prior written permission of the original manufacturer. Trademark Acknowledgement Brand and product names are trademarks or registered trademarks of their respective owners. - Page 4 19"~23.8" G-WIN GC Series Display Quick Start Guide Advisory Conventions Four types of advisories are used throughout the user manual to provide helpful information or to alert you to the potential for hardware damage or personal injury. These are Notes, Important, Cautions, and Warnings.
- Page 5 Preface For your safety carefully read all the safety instructions before using the device. Keep this user manual for future reference. Always disconnect this equipment from any AC outlet before cleaning. Do not use liquid or spray detergents for cleaning. Use a damp cloth. ...
- Page 6 Low Voltage Directive (2014/35/EU) EN 60950-1:2006/A11:2009/A1:2010/A12:2011/ A2:2013 About This User Manual This User Manual provides information about using the Winmate® G-WIN GC Series Panel PC. This User Manual applies to the G-WIN GC Series Display. Note: Some pictures in this guide are samples and can differ from actual product.
-
Page 7: Chapter 1: Introduction
Chapter 1: Introduction Congratulations on purchasing Winmate® G-WIN GC Series Display. The elegantly designed, yet rugged, industrial grade G-WIN GC Series is designed heavy duty applications. With rugged construction, ultimate computing power, G-WIN GC Series guaranteed to meet "heavy duty" needs. This series feature high computing power and user-friendly interface with projected capacitive multi-touch (PCAP) technology and support Android, Linux Kernel and Ubuntu operating systems. -
Page 8: Product Overview
19"~23.8" G-WIN GC Series Display Quick Start Guide 1.3 Product Overview 19”, R19L100-GCM1 Unit: mm № № Description Description ① 12V DC in ④ Touch (USB) ② ⑤ HDMI 2 Watt Speaker ③ ⑥ OSD Control Panel 21.5”, W22L100-GCA3 Unit: mm №... -
Page 9: Physical Buttons And Led Indicators
Chapter 1: Introduction 23.8”, W24L100-GGCA2 Unit: mm № № Description Description ① 12V DC in ④ Touch (USB) ② ⑤ HDMI 2 Watt Speaker ③ ⑥ OSD Control Panel 1.4 Physical Buttons and LED Indicators Physical buttons and LED indicators (OSD Control Panel) located on the rear side of the Display. - Page 10 19"~23.8" G-WIN GC Series Display Quick Start Guide Physical Buttons Icon Button Description DOWN/ VOLUME Press to lower down the volume. DOWN UP/ VOLUME UP Press to increase the volume. ESC/ AUTO Press to exit the menu. Press to confirm the action or to come back OK/ MENU to the main menu.
-
Page 11: Chapter 2: Getting Started
Chapter 2: Getting Started Chapter 2: Getting Started 2.1 Turning On and Off Your Device Follow the following steps to turn on your device: 1. Connect the Display to the AC adapter. 2. Connect the AC adapter to the power cord. 3. -
Page 12: Osd Menu Navigation
19"~23.8" G-WIN GC Series Display Quick Start Guide 2.2 OSD Menu Navigation Icon Menu Description BRIGHTNESS BRICONTRAST CONTRAST Only support VGA mode POSITION H position V position Only support VGA mode Auto Adjustment IMAGE Clock Phase White Balance USER 9300K... -
Page 13: Chapter 3: Installation
Chapter 3: Installation Chapter 3: Installation 3.1 Wiring Requirements The following common safety precautions should be observed before installing any electronic device: Strive to use separate, non-intersecting paths to route power and networking wires. If power wiring and device wiring paths must cross make sure the wires are perpendicular at the intersection point. - Page 14 19"~23.8" G-WIN GC Series Display Quick Start Guide 3.2.2 HDMI Connector GC Series Display has HDMI 1.4a connector. Pin № Signal Name HDMI_RX2+ HDMI_RX2- HDMI_RX1+ HDMI_RX1- HDMI_RX0+ HDMI_RX0- HDMI_RXC+ HDMI_RXC- HDMI_CON_CEC HDMI_CON_SCL HDMI_CON_SDA HDMI_CON_CABLE +5V_HDMI HDMI_CON_HP 3.2.3 VGA Connector GC65 Display has standard 15pin D-sub connector.
-
Page 15: Chapter 4: Mounting
Chapter 4: Mounting Chapter 4: Mounting GC Series Display comes with different mounting options suitable for most of the industrial and commercial applications. 4.1 VESA Mount This device supports VESA Mounting and provides various types of mounting options to fit any industrial use or vehicle. -
Page 16: Panel Mount
19"~23.8" G-WIN GC Series Display Quick Start Guide 4.2 Panel Mount Panel Mount mounting solutions is suitable for many applications where Display should be embedded. With this mounting solution flat surface leave no bezel in the front. Size Wall Cutout Screw Hole Diameter 19”... -
Page 17: Chapter 5: Troubleshooting
Chapter 5: Troubleshooting Chapter 5: Troubleshooting If your monitor fails to operate correctly, check the following chart for possible solution before calling for repairs: Problem Solution • Check if the signal cable is firmly seated in the socket. The picture does not •... -
Page 18: Appendix
19"~23.8" G-WIN GC Series Display Quick Start Guide Appendix Appendix A: Display Specifications Model Name R19L100-GCM1 W22L100-GCA3 W24L100-GGCA2 Display 21.5” TFT 23.8” TFT Size/Type 19" TFT Resolution 1280x1024 1920x1080 1920x1080 Brightness 250cd/m2 (typ.) 250cd/m2 (typ.) 250cd/m2 (typ.) Contrast Ratio 1000 : 1 (typ.) 3000 : 1 (typ.) -
Page 19: Appendix B: Cleaning The Monitor
Resolution Frequency (Hz) 1280x1024 1280x1024 1366x768 1280x1024 1600x1200 1366x768 1680x1050 1600x1200 1920x1080 1680x1050 1920x1200 1920x1200 1920x1080 For information about available input signals, please refer to R-Series AD Board Manual included in the package or visit Winmate Download Center at http://www.winmate.com/DownCenter/DownLoadCenterIndex.asp... - Page 20 Winmate Inc. 9F, No.111-6, Shing-De Rd., San-Chung District, New Taipei City 24158, Taiwan, R.O.C www.winmate.com Copyright © Winmate Inc. All rights reserved.
