- Page 1 G-WIN Front IP65 P-Cap Panel PC Intel® Core i5-7200U Kaby Lake 2.5 GHz (Turbo to 3.1GHz) GC Series Model No. R12IK3S-GCM2(HB) R15IH3S-GCC3(HB) Quick Start Guide Document Version 1.0 Please read these instructions carefully before using this product, and save this manual for future use.
-
Page 2: Table Of Contents
GC65 Series Panel PC Quick Start Guide Contents Chapter 1: Introduction 1.1 Features 1.2 Package Content 1.3 Product Overview Chapter 2: Getting Started 2.1 Turning on / off Your Device 2.2 How to Enable Watchdog Chapter 3: Installation 3.1 Wiring Requirements 3.2 Connecting to Other Devices 3.3 Mounting Appendix... - Page 3 Chapter 1: Introduction FCC Statement This device complies with part 15 FCC rules. Operation is subject to the following two conditions: This device may not cause harmful interference. This device must accept any interference received including interference that may cause undesired operation. This equipment has been tested and found to comply with the limits for a class "B"...
- Page 4 Brand and product names are trademarks or registered trademarks of their respective owners. Disclaimer Winmate Inc. reserve the right to make changes, without notice, to any product, including circuits and/or software described or contained in this manual in order to improve design and/or performance. We assume...
- Page 5 Chapter 1: Introduction Advisory Conventions Four types of advisories are used throughout the user manual to provide helpful information or to alert you to the potential for hardware damage or personal injury. These are Notes, Important, Cautions, and Warnings. The following is an example of each type of advisory. Note: A note is used to emphasize helpful information Important:...
-
Page 6: Chapter 1: Introduction
GC65 Series Panel PC Quick Start Guide Chapter 1: Introduction Congratulations on purchasing Winmate® GC65 Panel PC. The elegantly designed, yet rugged, industrial grade G-WIN GC series is designed for heavy duty applications. With rugged construction, ultimate computing power, GC65 series are guaranteed to meet "heavy duty"... -
Page 7: Product Overview
Chapter 1: Introduction 1.3 Product Overview R12IK3S-GCM2(HB) Unit: mm R15IK3S-GCC3(HB) Unit: mm № № Description Description ① ⑤ 12V DC in (optional 9-36V DC) 2 x RJ-45 ② ⑥ RS-232/422/485 OSD Control Panel ③ ⑦ 2 x USB 3.0 2 Watt Speaker ④... -
Page 9: Chapter 2: Getting Started
Chapter 2: Getting Started Chapter 2: Getting Started 2.1 Turning on / off Your Device To turn on your device: 1. Connect the Panel PC to a thermal block (3-pin). 2. Connect the other side of the thermal block to the AC adapter. 3. -
Page 10: How To Enable Watchdog
GC65 Series Panel PC Quick Start Guide 2.2 How to Enable Watchdog To enable Watchdog, you need to download Winmate Watchdog utility. Find more information on Watchdog in “Watchdog Guide” that you can download from Winmate Download Center or File Share. -
Page 11: Chapter 3: Installation
Chapter 3: Installation Chapter 3: Installation 3.1 Wiring Requirements The following common safety precautions should be observed before installing any electronic device: Caution Strive to use separate, non-intersecting paths to route power and networking wires. If power wiring and device wiring paths must cross make sure the wires are perpendicular at the intersection point. - Page 12 GC65 Series Panel PC Quick Start Guide 3.2.1.2 Terminal Block Notice that 9-36V DC input is optional and may not be present tin your device. GC65 Panel PC has DC power source input is a 3 pin terminal block connector that accepts 9-36V DC power input (Optional).
-
Page 13: Mounting
75x75 mm 15” 100x100 mm Mounting Instruction Use Philips M4x5 screws to fix the desk stand to VESA holes on the back cover of the device. *The picture is for demonstration purposes only. VESA Mounting accessories are not supplied by Winmate. - Page 14 GC65 Series Panel PC Quick Start Guide 4.2 Panel Mounting Panel Mount mounting solutions is suitable for many applications where Panel PC should be embedded. With this mounting solution flat surface leave no bezel in the front. Size Wall Cutout, mm Screw Hole Diameter, mm 12.1”...
-
Page 15: Appendix
Appendix Appendix Appendix A: Specifications Model Name R12IB3S-GCM2(HB) R15IB3S-GCC3(HB) Display 12.1” TFT 15” TFT Size/Type Resolution 1024 x 768 1024 x 768 Brightness 500 nits 250 nits Contrast Ratio 700:1(typ.) 700:1 (typ.) Viewing Angle -80~80(H) ; -70~70(V) -88~88(H);-88~88(V) Max Colors 16.2M 16.2M Touch... - Page 16 Winmate Inc. 9F, No.111-6, Shing-De Rd., San-Chung District, New Taipei City 24158, Taiwan, R.O.C www.winmate.com Copyright © Winmate Inc. All rights reserved.
