Regency Bellavista
WARNING:
If the information in these instructions are not followed exactly,
a fi re or explosion may result causing property damage,
personal injury or loss of life.
FOR YOUR SAFETY
Do not store or use gasoline or other fl ammable vapors and
liquids in the vicinity of this or any other appliance.
Installation and service must be performed by a qualifi ed
installer, service agency or the gas supplier.
Tested by:
919-154
FPI FIREPLACE PRODUCTS INTERNATIONAL LTD. 6988 Venture St., Delta, BC Canada, V4G 1H4
B36XTCE
Gas Fireplace
Installer: Please complete the details on the back cover
and leave this manual with the homeowner.
Homeowner: Please keep these instructions for future reference.
™
Installation Manual
Medium DV Gas Fireplace
www.regency-fi re.com
FOR YOUR SAFETY
What to do if you smell gas:
Do not try to light any appliance
Do not touch any electrical switch:
do not use any phone in your
building.
Immediately call your gas supplier
from a neighbour's phone. Follow
the gas supplier's instructions.
If you cannot reach your gas
supplier, call the fi re department.
Owners &
MODEL: B36XTCE
Bellavista
B36XTCE Video
10/30/13
Advertisement
Table of Contents
Related Manuals for Regency Fireplace Products Bellavista B36XTCE
Summary of Contents for Regency Fireplace Products Bellavista B36XTCE
- Page 1 Regency Bellavista ™ Owners & Installation Manual B36XTCE MODEL: B36XTCE Medium DV Gas Fireplace Gas Fireplace Bellavista B36XTCE Video www.regency-fi re.com WARNING: FOR YOUR SAFETY If the information in these instructions are not followed exactly, What to do if you smell gas: a fi...
- Page 2 . The Bellavista™ B36XTCE has been designed to provide you with all the warmth and charm of a wood fi replace at the fl ick of a switch. The Bellavista™ B36XTCE has been approved by Warnock Hersey/Intertek for both safety and effi ciency. As it also bears our own mark, it promises to provide you with economy, comfort and security for many trouble free years to follow.
-
Page 3: Manufactured Mobile Home Requirements
This appliance can only be used with the type of gas indicated on the rating plate. This appliance is not convertible for use with other gases. Ensure that structural members are not cut or weakened during installation. Regency B36XTCE Gas Fireplace... -
Page 4: Table Of Contents
Three (3) 90 Elbows (Rigid Pipe 4" x 6 - 5/8") ....33 venting arrangements ..........34 With Co-linear Flex System .........34 Vertical Terminations ...........35 Co-linear Flex System Into Masonry Fireplaces .35 Unit Installation with Horizontal Termination ....36 Regency B36XTCE Gas Fireplace... -
Page 5: Safety Label
MAY BE INSTALLED IN MANUFACTURED (MOBILE) HOMES AFTER FIRST SALE. 4001172 Minimum Clearances to Combustibles / APPAREIL FONCTIONNANT AU NATURAL GAS Degagement Minimum De Materiaux Combustibles NATURAL GAS: Model B36XTCE-NG CONCU POUR ETRE POELE: Mod le B36XTCE-NG é Ceiling 0" Clearance to Minimum supply pressure 5.0"... -
Page 6: Requirements
(e) A copy of all installation instructions for all Product Approved side wall horizontally vented gas fueled equipment, all venting instructions, all parts lists for venting instructions, and/or all venting design instructions shall remain with the appliance or equipment at the completion of the installation. Regency B36XTCE Gas Fireplace... -
Page 7: Dimensions
DIMENSIONS UNIT DIMENSIONS 40-5/16" (1024mm) 33" (838mm) 40-5/8" (1032mm) 7-7/16" (188mm) 3-1/4" (79mm) 29-7/8" (759mm) 32-7/8" (759mm) Regency B36XTCE Gas Fireplace... -
Page 8: Installation
fi replace. ANCE. TODDLERS, YOUNG CHILDREN AND OTHERS MAY BE SUSCEPTIBLE The B36XTCE Gas Fireplace must be installed 9) Wear gloves and safety glasses for protection TO ACCIDENTAL CONTACT BURNS. A in accordance with these instructions. Carefully while doing required maintenance. -
Page 9: Installation Checklist
Line Installation" and "Conversion Kit from NG to LPG" sections). 3) The B36XTCE Gas Fireplace can be installed 5) Make electrical connections to receptacle in a recessed position or framed out into the room as in A, B, C and D. -
Page 10: Clearances
Front to Back Wall (Maximum) Notes: 0" No Hearth Required Close to Ceiling Minimum Vent Clearances to Combustibles Horizontal Top 2" (51mm) Horizontal Side 1-1/2 " (38mm) Horizontal Bottom 1-1/2" (38mm) Vertical Vent 1-1/2" (38mm) Alcove Regency B36XTCE Gas Fireplace... -
Page 11: Mantel Clearances
Mantel Clearances B36XTCE From Top of Fireplace 29-11/16" 23-1/2" 20" 15-1/2" Opening (754mm) (597mm) (508mm) (394mm) Note: Ensure the paint that is used on the mantel and the facing is "High Quality" or the paint may discolour. Regency B36XTCE Gas Fireplace... -
Page 12: Mantel Leg Clearances
NOTE: The 3-1/2" x 40-5/8" non combustible material supplied with this unit can be replaced if trying to achieve a clean fi nish. A large piece of non combustible material (ie. 4' x 8' x 1/2") can be used to eliminate taped seams on or near unit. Regency B36XTCE Gas Fireplace... -
Page 13: Framing
** Important: Framing height requires consideration of the hearth depth. Dimension N = N + the thickness of the installed hearth. Drywall (or other Non-combustible facing) Header Non-Combustible (steel stud Header on edge) (steel stud) on edge Non-Combustible Facing 11" (279mm) dia. Hole through wall Vent. Opening for gas connection Regency B36XTCE Gas Fireplace... -
Page 14: Framing & Finishing
NOTE: The 3-1/2" x 40-5/8" non combustible material supplied with this unit can be replaced if trying to achieve a clean fi nish. A large piece of non com- bustible material (ie. 4' x 8' x 1/2") can be used to eliminate taped seams on or near unit. Regency B36XTCE Gas Fireplace... - Page 15 To maintain a clean fi nished edge - facing material edges may be fi nished with a J-style trim or metal cornerbead (both materials available at your local building or hardware store). IMPORTANT: Materials used must be NON-COMBUSTIBLE. Regency B36XTCE Gas Fireplace...
-
Page 16: Unit Assembly Prior To Installation
Nailing strip for Clean Finish (set fl ush with unit) Nailing strip for Tile Finish (set Nailing strip for back 1/2") Tile Finish (set back 1/2") Nailing strip for Clean Finish (set fl ush with unit) Regency B36XTCE Gas Fireplace... -
Page 17: Conversion To Top Vent
Diagram 2 Heat Defl ector 3) From inside the fi rebox, remove the baffl e plate by removing 4 screws - remove top front screw fi rst. See Diagram 3. Diagram 4 Baffl e Plate Diagram 3 Regency B36XTCE Gas Fireplace... -
Page 18: Venting Introduction
8) From the inside of the fi rebox, place the exhaust assembly into position as shown in Diagram 8 and secure with 8 - 1/4" x 1/2" screws The B36XTCE uses the "balanced fl ue" technology Co-Axial sys- (Diagram 9). Ensure all screws are tight, but do not over tighten. -
Page 19: Vent Restrictor, Baffl E & Heat Defl Ector Installation
7) From inside the fi rebox, install the top heat defl ector with 2 - 1/4" x 1/2" screws. Ensure all screws are tight, but do not over tighten. Diagram 4 Heat Defl ector Regency B36XTCE Gas Fireplace... -
Page 20: Exterior Vent Termination Requirements
* Clearance in accordance with local installation codes and the requirements of the gas supplier 3 feet (91cm) within a height of 15 feet (4.5m) above the meter / regulator assembly 3 feet (91cm) above - if within 10 feet (3m) horizontally Regency B36XTCE Gas Fireplace... -
Page 21: 4" X 6-5/8" Rigid Pipe
Offset Support 46DVA-ES (N/A - FPI) 4DT-OS SV4SU Wall Thimble-Black 46DVA-WT 4DT-WT 4DWT 4DWT SV4RSM TE-4DE90 Wall Thimble Support/Ceiling Support 46DVA-DC SV4PF TE-4DE90B Firestop Spacer 46DVA-FS 4DT-FS 4DFSP 4DFS SV4BF Trim Plate-Black 4DT-TP 4DFPB 4DCP SV4LA Regency B36XTCE Gas Fireplace... - Page 22 Note: Horizontal runs of vent must be level, or have a 1/4” rise for every 1 foot of run towards the termination. Never allow the vent to run downward - this could cause high temperatures and may present a possible fi re hazard. Regency B36XTCE Gas Fireplace...
-
Page 23: 5" X 8" Rigid Pipe
5DT-WS/B 5DWS Offset Support 58DVA-ES - N/A from FPI 5DT-OS Wall Thimble-Black 58DVA-WT 5DT-WT 5DWT TE-5DE90 Wall Thimble Support/Ceiling Support 58DVA-DC TE-5DE90B - N/A from FPI Firestop Spacer 58DVA-FS 5DT-FS 5DFS Trim Plate-Black 58DAV-WFS 5DT-TP 5DCP Regency B36XTCE Gas Fireplace... - Page 24 1 foot of run towards the termination. 36” (914mm) 29-13/16” (757mm) 39-7/16” (1002mm) Never allow the vent to run downward - this could cause high temperatures and may present a possible fi re hazard. 48” (1219mm) 38-1/4” (972mm) 47-7/8” (1216mm) Regency B36XTCE Gas Fireplace...
- Page 25 Horizontal vent must be supported every 3 feet. • Firestops are required at each fl oor level and whenever passing through a wall. Horizontal (Feet) Max. 36”(0.9m) Factory Setting - No Restrictor Required Factory Setting - No Restrictor Required Regency B36XTCE Gas Fireplace...
-
Page 26: Horizontal Terminations
FLEX VENT 5" X 8" These venting systems, in combination with the B36XTCE Direct Vent Gas Fireplace, has been tested and listed as a direct vent heater system by Warnock Hersey. The location of the termination cap must conform to the requirements in the Vent Terminal Locations Diagram in "Exterior Vent Termination Locations"... - Page 27 5" X 8" AstroCapXL™ Flex vent or approved Rigid Vent System • Max. 3 ft. horizontal run Rear Vent w/ Horizontal Termination • Can only use 5" x 8" venting • Max. 3ft. horizontal run Regency B36XTCE Gas Fireplace...
-
Page 28: Astrocap Xl & Rigid Rear Vent Kit For Corner Installations
Inside corner out along the wall 53" Across the face of the unit, wall to wall 75" Standoff Inside corner to front face of the unit 37-1/2" (Optional) Astrocap Wall Thimble Pipe Length 45 elbow Rigid Pipe Adaptor 26-1/2” (673mm) Regency B36XTCE Gas Fireplace... -
Page 29: Venting Arrangements For Horizontal Terminations
Horizontal vent must be supported every 3 feet. • Firestops are required at each fl oor level and whenever passing through a wall. • A wall thimble is mandatory for all horizontal terminations due to high temperatures. Regency B36XTCE Gas Fireplace... -
Page 30: Horizontal Or Vertical Terminations
American Metal Products, Security Secure Vent , AmeriVent Direct Vent, ICC Excel. AstroCap is the proprietary trademark of FPI Fireplace Products International Ltd. Dura-Vent® and Direct Vent are registered and/or proprietary trademarks of Simpson Dura-Vent Co. Inc. Regency B36XTCE Gas Fireplace... -
Page 31: Horizontal Terminations
5' Max. 11' Min. 8' Max. elbows is required. 7' Min. 6' Max. 12' Min. 9' Max. No Vent Restrictor Installed Lengths do not include elbow indicated. Must use reducer # 946-606 and rigid pipe adaptor #770-994. Regency B36XTCE Gas Fireplace... -
Page 32: Venting Arrangements For Vertical Terminations
Refer to the "Vent Restrictor Position" section for details on how to change the vent restrictor from the factory setting to 2-14" opening ,1-5/8"opening and to 1-1/16" opening. Note: Must use optional fl ue adapter when using Rigid Pipe (Part # 770-994). Regency B36XTCE Gas Fireplace... -
Page 33: Vertical Terminations
90 elbows is 6' Min. 7' Max. 9' Min. required. 7' Min. 8' Max. 10' Min. No Vent Restrictor Installed Lengths do not include elbow indicated. Must use reducer # 946-606 and rigid pipe adaptor #770-994 Regency B36XTCE Gas Fireplace... -
Page 34: Venting Arrangements
fl ex system Pipe Length into masonry fi replaces in this manual. Co-Linear Flex Adapter Reducer #946-606 with Kit# (4 x 6-5/8 venting) 946-563 Rigid Pipe Adapter 90 Degree # 770-994 Elbow Inner Pipe Adapter with Kit# 946-563 Regency B36XTCE Gas Fireplace... -
Page 35: Vertical Terminations
INSTALLATION VERTICAL TERMINATIONS CO-LINEAR FLEX SYSTEM INTO MASONRY FIREPLACES FOR BOTH RESIDENTIAL & MANUFACTURED HOMES The shaded area in the Diagrams show the allowable vertical terminations. Regency B36XTCE Gas Fireplace... -
Page 36: Unit Installation With Horizontal Termination
Diagram 7 4) Level the fi replace and fasten it to the framing using nails or screws through the top and ASTROCAP # 946-523/P side nailing strips. DIMENSIONS 11” (279mm) Diagram 2 Diagram 1 11” (279mm) Regency B36XTCE Gas Fireplace... -
Page 37: Unit Installation With Horizontal Termination
Apply Mill Pac or high temperature silicone to the outer fl ex pipe and slip it over Vinyl Siding the outer fl ue collar of the vent terminal at Wall Thimble least 1-3/8"(35mm) and fasten with the 3 Screws screws. Regency B36XTCE Gas Fireplace... -
Page 38: Unit Installation With Vertical Termination
Important: Always check for gas leaks with a soap and water solution or gas leak detector. 7) Ensure vent is vertical and secure the base Do not use open fl ame for leak testing. Regency B36XTCE Gas Fireplace... -
Page 39: Pilot Adjustment
(Low) 1.6"+/- 0.2" w.c. Note: To properly check gas pressure, both inlet and manifold pressures should B36XTCE - LP System Data be checked using the valve pressure ports on the valve. For 0 to 4500 feet altitude 1) Make sure the valve is in the "OFF" position. -
Page 40: Conversion From Ng To Lp
INSTALLATION CONVERSION KIT #576-972 FROM NG TO LP for B36XTCE using SIT 886 NOVA Gas Valve THIS CONVERSION MUST BE DONE BY A QUALIFIED GAS FITTER IF IN DOUBT DO NOT DO THIS CONVERSION !! Remove the pilot shield by removing 2 Each Kit contains one LP screws. - Page 41 17) Replace yellow “NG” label with red “LPG” label. 18) Reverse steps 3 - 1. 19) Check for gas leaks. 20) Check inlet and outlet pressures. 21) Check operation of fl ame control. Installer Notice: These instructions must be left with the appliance. Regency B36XTCE Gas Fireplace...
-
Page 42: Brick Panel Installation
Note: Ensure that an equal space (gap) is maintained on both left panel (see step 5). the right and left side - when installing the back panel. Final Brick Panel Installation Back Panel Installed 8) Reinstall top heat defl ector (reverse Step 3). Regency B36XTCE Gas Fireplace... -
Page 43: Optional Black Enamel Panel Installation
2) Install the back panel fi rst - use care when clearing the burner assembly and rear log tray, so panel is not scratched. Diagram 5 5) Repeat step 4 for left side panel. 6) Reverse step 1. Diagram 3 Diagram 6 Final Installation Regency B36XTCE Gas Fireplace... -
Page 44: Log Set Installation
1) Carefully remove the logs from the packaging and unwrap them. The logs are fragile, handle with care - do not force into position. Notch Note: See fi nal positioning of Log B on next page. Regency B36XTCE Gas Fireplace... - Page 45 Right Peg - Log E 7) The notch on the bottom of Log D rests against the knot on Log A (as shown below). Back of Log A Notch location on underside of Log A (runs from back - front) Regency B36XTCE Gas Fireplace...
- Page 46 Fit Log C onto left peg on Log E - the notch on the bottom of Log C rests against the 3rd (from the left) grate post. Notch in log C Left Peg - Log E 3rd Grate Post Regency B36XTCE Gas Fireplace...
-
Page 47: Optional Fan Installation
. R e f e r t o w i r i n g d i a g r a m . Electrical Receptacle Push Fan down on mounting pins Diagram 5 Clip Ground Lug Plug fan power cord Regency B36XTCE Gas Fireplace... -
Page 48: Ac Power Adaptor Installation (For Surefi Re Systems)
5) Neatly tuck any loose AC Power Adaptor wires neatly underneath / inside the appliance. Note: (keep wires away from the heat as much as possible). FCM - COM 03/04/2013 919-063 Regency B36XTCE Gas Fireplace... -
Page 49: Gt Remote Installation
(white) 12) Reverse steps 5 and 4. (green) 13) Match the remote control to the receiver - see remote control instructions. 14) Reverse steps 2 and 1. 15) Check to ensure there are no gas leaks. Regency B36XTCE Gas Fireplace... -
Page 50: Optional Wall Thermostat
The remote control is now ready for operation. Thermostat (CP-2 System) Wire Size Max. Length 14 GA. 50 Ft. 16 GA. 32 Ft. 18 GA. 20 Ft. 20 GA. 12 Ft. 22 GA. 9 Ft. Regency B36XTCE Gas Fireplace... -
Page 51: Gtm Remote Installation
4) Remove DFC (digital fi rebox control box) from the fl oor of the unit. 9) Remove the hi/lo knob if installed by removing 2 screws as shown below. 5) Disconnect wire harness, ground wire and spark wire from DFC. Regency B36XTCE Gas Fireplace... - Page 52 19) Reverse steps 2 and 1. 20) Check to ensure there are no gas leaks. 14) To unattach these wires - un-clip from the wires on the stepper motor side as shown below. Press down this tab Regency B36XTCE Gas Fireplace...
-
Page 53: Gtmf Remote Installation
9) Remove the hi/lo knob by removing 2 screws as shown below. 6) Disconnect wire harness, ground wire and spark wire from DFC. 10) Install the stepper motor in the same location the hi/lo knob was removed from - with 2 screws as shown below. Regency B36XTCE Gas Fireplace... - Page 54 18) Plug fan control module into recepticle located on the left hand side of the unit. 19) Match the remote control to the receiver - see remote control instructions. 20) Reverse steps 2 and 1. 21) Check to ensure there are no gas leaks.. Regency B36XTCE Gas Fireplace...
- Page 55 Note 1 ~ Profl ame Flame Modulator for GTM & GTMF Remote Controls are sold seperately. Choice of NG or LP fl ame modulator (to match unit fuel type). See Regency Retail Price pages for complete details Note: Regency Profl ame systems include a white and black wall cover & switch. Regency B36XTCE Gas Fireplace...
-
Page 56: Aeration Adjustment
If the optional remote control is used, the AA batteries normally installed into the battery holder must be removed. The AA batteries in the receiver now operate the unit. Having AA batteries in both the battery holder and receiver will damage the gas valve. Regency B36XTCE Gas Fireplace... - Page 57 GTMF Option SureFire™ Switch GT, GTM, GTMF Option PROFLAME REMOTE SERIES 946-690 GT Remote System 946-691* GTM Remote System 946-692* GTMF Remote * Must also order a 946-693-NG or 946-694 modulator if using the noted remote controls. Regency B36XTCE Gas Fireplace...
-
Page 58: Optional Accent Light Installation
Cover plate 7) From inside the fi rebox - feed the wires from the bottom of the light assembly - through the opening exposed after the removal of the cover plate. Light assembly Cable Tie wiring Regency B36XTCE Gas Fireplace... - Page 59 Amber glass plate covered - for use with units using stainless steel / black enamel panels as show below in Image B. Wire Clip 14) Reinstall the rear log tray - secure with 2 screws. Regency B36XTCE Gas Fireplace...
- Page 60 ELECTRICAL WORK MUST BE Light Switch Switch PERFORMED BY A QUALIFIED ELECTRICIAN Ground To Fan (see above) Do Not Break Tab Break Tab Optional Accent Light on Neutral (silver terminals) Copper terminals Black Green Receptacle in Unit Regency B36XTCE Gas Fireplace...
-
Page 61: Mesh Guard Installation
1) Hook mesh guard frame over top of fl ush glass door frame as shown in Diagram 1. Push bottom part of mesh frame over fl ush glass door frame until tabs snaps into place. 2) Install mesh guard and fl ush glass together - following fl ush glass door installation instructions. Regency B36XTCE Gas Fireplace... -
Page 62: Flush Glass Door Installation
2) Lower the fl ush door, then hook the 2 adjustable tension latches - close the latches to secure the fl ush door (See Diagram 2). Adjustable Tension Latch location Diagram 2 Note: To remove Flush Glass door reverse Steps 1 and 2. Regency B36XTCE Gas Fireplace... -
Page 63: Operating Instructions
fi lm will bake on and become very diffi cult to remove. Use a non-abrasive cleaner and DO NOT ATTEMPT TO CLEAN THE GLASS WHILE IT IS HOT. Regency B36XTCE Gas Fireplace... -
Page 64: Copy Of Lighting Plate Instructions
If service is to be performed - you must disconnect power to the unit, from the battery pack, refer to manual. Appuyez sur le bouton ON / OFF Si le service est effectuée, vous devez débrancher l'appareil, du bloc-piles, voir le manuel d'instruction pour plus de détails. DO NOT REMOVE THIS INSTRUCTION PLATE 918-628b Regency B36XTCE Gas Fireplace... -
Page 65: Maintenance Instructions
2) Remove the Cap, and shine a fl ashlight down the Vent. Remove any bird nests, or other 4) Reverse steps. foreign material. 3) Check for evidences of excessive condensation, such as water droplets forming in the inner Regency B36XTCE Gas Fireplace... -
Page 66: Removing Valve
fl ame appearance and glow on logs. Diagram 2: Slide burner assembly to the left and then remove. 7) Remove the 2 screws securing the rear log Diagram 6 tray and lift out. Diagram 3 Diagram 3 Diagram 7 Regency B36XTCE Gas Fireplace... -
Page 67: Parts List
Oval Duct Adaptor 14) 940-357/P Ceramic Glass 946-007 Angle Bracket 15) 556-012 Door Frame 946-517/P Fan Assembly - Heat Wave Outerbox Assembly 946-004 Junction Box Firebox Assembly 577-929 Mesh Guard 919-154 Manual Not available as a replacement part. Regency B36XTCE Gas Fireplace... - Page 68 PARTS LIST MAIN ASSEMBLY Regency B36XTCE Gas Fireplace...
-
Page 69: Burner Assembly
904-645 Orifi ce # 51 LP 911-005 Valve LP 910-568 Valve NG/LP SIT High/Low 886 911-012 Ignition Board (DBC) 911-013 Wiring Harness -Switch Valve Tray - B36XTCE 911-018 Battery Holder 911-037 Flame Sensor 911-038 Flame Electrode 911-039 Pilot Hood 910-432... - Page 70 NOTES Regency B36XTCE Gas Fireplace...
-
Page 71: Warranty
Any alteration to the unit which causes sooting or carboning that results in damage to the interior / exterior facia is not the responsibility of FPI. * Subsidy according to job scale as predetermined by FPI. Regency B36XTCE Gas Fireplace... - Page 72 Installer: Please complete the following information Dealer Name & Address: ______________________________________________ ___________________________________________________________________ Bellavista B36XTCE Installer: ___________________________________________________________ Phone #: ___________________________________________________________ Date Installed: ______________________________________________________ Serial No.: __________________________________________________________ Regency™, Bellavista™,Surefi re™, and AstroCap™ are trademarks of FPI Fireplace Products International Ltd.
