Parts List - Linear Technology DC1929A Demo Manual

DEMO MANUAL DC1929A

parts List

ITEM QTY REFERENCE
Required Circuit Components
1 9 CIN1-CIN9
2 4 CO1, CO2, CO3, CO4
3 1 CSYS1
4 1 CY1
5 1 C1
6 1 C4
7 2 C5, C8
8 1 C6
9 1 C7
10 1 C10
11 2 C11, C27
12 1 C12
13 2 C13, C21
14 1 C14
15 2 C22, C26
16 1 C23
17 1 C24
18 2 C25, C31
19 1 C28
20 1 C29
21 1 C30
22 1 C32
23 1 C33
24 2 D1, D2
25 4 D4, D5
26 1 D10
27 1 D12
28 1 F1
29 1 L1
30 1 L2
31 1 Q1
32 3 Q2, Q3, Q8
33 2 Q4, Q5
34 1 Q6
35 1 Q7
36 1 Q9
37 1 RCS1
38 1 RCS2
39 1 RCS3
40 2 R1,R6
41 1 R2
6
PART DESCRIPTION
CAP., X7T, 0.22µF, 630V, 10% 1812
CAP., X7R, 33µF, 16V, 20%, 1812
CAP., ALUM, 1000µF, 16V, SEPF SERIES
CAP., CER, 2200pF, 500VAC, 20% RADIAL
CAP., X7R, 10nF, 250V, 10% 1210
CAP., X7R, 4.7µF, 25V, 10%, 1206
CAP., X7R, 47nF, 630V, 10%, 1812
CAP., X7R, 22µF, 25V, 10%, 1210
CAP., CH, 10nF, 630V, 10%, 1210
CAP., X7R, 10µF, 25V, 10%, 1210
CAP., X7R, 22nF, 50V, 10%, 0603
CAP., C0G, 220pF, 25V, 5%, 0603
CAP., C0G, 470pF, 25V, 5%, 0603
CAP., X7R, 1nF, 25V, 10%, 0603
CAP., X5R, 4.7µF, 25V, 10%, 0805
CAP., X7R, 0.47µF, 16V, 10%, 0603
CAP., X7R, 0.22µF, 25V, 10%, 0603
CAP., X5R, 2.2µF, 16V, 10%, 0603
CAP., C0G, 68pF, 50V, 5%, 0603
CAP., X7R, 1µF, 25V, 10%, 0603
CAP., X7R, 0.22µF, 50V, 10%, 0805
CAP., C0G, 10pF, 50V, 5%, 0603
CAP., Alum. Electro. 2.2µF, 450V, G13 size
Schottky Barrier Rec., POWER-DI-123
Diode, High-Speed Diode, SOD-523
Schottky Barrier Rec., SOD-123
Rectifier, 1000V, 1A, SMB
FUSE, 600V, 2.5A, 485 SERIES
IND., 15µH
IND., 4.7µH, XAL40xx SERIES
N-Chan. BSP300, SOT-223
FET, N-CH, POWER 56
FET, N-CH, LFPAK
Power Transistor, 600V, DPAK
Power Transistor, 650V, DPAK
NPN/PNP Transistor, SC-74
RES., CHIP., 0.2, 1/8W, 1% 0805
RES., CHIP., 0.039, 1W, 1%, PRL1632
RES., CHIP., 0.002, 1W, 2%, PML18
RES., CHIP., 20k, 1/4W, 1%, 1206
RES., CHIP., 2, 1/4W, 1%, 1206
MANUFACTURER/PART NUMBER
TDK, C4532X7T2J224K
TDK, C4532X7R1C336M
PANASONIC, 16SEPF1000M
VISHAY, VY1222M47Y5UG63V0
AVX, 1210PC103KAT1A
TDK, C3216X7R1E475K
AVX, 1812CC473KAT1A
MÜRATA, GRM32ER71E226K
TDK, C3225CH2J103J125AA
AVX, 12103C106KAT2A
AVX, 06035C223KAT2A
AVX, 06033A221JAT2A
AVX, 06033A471JAT2A
AVX, 06033C102KAT2A
AVX, 08053D475KAT2A
TDK, C1608X7R1C474K
AVX, 06033C224KAT2A
AVX, 0603YD225KAT2A
AVX, 06035A680JAT2A
AVX, 06033C105KAT2A
AVX, 08055C224KAT2A
AVX, 06035A100JAT2A
Panasonic, EEVEB2W2R2Q
DIODE INC., DFLS1200-7
NXP/Phillips Semi. BAS516
CENTRAL SEMI., CMMR1U-02
CENTRAL SEMI., CMR1U-10
Littelfuse, 048502.5DR
Coilcraft, AGP2923-153KL
Coilcraft, XAL4030-472ME
infineon, BSP300
Fairchild, FDMS86200
RENESAS, RJK0653DPB-00#J5
Infineon, IPD60R1K4C6
Infineon, IPD65R250C6
NXP SEMI., PBSS4140DPN
VISHAY, WSL0805R200FEA
SUSUMU, PRL1632-R039-F-T1
ROHM, PML18EZPGV2L00
VISHAY, CRCW120620K0FKEA
VISHAY, CRCW12062R00FKEA
dc1929afa
