INSTALLATION
MANUAL
MASTERLINE Ultimate Small Cell
Table of contents
• POLE INSTALLATION .............................................................................. 1
• WALL INSTALLATION .............................................................................. 2
POLE INSTALLATION
Step 1
Feed hose clamps through dedicated eyelet on the base of the
connector head.
Step 2
Fix housing to mast.
Be careful not to damage it by over-tightening the clamps (max
5Nm).
HUBER+SUHNER disclaims any liability resulting from incorrect installation and use, including any damages resulting from the use of tools and
accessories other than the ones recommended herein. Any installation performed by unqualified personnel voids the product warranty provided by
HUBER+SUHNER. All due care and attention must be exercised when performing the installation of these products. For advice concerning the
HUBER+SUHNER AG
Fiber Optics
MASTERLINE Ultimate Small Cell
October 18, 2016
Page 1 of 2
general handling of these products please contact HUBER+SUHNER.
