HUBER+SUHNER MASTERLINE Extreme Hybrid Installation Manual

INSTALLATION
MANUAL
MASTERLINE Extreme Hybrid

Table of contents

• SAFETY NOTES ....................................................................................... 1
• HANDLING OF THE CABLING SYSTEM ................................................. 1
• HANDLING OF FIBER OPTIC ASSEMBLIES .......................................... 1
• RRH END OF ASSEMBLY ....................................................................... 2
• BASE STATION END OF ASSEMBLY ..................................................... 8
• FIBRE OPTIC ALLOCATION ..................................................................13
• POWER CODING ...................................................................................14
• REVISION HISTORY ..............................................................................15

SAFETY NOTES

Installation and maintenance work on this device may only be carried out by an authorized
electrician.
National laws and regulations must be observed during installation. The housing and the
components used must be checked for exterior damage prior to installation. If the cabling
system is defective, it may not be used.

HANDLING OF THE CABLING SYSTEM

To avoid any damage due to improper installation, please keep in mind below points:

AVOID any additional stress on the divider housing by twisting or bending when routing or
locating it

AVOID installation path around any sharp objects

AVOID uncontrolled knocking of the divider housing on any hard object

AVOID any contact of the divider housing with any additional substance such as glue/oil/fat
etc. unless prior authorization is given by HUBER+SUHNER AG
See also "User handling manual for cables and cable systems" on
www.hubersuhner.com/en/support

HANDLING OF FIBER OPTIC ASSEMBLIES

In order to guarantee the performance, fiber optic assemblies need to be treaded carefully and
with attention on the minimum bend radius and never exposed to dirt.
See also "User handling manual for cables and cable systems" on
www.hubersuhner.com/en/support
HUBER+SUHNER disclaims any liability resulting from incorrect installation and use, including any damages resulting from the use of tools and
accessories other than the ones recommended herein. Any installation performed by unqualified personnel voids the product warranty provided by
HUBER+SUHNER. All due care and attention must be exercised when performing the installation of these products. For advice concerning the
HUBER+SUHNER AG
Fiber Optics
MASTERLINE Extreme Hybrid
DOC-0000692200 Rev K
3 July 2020
www.hubersuhner.com
general handling of these products please contact HUBER+SUHNER.
