HUBER+SUHNER MASTERLINE Ultimate Hybrid Installation Manual

INSTALLATION
MANUAL
MASTERLINE Ultimate Hybrid
Table of contents
• INSTALLATION OF RRH SIDE OF ASSEMBLY ......................................................................................................................................... 1
• BASE STATION END OF ASSEMBLY ........................................................................................................................................................ 4
• FIBRE OPTIC ALLOCATION ....................................................................................................................................................................... 9
• POWER CODING ...................................................................................................................................................................................... 10
Handling of assembly
To avoid any damage due to improper installation, please keep in mind below points:

AVOID any additional stress on assembly head by twisting or bending when routing or locating it

AVOID installation path around any sharp objects

AVOID uncontrolled knocking of assembly head on any hard object

AVOID any contact of assembly head with any additional substance such as glue/oil/fat etc. un-
less prior authorization is given by HUBER+SUHNER AG

INSTALLATION OF RRH SIDE OF ASSEMBLY

Mount the cable spool onto suitable de-reeling equip-
Step 1
ment. Start unwinding side where the MLUH connector
head is located (picture to the right). Do not pull side
where pulling tube is attached. Make sure, that the
spool can turn freely when unspooling.
HUBER+SUHNER disclaims any liability resulting from incorrect installation and use, including any damages resulting from the use of tools and
accessories other than the ones recommended herein. Any installation performed by unqualified personnel voids the product warranty provided by
HUBER+SUHNER. All due care and attention must be exercised when performing the installation of these products. For advice concerning the
HUBER+SUHNER AG
Fiber Optics
MASTERLINE Ultimate Hybrid
DOC-0000692201 Rev C
November 25, 2016
Page 1 of 10
general handling of these products please contact HUBER+SUHNER.
