Quick-Fit plus preparing tool 74_Z-0-12-18 for

½" annular cables

Safety Instructions

1x screwdriver

Make sure that the preparing tool is in the

START/END position. If not, then keep the grip fix

and rotate the base tool clockwise or counter-

clockwise until the START/END position is

reached.

Release the lock-mechanism (latch) at the

preparing tool carefully by using a screw-driver

and remove the base tool part at once.
