INSTALLATION
MANUAL
MASTERLINE Ultimate Power

Table of contents

• SAFETY NOTES .......................................................................................................................................................................................... 1
• HANDLING OF THE CABLING SYSTEM .................................................................................................................................................... 1
• HANDLING OF FIBER OPTIC ASSEMBLIES ............................................................................................................................................. 1
• RRH END OF ASSEMBLY .......................................................................................................................................................................... 2
• BASE STATION END OF ASSEMBLY ........................................................................................................................................................ 8
• POWER CODING ...................................................................................................................................................................................... 10
• REVISION HISTORY ................................................................................................................................................................................. 11

SAFETY NOTES

HANDLING OF THE CABLING SYSTEM

HANDLING OF FIBER OPTIC ASSEMBLIES

HUBER+SUHNER disclaims any liability resulting from incorrect installation and use, including any damages resulting from the use of tools and
accessories other than the ones recommended herein. Any installation performed by unqualified personnel voids the product warranty provided by
HUBER+SUHNER. All due care and attention must be exercised when performing the installation of these products. For advice concerning the
Installation and maintenance work on this device must be carried out only by an authorised
electrician.
National laws and regulations must be observed during installation. The housing and the
components used must be checked for exterior damage prior to installation. If the cabling
system is defective, it must not be used.
To avoid any damage due to improper installation, please note the following points:
AVOID any additional stress on the connector head causing by twisting or bending dur-
ing routing or location
AVOID installation paths around any sharp objects
AVOID uncontrolled impacts of the connector head against any hard object
AVOID any contact between the connector head and any additional substance such as
glue, oil or fat, unless prior authorisation is given by HUBER+SUHNER AG
See also the "User handling manual for cables and cable systems" available at
www.hubersuhner.com/en/support
To guarantee proper performance, fiber optic assemblies must be handled carefully with due
attention to the minimum bend radius and never exposed to dirt.
See also the "User handling manual for cables and cable systems" available at
www.hubersuhner.com/en/support
HUBER+SUHNER AG
Fiber Optics
MASTERLINE Ultimate Power
DOC-0000807936 Rev B
June 23, 2020
Page 1 of 11
general handling of these products please contact HUBER+SUHNER.
