Handbook
©
KROHNE 06/05
7.02233.24.00
Subject to change without notice
Installation and operating
handbook
Optimass Series of Mass Flowmeters and
050/051 Converters
Electromagnetic flowmeters
Variable area flowmeters
Mass flowmeters
Ultrasonic flowmeters
Vortex flowmeters
Flow controllers
Level measuring instruments
Pressure and temperature
Heat metering
Communications technology
Switches, counters, displays and recorders
Engineering systems & solutions

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the OPTIMASS Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for KROHNE OPTIMASS Series

Summary of Contents for KROHNE OPTIMASS Series

  • Page 1 Handbook © KROHNE 06/05 7.02233.24.00 Installation and operating handbook Optimass Series of Mass Flowmeters and 050/051 Converters Electromagnetic flowmeters Variable area flowmeters Mass flowmeters Ultrasonic flowmeters Vortex flowmeters Flow controllers Level measuring instruments Pressure and temperature Heat metering Communications technology Switches, counters, displays and recorders Engineering systems &...

  • Page 3: Table Of Contents

    Contents MECHANICAL INSTALLATION General principles 1.1.1 Transport and Lifting OPTIMASS 7000 Single Straight Tube Meter 1.2.1 Specific Installation Guidelines 1.2.2 Ambient / Process temperatures 1.2.3 Pressure Equipment Directive (PED) requirements 1.2.4 Secondary Pressure containment 1.2.5 Pressure de-rating 1.2.6 Hygienic Applications 1.2.7 Heating and insulation 1.2.8...
  • Page 4 PROGRAMMING THE CONVERTER MFC 050/051 Operating and check elements OPTIMASS MFC 050/051 Operating Concept Key functions 4.3.1 How to enter programming mode 4.3.2 How to terminate Programming mode Table of programmable functions Reset / Quit Menu - Totalizer reset and status indication acknowledgement DESCRIPTION OF FUNCTIONS Menu 1 - Initial Start up Menu 2 –...
  • Page 5 In addition, the “general conditions of sale” which forms the basis of the purchase agreement are applicable. If you need to return OPTIMASS flow meters to KROHNE, please complete the form on the last page of the installation and Operating manual and return it with the meter to be repaired. KROHNE regrets that it cannot repair or check your flow meter unless accompanied by this completed form.
  • Page 6 6. Screw driver for terminal connections 7. Calibration certificate 8. Factory and Material certification, if ordered. If any of these items are missing, please contact your nearest KROHNE Office or representative (see back page). Attention: Please read the Handbook before installing the meter.

  • Page 7: Mechanical Installation

    Mechanical Installation 1.1 General principles The OPTIMASS mass flow meters provide high accuracy and excellent repeatability. Narrow band pass digital filtering, and the mathematically modelled internal primary head design with AST (Adaptive Sensor Technology) for the OPTIMASS sensor family provide exceptional immunity to external vibratory disturbances from nearby process equipment.
  • Page 8 Examples Vertical mounting Horizontal mounting Upward sloping installation Avoid mounting the meter with long vertical drops after the meter. This could cause siphoning and cause measurement errors. Avoid mounting the meter at the highest point in the pipeline. Air or gas can accumulate here and cause faulty measurements Flow Flow...

  • Page 9: Transport And Lifting

    1.1.1 Transport and Lifting As the larger meters are heavy, care should be taken when lifting to install. • Meters should be lifted or suspended using a well maintained sling. • The meters should under no circumstances be lifted by the electronics housings. •...

  • Page 10: Optimass 7000 Single Straight Tube Meter

    1.2 OPTIMASS 7000 Single Straight Tube Meter 1.2.1 Specific Installation Guidelines • Tighten flange bolts evenly. • Observe min and max pipe end loads at end of this section. The use of reducers at the flanges is allowed. Extreme pipe size reductions should be avoided due to possibility of cavitation and degassing.

  • Page 11: Secondary Pressure Containment

    1.2.4 Secondary Pressure containment The OPTIMASS 7000 meters are supplied with secondary pressure containment as standard. Allowable maximum secondary containment pressures are 63 bar at 20°C or 914 psig at 70°F If the user suspects that the primary tube has failed, the unit must be depressurised and removed from service as soon as possible.
  • Page 12 Pressure/Temperature de-rating for SS and Hast. C22 Metric DIN 2501 PN 40 Secondary Pressure Containment 316 L DN100 PN40 Flange Secondary Pressure Containment 304 L and flanges DIN 2501 PN 40 Temperature Deg. C Pressure/Temperature de-rating for Titanium Gr.9 ANSI 150/300/600 lbs 1000 Secondary Pressure containment 316 L...
  • Page 13 *On Optimass 15 H or S with ½” ANSI flanges only – maximum end load is 19 KN Loads given in both tables are maximum static loads. If loads are cycling, particularly between tension and compression then these loads should be reduced. Please consult KROHNE for more information. Installation and Operating Instructions OPTIMASS...

  • Page 14: Hygienic Applications

    Installation lengths For installation lengths, please see section 1.2.10 Please check with KROHNE if you are unsure of the installation length. Many meters are built to customer requirements / specifications especially where special hygienic process connectors have been adapted to the meter. As these are normally non-standard, the installation length will not be given in the technical data.

  • Page 15: Heating And Insulation

    1.2.7 Heating and insulation There are several methods to heat the meter. In most cases heating is unnecessary as the meter is designed as such that very little heat is lost or gained through the outer cylinder. Insulation Where insulation is required a variety of materials may be used to insulate the meter. Care must be taken not to insulate the meter above the halfway mark of the electronics support post as shown in the sketch.
  • Page 16 The maximum heating temperature for a Titanium meter is 150°C or 300°F. The maximum heating temperature for Hastelloy or SS meters is 100°C or 210°F. If these temperatures are exceeded, the meter will be damaged. KROHNE accepts no responsibility if this happens. Installation and Operating Instructions OPTIMASS...
  • Page 17 OPTIMASS T10 to T25 - Heating Times 160.0 140.0 120.0 100.0 80.0 60.0 40.0 20.0 0.00 1.00 2.00 3.00 4.00 5.00 6.00 7.00 8.00 9.00 Time (hours) OPTIMASS T 40 to T 80 - Heating Times 160.0 140.0 120.0 100.0 80.0 60.0 40.0...
  • Page 18 40.0 30.0 20.0 10.0 0.00 2.00 4.00 6.00 8.00 10.00 12.00 14.00 16.00 18.00 20.00 22.00 24.00 26.00 Time (hours) Cooling Please consult KROHNE if cooling medium is to be used in the heating jacket. Installation and Operating Instructions OPTIMASS...

  • Page 19: Purge Port Meters And Burst Disk Meters

    Important: The burst disk is suitable for the designed application according to the process conditions and flow rates as per original order. If conditions alter, consult KROHNE for further advice regarding suitability of disk fitted. If the product is in any way hazardous, it is strongly recommended that an exhaust tube is connected to the NPT male thread of the burst disk so that the discharge can be piped to a safe area.

  • Page 20: Technical Data

    1.2.9 Technical Data Nominal Flow Rates 2,700 11,250 34,500 91,500 180,000 430,000 Kg/h Lbs/min 35 1,250 3,350 6,600 15,800 Maximum flow rate Typically 130 % of the nominal flow rate for the sensor size depending on application. Minimum flow rate Depending on measuring error required.

  • Page 21: Weights & Dimensions

    1.2.10 Weights & Dimensions Weights Weight of OPTIMASS 7000 sensor fitted with a typical standard flange in kg (lbs) Size Flanged versions Dimensions Meter ø A C std C Ex D for std D1 for ANSI 600# flg. & Size Flanges tongue/groove 420±2...
  • Page 22 Meter connection size Connection type Connection standard D in mm D in inches DN10 all welded din 32676 19.1 1/2" all welded tri-clover 18.9 DN10 all welded DIN 11864 20.8 DN10 all welded DIN 32676 22.2 1/2" all welded Tri-clover 22.0 DN10 adaptor...
  • Page 23 Heating Jacket Dimensions Meter Connection ø A Titanium Hastelloy Size Size 1/2"(12 mm) 115±1 36±1 1/2"(12 mm) 115±1 51±1 51±1 1/2"(12 mm) 142±1 100±1 55±1 1/2"(12 mm) 206±1 130±1 130±1 1/2"(12 mm) 254±1 180±1 105±1 1"(25 mm) 254±1 175±2 26±1 100±2 26±1 1"(25 mm)

  • Page 24: Optimass 3000 (7100) Single Z Shaped Tube Meter

    1.3 OPTIMASS 3000 (7100) Single Z Shaped Tube Meter 1.3.1 Specific Installation Guidelines When installing, please observe the following: • Four holes are provided in the base plate and all four should always be used. • The plastic inserts in the base plate mounting holes are important to ensure a rigid and stable connection to the mounting structure.

  • Page 25: Ambient / Process Temperatures

    Flanged and Tri-clamp Meters When installing these meters ensure that the pipework is supported behind the process flange, so that no unnecessary stress is applied to the meter flanges. 1.First fix meter to firm support 2.Carefully align process flanges and connect 3.Support process pipe close to flanges –...

  • Page 26: Secondary Pressure Containment

    1.3.4 Secondary Pressure containment The OPTIMASS 3000 (7100) meters are supplied with secondary pressure containment as standard. Allowable maximum secondary containment pressures are 30 bar at 20°C or 435 psig at 70°F, and is de- rated as follows : 20 °C 50°C 100°C 150°C...

  • Page 27: Heating And Insulation

    Important: The burst disk is suitable for the designed application according to the process conditions and flow rates as per original order. If conditions alter, consult KROHNE for further advice regarding suitability of disk fitted. If the product is in any way hazardous, it is strongly recommended that an exhaust tube is connected to the NPT male thread of the burst disk so that the discharge can be piped to a safe area.

  • Page 28: Technical Data

    1.3.8 Technical Data Nominal Flow Rates Kg/h Lbs/min 0.5 12.5 Maximum flow rate Typically 130 % of the nominal flow rate for the sensor size depending on application. Minimum flow rate Depending on measuring error required. Tube materials: • S 316L •...

  • Page 29: Weights & Dimensions

    1.3.9 Weights & Dimensions Weights Weight of OPTIMASS 3000 (7100) sensor fitted with a typical standard connection in kg (lbs) Size 26.4 26.4 26.4 Standard Connections Flanged and Hygienic Connections Installation and Operating Instructions OPTIMASS...
  • Page 30 Dimensions 7100 Flange Size ø A B std B Ex None ANSI 150 286±2 ANSI 300 286±2 ANSI 600 295±2 DIN15 PN40 286±2 DIN15 PN63 295±2 DIN10 DIN 32676 1/2" TRI CLOVER N/A 261.6 inches None 10.1 ANSI 150 11.3 ANSI 300 11.3 ANSI 600...

  • Page 31: Optimass 8000 / 9000 Meter With Twin U Measuring Tubes

    1.4 OPTIMASS 8000 / 9000 Meter with Twin U Measuring Tubes 1.4.1 Specific Installation Guidelines • Tighten flange bolts evenly. • Do not stress the sensor mechanically. Clamp and support the connecting pipework accordingly. • It is permissible to support the weight of the meter on the square body. •...

  • Page 32: Secondary Pressure Containment

    1.4.4 Secondary Pressure containment The OPTIMASS 8000/9000 series sensors do not have certified secondary containment. If the user suspects that the primary tube has failed, the unit must be depressurised and removed from service as soon as possible. 1.4.5 Pressure de-rating Meter data plates are stamped with maximum pressure rating (at max.
  • Page 33 ANSI flanges to ASME B16.5. Note also pressure / temperature limits for measuring tubes above. 3500 3000 2500 Flange ASME B16.5 Class 150 2000 Flange ASME B16.5 Class 300 Flange ASME B16.5 Class 600 Flange ASME B16.5 Class 900 1500 Flange ASME B16.5 Class 1500 1000 -300...

  • Page 34: Hygienic Applications

    Installation lengths For installation lengths, please see section 1.4.10 Please check with KROHNE if you are unsure of the installation length. Many meters are built to customer requirements / specifications especially where special hygienic process connectors have been adapted to the meter. As these are normally non-standard, the installation length will not be given in the technical data.

  • Page 35: Heating And Insulation

    1.4.7 Heating and insulation Insulation OPTIMASS 8000 Where insulation is required a variety of materials may be used to insulate the meter. Care must be taken not to insulate the meter above the halfway mark of the electronics support post as shown in the sketch. Do not insulate above this line.

  • Page 36: Purge Port Meters And Burst Disk Meters

    The burst disk is suitable for the designed application according to the process conditions and flow rates as per original order. If conditions alter, consult KROHNE for further advice regarding suitability of disk fitted. If the product is in any way hazardous, it is strongly recommended that an exhaust tube is connected to the 3/4"...
  • Page 37 Flanged & Hygienic Connections Dimension A SIZE 15 SIZE 25 SIZE 40 SIZE 80 SIZE 100 EN 1092-1 MATERIAL DN15 DN25 DN25 DN40 DN40 DN50 DN80 DN80 DN100 DN100 DN150 PN40 1000 1000 1100 1100 HAST 1000 1000 PN 63 HAST PN100 HAST...
  • Page 38 Triclamp DIN32676 & ISO2852 Material SIZE 15 SIZE 25 SIZE 40 SIZE 80 DN25 DN40 DN50 DN65 DN100 1020 Triclover Triclamp Material SIZE 15 SIZE 25 SIZE 40 SIZE 80 1" 1 1/2" 2" 3" 4" 1020 DIN 11851 Male Material SIZE 15 SIZE 25...
  • Page 39 Insulated / Heated Jacket Meters Major external dimensions of insulating and heating jacket options. SIZE 1000 1040 Installation and Operating Instructions OPTIMASS...

  • Page 40: Electrical Installation

    Electrical Installation 2.1 Location and connecting cables Location Do not expose the compact flow meter to direct sunlight in hot climates. Install a sunshade if necessary. Connecting cables To conform to protection category requirements, observe the following recommendations: • Fit blanking plug and apply sealant to unused cable entries. •...

  • Page 41: Power Supply Wiring Mfc 051 Ex

    2.2.3 Power Supply Wiring MFC 051 Ex Slide the cover to the left to expose the power terminals. Power supply terminals covered. Terminal designation as per section 2.2.2. 2.3 Connection of remote meters The OPTIMASS meter can be supplied as a remote meter with up to 300 m or 1000 ft distance between sensor and converter.

  • Page 42: Hazardous Area Requirements

    Shield is connected through the cable gland. Hazardous Area requirements • Hazardous Area Installation. • For further information please see supplementary installation and operating instructions. • Please follow these guidelines explicitly for mechanical and electrical connections. • General cabling guidelines. To maintain the IP 67 / NEMA 4x protection it is necessary to ensure that the correct size cable is used for the cable glands.
  • Page 43 Output Option 1 Active status O/P 24V DC Pulse O/P (Passive) Input < 24V DC 4-20 mA Common Active Status Output The status output can be programmed to provide a constant 24V (20mA maximum) which can be used as the power source for the pulse output and control input. Set Menu 4.6.1 to OFF Set Menu 4.6.2 to ACTIVE LOW Example Circuits...
  • Page 44 Contact Input <24V DC 0V DC Fig 5 : Binary input Fig 6 : Binary input status powered < 24V DC Contact > I500Ω Contact Pull down IKΩ 0V DC Fig 7 : Binary input status powered Fig 8 : Binary input external powered <...
  • Page 45 Output Option 2 Modbus Current Output Refer to communications handbook for details of Modbus connections Output Option 3 Pulse 2 Pulse 1 B LAGS A BY 90° Common 0 V Common 0 V Phase shifted pulse (Passive) for Custody Transfer Alternative to drive 2 pulse outputs.
  • Page 46 Output Option 5 Status Output (Passive) Control Input (Passive) Current Output 2 Current Output 1 Common 0 V <24 V DC V < 24 V DC Output > IK5R ETC. Status Relay Common 0V Common 0V Passive Status Output Passive Status Relay ; 24VDC < 20mA relay Output Option 6 Output Option 7 Pulse Output (Passive)

  • Page 47: Inputs / Outputs Mfc051

    2.5.2 Inputs / Outputs MFC051 The MFC 051 offers galvanically separated outputs in the non-hazardous area version and intrinsically safe outputs for the Hazardous area approved version (see Supplementary Installation and Operating Instructions). All outputs are passive. The converter is shipped from the factory with the required output option fitted and configured. These cannot be changed in the field as the modules are soldered in place.
  • Page 48 Output Option 3 In addition to the 1 4...20mA, a control or binary input can be wired as shown. 5 … 30 V DC Contact 0 V DC Output Option 4 In addition to the 1 4...20 mA, a status or alarm output can be wired as shown. 5 …...

  • Page 49: Compact To Remote / Remote To Compact Conversion Instructions

    A change from compact to remote or vice versa in the field is possible in safe areas, for hazardous areas only in the workshop. Contact your local KROHNE Company and provide the serial number of the meter for further details. 2.7 Technical Data 2.7.1 MFC050...

  • Page 50: Mfc051

    2.7.2 MFC051 Power Supply Operating Voltage : 100 – 230V AC (+10% / -15%) 24V DC (+/- 30%) Power consumption : AC – 18VA DC – 10W Inputs and Outputs Current (mA) output Function : Passive (externally powered) Level : 4 …...

  • Page 51: Start-Up

    Start-Up 3.1 Factory Set Parameters The mass flow meter leaves the factory ready to be used. All process data has been programmed according to the customer order. When no process details were supplied at the time of order, the mass flow meter is programmed to a standard default set of values and functions.

  • Page 52: Zero Point Adjustment

    • These sensors then duplicate the functions of the push buttons. • This is mandatory in Ex environments • Also recommended in humid environments KROHNE MFC 50 Installation and Operating Instructions OPTIMASS...

  • Page 53: Programming The Converter Mfc

    Do not damage the screw thread and the gasket, never allow dirt to accumulate, and make sure they are well greased at all times. Display 1st (top) line Display 2nd (middle) line Display 3rd (bottom) line: arrows (▼) to identify the state of the signal KROHNE MFC 50 converter • Status message indicator •...

  • Page 54: Optimass Mfc 050/051 Operating Concept

    4.2 OPTIMASS MFC 050/051 Operating Concept Installation and Operating Instructions OPTIMASS...

  • Page 55: Key Functions

    4.3 Key functions Function of the keys Cursor The location of the cursor on the display is indicated by flashing characters. This could be a single digit when entering number; numeric sign ( + or -) ; measurement units (g, kg, t etc.);...

  • Page 56: How To Enter Programming Mode

    A wrong Supervisor CodE 1 was keyed in. Press any key and set CODE WRONG the correct 9-keystroke Supervisor CodE 1.* * If correct code is not known, note number given (XXXXX) and contact KROHNE for further instructions regarding decoding. 4.3.2 How to terminate Programming mode...
  • Page 57 Examples The cursor (flashing part of display) has a grey background in the following examples: To start programming Measurement mode Programming mode → 1 3. 5 7 1 F c t. 1. 0 m 3 / O P E R A T I Note: When ”yes”...
  • Page 58 To change numeric values Increase numeric value ↑ 2 1 0 . 2 1 0 . k g / k g / To move the cursor (flashing digit) To move to the right → 2 1 0 . 2 1 0 . k g / k g / To move the decimal point...

  • Page 59: Table Of Programmable Functions

    4.4 Table of programmable functions Fct. Text Description and settings OPERATION Main menu 1 Operation ZERO CALIB. Submenu 1.1 Zero adjustment 1.1.1 AUTO. CALIB. Automatic zero adjustment *1) Select: SURE YES or NO *2) If YES: Calibration (approx. 30 sec. duration) Display: Actual flow rate as percent of the maximum rated flow for the primary head.
  • Page 60 Fct. Text Description and settings TEST Main Menu 2. Test functions DISPLAY. Carry out display test * SURE (NO). Use the ↑ key to select YES, then press ↵ (Duration of test approx. 30 sec.). Stop test at any time with the ↵ key. CUR.
  • Page 61 Fct. Text Description and settings CONFIG Main menu 3 Configuration BASIS.PARAM Submenu 3.1 Base data 3.1.1 L.F. CUTOFF Low flow cut-off Value: 0 to 10 percent of nominal flow 3.1.2 TIME CONST. Time constant for output of measured values Range 0,2 ... 20 sec. 3.1.3 FLOW MODE Define whether bi-directional or uni-directional flow is expected.
  • Page 62 Fct. Text Description and settings 3.2.11 CONC.BY.VOL. Monitor concentration by volume * Select OFF (no concentration by volume on display or * PERCENT V 3.2.12 VELOCITY Monitor flow velocity * Select OFF (no flow velocity on display or) * m/sec * ft/sec 3.2.13 LANGUAGE...
  • Page 63 Fct. Text Description and settings I.O. CONFIG Main menu 4 Input/output configuration I.O. FITTED Submenu 4.1 Fitted inputs and outputs Setting of fitted input/output modules * NONE * I F A B (1 current op, 1 pulse/frequency op, 1 alarm op, 1 control ip) * I Fcl B (1 current op, 1 dual phase shifted frequency op, 1 control ip) * I RS485 (1 current op, Modbus) MFC 050...
  • Page 64 Fct. Text Description and settings PULSE OUT. Submenu 4.5 Pulse/frequency output 4.5.1 FUNCTION Function pulse/frequency output P * OFF (Output = 0V DC) * MASS FLOW (Frequency output 0 to MAX Freq. Hz = Mass Flow in range: MIN. FLOW to MAX FLOW as set in Fct. 4.5.2 and 4.5.3) * DENSITY (Frequency output 0 to MAX Freq.
  • Page 65 Fct. Text Description and settings ALARM. OUT Sub menu 4.6 Process alarm output 4.6.1 FUNCTION Function for alarm output * OFF (Output goes to its inactive state) * MASS FLOW (Alarm active if mass flow goes outside limits as set in Fcts. 4.2 to 4.5) * DENSITY (Alarm active if density goes outside limits as set in Fcts.
  • Page 66 Function not available with Custody Transfer Protection COMM.MODULE Submenu 4.9 Communication modules 4.9.1 PROTOCOL Display of communication protocol fitted (OFF, SERIAL, HART, MODBUS, PROFIBUS, FF BUS or KROHNE) 4.9.2 ADDRESS Address (not available for selection OFF and SERIAL in Fct. 4.9.1) 4.9.3 BAUDRATE Setting Baudrate (for option MODBUS in Fct.
  • Page 67 Fct. Text Description and settings FACTORY.SET Main menu 5 Factory settings CALIBRATED Submenu 5.1 Calibration values 5.1.1 5.1.2 5.1.3 5.1.4 5.1.5 5.1.6 5.1.7 5.1.8 5.1.9 5.1.10 CF10 Display of transducer calibration coefficients 5.1.11(Read only) 5.1.11 CF11 5.1.12 CF12 5.1.13 CF13 5.1.14 CF14 5.1.15...

  • Page 68: Reset / Quit Menu - Totalizer Reset And Status Indication Acknowledgement

    4.5 Reset / Quit Menu - Totalizer reset and status indication acknowledgement Totalizer reset Button Display Description 10.36 Measurement mode ↵ CodE 2 Enter access Code 2 for reset/quit menu: ↑ → –– ↑ → RESET.TOTAL Totalizer reset menu If the additional totaliser is selected (Fct. 3.1.6) a choice of reset options is presented: * RESET ALL Reset all totalisers...

  • Page 69: Description Of Functions

    Description of Functions In all the following examples, a short notation is used for the setting of the signal converter. Pushing a key several times is indicated by the number of times without the intermediate display messages. Only the final display output is listed. 5.1 Menu 1 - Initial Start up Zero Point Adjustment Fct.
  • Page 70 Under certain conditions, it may not be possible to adjust the zero point, for instance when: • The medium is in motion, because the shut-off valves etc. are not functioning properly. • There are still gaseous inclusions in the primary head because it was flushed insufficiently. In such cases the zero point adjustment will not be accepted.
  • Page 71 Note: When changing from STOP into STANDBY the instrument will run through the STARTUP mode. In addition to these 'standby' modes the SYSTEM CONTROL function provides a fully automated way of switching to similar modes using either the density or temperature of the process fluid as a control (see submenu 4.8).
  • Page 72 First (1 ) Entered Sample Option: CAL Sample 1 Exit - Do not calibrate and exit (Does not change the calibration details) CAL Sample 1 This gives you a choice of the following products air, pure water, town water and other. Enter the product that is in the meter.
  • Page 73 Density of water as a function of temperature Temperature in Density in Temperature in Density in °C °F kg/m lb/ft3 °C °F kg/m lb/ft3 999.8396 62.41999 22.5 72.5 997.6569 62.28372 32.9 999.8712 62.42197 73.4 997.5398 62.27641 33.8 999.8986 62.42367 23.5 74.3 997.4201 62.26894...
  • Page 74 Temperature in Density in Temperature in Density in °C °F kg/m lb/ft3 °C °F kg/m lb/ft3 990.2427 61.82085 145.4 981.7646 61.29157 45.5 113.9 990.0341 61.80783 63.5 146.3 981.5029 61.27523 114.8 989.8239 61.79471 147.2 981.2399 61.25881 46.5 115.7 989.6121 61.78149 64.5 148.1 980.9756 61.24231...

  • Page 75: Menu 2 - Functional Checks

    5.2 Menu 2 – Functional Checks Menu 2.0. contains a number of test functions. These allow the current, frequency and alarm outputs to be driven at a number of fixed test levels, so that the communication between the converter and the customer's equipment can be verified.
  • Page 76 Testing the pulse output Fct. 2.5 To test the pulse output, connect an external counter to the output terminals. When testing the pulse output, the operator has the choice of the following pulse widths: 0.4 ms, 1.0 ms, 10.0 ms, 100.0 ms and 500 ms.
  • Page 77 Testing alarm output Fct. 2.7 This is a simple function that allows the alarm output to be tested at both its high and low states. Display Line 1 Line 2 Fct. (2) TEST →↑ Fct. 2.(1) DISPLAY → Fct. 2.(7) Alarm out ↑...
  • Page 78 Viewing sensor signal conditions – Diagnose Fct. 2.9 Menu 2.9 allows the viewing of eight parameters Display Line 1 Line 2 Fct. 2.9 Diagnose Fct. 2.9.1 ↑ This displays the temperature of the measuring tube. By pressing the → key, the temperature will be indicated. By pressing the ↵...

  • Page 79: Menu 3- Configuration Menu

    5.3 Menu 3- Configuration Menu To access this menu, enter programming mode Display Line 1 Line 2 Fct. 1 Operation → Fct. 2 Test ↑ Fct. 3 Config. ↑ Fct. 3.1 Basic Param. → Fct. 3.1.1 Low Flow cut off →...
  • Page 80 To set a time constant: e.g. 0.5 sec Display Line 1 Line 2 From 3.1.(2) Time. Const. (0)0.3 Time. Const. → (0).2 Time. Const. → 0.(2) Time. Const. → ↑ Repeat ↑ key till 5 is reached, then to accept the value. ↵...
  • Page 81 Flow direction Fct. 3.1.4 This function allows the user to select the direction of the flow measurement in relation to the arrows on the Front End housing. (see section 1.1 General Principles). ‘Forward’ is selected if the flow is in the same direction as the + arrow and ‘Backward’...
  • Page 82 Pressure Suppression Fct. 3.1.8 and 3.1.9 The Pressure Suppression feature eliminates any influences on the measurement result of sudden termination of flow, such as when a valve is shut. When this occurs the propagation of pressure waves along the pipe work and through the meter may produce an “Over-shoot” or “ringing” effect, where the flow rate will oscillate backwards and forwards until it settles to a stable zero flow condition, as is indicated in the diagram below.
  • Page 83 Cyclic Display Fct. 3.2.1 The display can be programmed to cycle between all values or to remain static at the selected variable. To select an option: Display Line 1 Line 2 From Fct. 3.2.1 Cycle Disp. STATIC DISPLAY → CYCLE DISPLAY ↑...
  • Page 84 Volume Total Fct. 3.2.5. Parameters for the volume totalizer are selected in this menu. Display Line 1 Line 2 From Fct. 3.2.5 Volume Tot. (off) – default is off. → Selects the totalizer display. ↑ 00000.000 (cm³) Selects the units. Selection of cm³, dm³, litre, m³, in³, ft³, US gal, ↑...
  • Page 85 Velocity: Fct. 3.2.12 This function provides an additional measurement parameter. This is particularly useful when the velocity of hazardous materials is to be monitored where static build up is a danger. The mass flow meter will calculate the velocity based on the tube diameter and the mass flow rate. In this menu the units for velocity may be selected.
  • Page 86 Menu 3.5 Passwords This menu contains all the settings to protect the configuration of the instrument from accidental or deliberate changes. Display Line 1 Line 2 From Fct. 3.5.1 Supervisor By pressing this button Enable PW appears. → Selects further options, change PW or Exit. ↑...

  • Page 87: Menu 4 - I/O Configuration

    Menu 3.6 Settings This menu allows a Tag or ID number to be programmed. A combination of alphanumeric characters is available. Display Line 1 Line 2 From Fct. 3.6.1 Tag ID Allows the programming of a Tag number. → The ↑ provides the selection of character required while the → allows the selection of the next character to be selected.
  • Page 88 Range Fct. 4.2.2. This allows the setting of the measurement range of the output. Choose from the following: Fct. 4.2.2. Range 4-20 mA 4-20/2 mA defaults to 2 mA in case of a fault. 4-20/3.5 mA defaults to 3.5 mA in case of a fault (required by some control systems).
  • Page 89 Alarm Output – Menu 4.6 Function Fct. 4.6.1. Any one of the following may be programmed / selected for the alarm output. Fct. 4.2.1. Function no alarm function Mass flow Density Mass total Volume flow Volume total Temperature Direction Severe Error All Errors I1 Sat.
  • Page 90 This menu is normally a read only menu. It indicates the communications protocol used by the converter. Protocol Fct. 4.9.1. This menu displays the communication protocol fitted. Options available: • Off – no options fitted • Serial – Internal KROHNE service and calibration protocol • HART® • Modbus • Profibus PA •...
  • Page 91 Calibration – Menu 4.10 This menu allows the calibration of the current outputs. This is always factory set before shipment. It only requires performing if any of the configuration for outputs, or output modules have been changed. I1 5mA Fct. 4.10.1. Injects 5 mA on the output terminals for the first current output.

  • Page 92: Menu 5 - Factory Settings

    5.5 Menu 5 - Factory Settings This menu allows the user to view certain information relating to the meter. E.g. calibration co-efficients, meter type, size, serial numbers etc. Fct. 5.1.1. through to Fct. 5.1.20. Read only transducer co-efficients. Meter Corr. Fct. 5.1.21. Correction factor if meter over or under reads in an application.
  • Page 93 Serial numbers – Menu 5.5 All the components that make up the complete instrument have individual serial numbers. This menu displays the serial numbers of the individual components. These serial numbers are mainly used for service purposes. The system serial number is the only serial number that is required when communicating with the factory.

  • Page 94: Service And Trouble Shooting

    Value of strain in Ohms. The values should be in the range stated in the table in chapter 7.3. Wildly unstable value even after temperature stabilisation: the strain gauge has possibly become delaminated due to the meter being operated over maximum temperature for prolonged periods of time (please contact KROHNE UK service department). Frequency (menu 2.9.4): •...

  • Page 95: Error Messages

    6.2 Error Messages • Basic Errors: These errors are displayed independently of which error message function is selected. • Transducer Errors: These errors only occur when error massage function is set to TRANS.ERROR or ALL ERRORS • I/O Errors: These errors only occur when TRANS.ERROR or ALL ERRORS is set to I/O Errors or All Errors •...

  • Page 96: Functional Tests And Troubleshooting

    6.3 Functional Tests and Troubleshooting Min. and Max. recorded temperature (menu 5.4): Records the maximum values of temperature and strain as experienced by the transducer. Maximum Minimum Max. operating temperature: OPTIMASS 7000 - Titanium 150°C or 302°F -40 °C or –40°F OPTIMASS 7000 - Hastelloy 100°C or 212°F 0°C or 32°F...
  • Page 97 Zero Problems • Perform auto zero, observe the displayed value, it should be stable and lower than +/- 0.5% • If the result is bad: Stop flow, set 3.1.1 Low flow cut off to 0, 3.1.3 Flow Mode to “+/-”, perform auto zero, and totalise over 2 minutes.

  • Page 98: Replacing The Front End Or Back End Electronics

    OPTIMASS 8000 / 9000 OPTIMASS Inductance (mH) Resistance (Ohm) Driver Sensor A/B Driver Sensor A/B 8000 0.735 12.5 9000 0.95 • The above data are provided as a rough guide only. • Driver = White / Brown • Sensor A = Orange / Black. Sensor B = Grey / Blue •...

  • Page 99: Replacing The Back End

    6.4.2 Replacing the Back End Unscrew the front lid and undo the two screws holding the display in place. The two screws holding the converter in the housing can now be seen towards the rear on the steel frame. Take care not to damage any components while attempting to loosen these screws.

  • Page 100: Spares

    6.5 Spares Description Part No Converters Complete Display Ex + Non Ex X2132750100 Front end electronics (cast in SS lid) X2134330100 Front end gasket X6870069989 Converter electronics insert (see main price list) Converter Output Modules (MFC 050 only) current output module non GI X2107010000 I/O Module, (input/output contact &...
  • Page 101 Terminal Labels for MFC 050 Housing Pack of 10 Opt 1: 1 x 4-20 mA, 1 x Pulse, 1 x Control input, 1 x Status output-HART X386054 Opt 2: 1 x 4-20 mA, Modbus X386056 Opt 3: 1 x 4-20 mA, 1 x Control input, 1 x dual phase frequency output-HART X586057 Opt 4: 2 x 4-20 mA, 1 x Pulse, 1 x Control input-HART X386058...

  • Page 102: External Standards And Codes

    External Standards and Codes 7.1 Standards The OPTIMASS range of mass flow meters comply with some or all of the following standards or codes: 7.1.1 Mechanical Pressure Equipment Directive PED 97/23/EC (acc. to AD2000 Regelewerk) Hygienic ASME Bioprocessing ASME BPEa-2000 Addenda to BPE-1997 3A Dairy Products Standard (28-03) Authorization No.

  • Page 103: Declaration Of Conformity

    7.2 Declaration of Conformity Installation and Operating Instructions OPTIMASS...

  • Page 104: Ped Certificate

    7.3 PED Certificate Installation and Operating Instructions OPTIMASS...
  • Page 105 Installation and Operating Instructions OPTIMASS...

  • Page 106: Device Configuration Sheet

    Device Configuration sheet The following pages can be photocopied for your use when required. Serial No. Tag No. MENU 3 CONFIGURATION 3.1.1 L.F. CUTOFF 3.2.6 TEMPERATUR. 3.1.2 TIME CONST. 3.2.7 DENSITY 3.1.3 FLOW MODE 3.2.8 CONC. FLOW 3.1.4 FLOW DIR. 3.2.9 CONC.
  • Page 107 Notes Installation and Operating Instructions OPTIMASS...

  • Page 108: Declaration Of Cleanliness Certificate

    KROHNE may only handle, test and repair returned devices that have been in contact with products without risk to personnel and environment. This means that KROHNE can only service this device if it is accompanied by the following certificate confirming that the device is safe to handle.
  • Page 109 Denmark Peru KROHNE Messtechnik KROHNE Austria Ges.m.b.H. Singapore Ecuador Poland GmbH & Co. KG Modecenterstraße 14 Tokyo Keiso - KROHNE Singapore Pte. Ltd. Egypt Portugal Ludwig-Krohne-Str. A-1030 Wien 14, International Business Park, Finland Romania D-47058 Duisburg TEL.: +43(0)1/203 45 32...

This manual is also suitable for:

Optimass 7000Optimass 3000Optimass 7100Optimass 8000Optimass 9000
