"TO BE REMOVED FOR USE BY THE OCCUPANT."
Jason International, Inc.
8328 MacArthur Drive
North Little Rock, AR 72118
www.jasoninternational.com
MADE IN THE U.S.A.
INSTALLATION, OPERATION, AND MAINTENANCE
If the carton shows sign of damage, inspect
the product before accepting and describe the
problem on the Bill of Lading.
INSPECTION
Inspect the unit prior to installation. In the event of a
problem, DO NOT install the unit.
All components are factory assembled to the bath and the
unit is water tested and inspected prior to leaving Jason
International, Inc.
NOTE: Transportation and insurance from Jason's
factory are the buyer's responsibility.
Damage sustained in transit is the responsibility of
the carrier. If damage is discovered, the carrier must
be immediately notified in writing with a request for a
representative to inspect the unit. Failure of the carrier
to respond should be reported to the seller and carrier.
Always file a freight claim promptly.
The installer is responsible for insuring that the unit is
free from defects or shipping damage. In the event of a
problem, DO NOT install the unit.
Jason International is not responsible for damage that
might have been avoided by inspection or testing prior to
installation.
Damage to the unit during installation will not be covered
by warranty and is the responsibility of the installer.
OWNER'S RECORD
Dealer:
Date Purchased:
Date Installed:
Installer:
Jason International, Inc. • 501.771.4477
OWNER'S MANUAL
forma
and Designer Collection Baths
®
ALL WARRANTY CLAIMS ON ACRYLIC SURFACE
DAMAGE MUST BE MADE PRIOR TO INSTALLATION.
Inspect plumbing and bath surface for missing or damaged
components. Alert your dealer of any discrepancies.
To protect the unit from damage keep the bath in the
carton until ready for installation.
EQUIPMENT ACCESS
In accordance with Building Codes, service access to
all hydrotherapy bath equipment, controls and electrical
connections must be provided during installation
(Recommended minimum 28" x 17" [71 x 43 cm]).
Insufficient access will hinder repair and maintenance.
Warranty service will not cover costs of providing
equipment access.
The Specification Sheet for this bath contains additional
technical information. This sheet can be provided by your
dealer or accessed online at www.jasoninternational.com.
PLACE SERIAL NUMBER CARD WITH
PRODUCT CONFIGURATION IN THIS BOX
Page 1 of 25
49-1020-000
Date 08/2018
Customer Service : 800.255.5766
Copyright © 2018 Jason International, Inc.
Copyright © 2018 Jason International, Inc.
Advertisement
Table of Contents
Related Manuals for JASON Hydrotherapy AirMasseur
Summary of Contents for JASON Hydrotherapy AirMasseur
- Page 1 “TO BE REMOVED FOR USE BY THE OCCUPANT.” Jason International, Inc. 49-1020-000 8328 MacArthur Drive Date 08/2018 North Little Rock, AR 72118 www.jasoninternational.com MADE IN THE U.S.A. OWNER’S MANUAL forma and Designer Collection Baths ® INSTALLATION, OPERATION, AND MAINTENANCE If the carton shows sign of damage, inspect ALL WARRANTY CLAIMS ON ACRYLIC SURFACE DAMAGE MUST BE MADE PRIOR TO INSTALLATION.
-
Page 2: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS INSTRUCTIONS PERTAINING TO THE RISK OF FIRE, ELECTRIC SHOCK, OR INJURY TO PERSONS. This manual contains information and instructions for proper operation and maintenance of your therapy bath. Failure to follow these instructions could result in personal injury, electrical shock, or fire. WARNING: When using this unit, basic precautions should always be followed, including the following: READ AND FOLLOW ALL INSTRUCTIONS CAREFULLY DANGER: TO REDUCE THE RISK OF INJURY FOLLOW THESE PRECAUTIONS:... -
Page 3: Consignes De Sécurité Importantes
CONSIGNES DE SÉCURITÉ IMPORTANTES INSTRUCTIONS RELATIVES AU RISQUE DE FEU, CHOC ÉLECTRIQUE, OU DE BLESSURE. Ce manuel contient des informations et des instructions pour le bon fonctionnement et l’entretien de votre bain thérapeutique. Ne pas suivre ces instructions cela pourrait entraîner des blessures corporelles, un choc électrique ou un incendie. AVERTISSEMENT: Lors de l’utilisation de cet appareil, des précautions de base doivent toujours être suivies, y compris les suivantes: LIRE ET SUIVRE TOUTES LES INSTRUCTIONS ATTENTIVEMENT... - Page 4 Cautionary Warnings (English/French) ATTENTION: la temperature ambiante sous la baignoire où CAUTION: Ambient temperature under the bath where equip- l’équipement est installé ne doit pas dépasser 50°C. ment is installed must not exceed 122°F (50°C). AVERTISSEMENT : Toute modification de l’équipement n’est WARNING: Any modification to the equipment is not recom- pas recommandé...
- Page 5 Jason offers the finest in soaking hydrotherapy baths but also offers the option for more hydrotherapy choices with This manual contains all of the information needed for Jason MicroSilk or AirMasseur therapy units. Please ® ® the proper installation and operation for your Jason bath.
- Page 6 AIRMASSEUR FEATURES WHIRLPOOL FEATURES ® Jason’s AirMasseur hydrotherapy bath fills the bath with Jason’s Whirlpool hydrotherapy bath utilizes Perfect Pres- millions of warm air bubbles to create a blanket of rolling sure/Perfect Flow jets that are directed at key muscle movement, gently massaging your skin.
- Page 7 FEATURES, CONTROLS AND OPERATING INSTRUCTIONS (cont.) STANDARD/PREMIER EDITION ELECTRONIC CONTROLS MicroSilk [MS] AirMasseur [AM] ® ® Whirlpool [WP] MicroSilk-AirMasseur [MA] MicroSilk-Whirlpool [MW] AirMasseur-Whirlpool [AW] ICONS POWER Icon LED Icon (Premier & Signature) WHIRLPOOL Icon PILLOW Icon (Optional) Blower SPEED Icon...
- Page 8 FEATURES, CONTROLS AND OPERATING INSTRUCTIONS (cont.) STANDARD/PREMIER EDITION OPERATING INSTRUCTIONS One main control touchpad mounted on the bath features several icons used by the bather to control the bath. This sec- tion will outline the functions of the system when a particular icon is pressed. If the icon is lit WHITE, then that particular option is available to operate.
- Page 9 Icon MicroSilk ® Icon The MICROSILK icon is used to activate the The AIRMASSEUR icon is used to activate the MicroSilk unit and the 20-minute timer. blower and the 20-minute timer. • Once pressed, the microbubble generator will start •...
- Page 10 FEATURES, CONTROLS AND OPERATING INSTRUCTIONS (cont.) SIGNATURE EDITION ELECTRONIC CONTROLS MicroSilk [MS] AirMasseur [AM] ® ® Whirlpool [WP] MicroSilk-AirMasseur [MA] MicroSilk-Whirlpool [MW] AirMasseur-Whirlpool [AW] ICONS WHIRLPOOL Icon PILLOW Icon (Optional) AIRMASSEUR Icon Blower SPEED Icon LED Icon (Premier & Signature) MICROSILK Icon Jason International, Inc.
- Page 11 Use the Blower SPEED icon to change an ® option. For example, press and release the AIRMASSEUR icon to change from Product Test to the Temperature option. Press and release the SPEED icon to change the temperature display from Fahrenheit (°F) to Celsius (°C).
- Page 12 FEATURES, CONTROLS AND OPERATING INSTRUCTIONS (cont.) WHIRLPOOL Icon AIRMASSEUR Icon ® The AIRMASSEUR icon is used to activate the The WHIRLPOOL icon is used to activate the blower and the 20-minute timer. whirlpool pump and the 20-minute timer. • CONSTANT Mode will start with the first press and •...
-
Page 13: User Maintenance Instructions
USER MAINTENANCE INSTRUCTIONS HUMIDITY SURFACE MAINTENANCE Area with minor scratches or dull surfaces can be restored WARNING: Avoid high humidity levels in your home. by applying commercially available plastic polish (i.e. No- Mold, mildew, fungi and bacteria which may be harm- vus Plastic Polish No. -
Page 14: Installation Instructions
Ventilation (AM, MA or AW baths) ® A minimum ventilation opening of 2” x 4” [5x10cm] for the AirMasseur blower is required. It should be designed to 1. Finish Frame draw in indoor ambient air at a minimum of 72°F [22°C]. - Page 15 INSTALLATION INSTRUCTIONS (cont.) 6. Integral Tile Lip Alcove Installation 7. Tile Flange After the bath has been leveled, confirm the height mea- 100% Silicone with mildew resistant properties should be surement of the underside of the flange deck in order to applied between the water resistant backer board and the install a 1”x2”...
- Page 16 INSTALLATION INSTRUCTIONS REMOTE MOUNTING OF AIR BLOWER FIELD INSTALLATION OF THE The Jason AirMasseur® system has been factory installed WHIRLPOOL PUMP ASSEMBLY following ETL/UL Standard safety guidelines. During in- The Jason Whirlpool system has been factory installed stallation, if remote mounting of the air blower is desired or following ETL/UL Standard safety guidelines.
-
Page 17: Electrical Installation
INSTALLATION INSTRUCTIONS (cont.) ELECTRICAL INSTALLATION These instructions are written assuming 60Hz, 120V power The pumps are supplied with an electrical bonding lug to supply. Verify the electrical requirements of the bath unit allow connection of a solid copper bonding conductor be- before installation. - Page 18 INSTALLATION INSTRUCTIONS MICROSILK® [MS] SYSTEM Additional Options Available: Standard Edition Bluetooth Sound Immersion: (Included on Signature Edition) MS Pump Optional Bluetooth Sound Immersion Transducers installed on bath. Bluetooth amp supplied Keypad and field installed. [IDU-264] TRANSDUCER J S O N Ncmi Pinc Mloi Drooidvlro To Dedicated...
- Page 19 INSTALLATION INSTRUCTIONS (cont.) AIRMASSEUR® [AM] SYSTEM Additional Options Available: Standard Edition Bluetooth Sound Immersion: Cmrzis (Included on Signature Edition) Optional Bluetooth Sound Immersion Keypad Transducers installed on bath. Bluetooth amp supplied [IDU-264] and field installed. TRANSDUCER Ncmi Pinc J S O N...
- Page 20 INSTALLATION INSTRUCTIONS WHIRLPOOL [WP] SYSTEM Additional Options Available: Standard Edition Bluetooth Sound Immersion: WP Pump (Included on Signature Edition) Optional Bluetooth Sound Immersion Transducers installed on bath. Bluetooth amp supplied Keypad and field installed. [IDU-264] TRANSDUCER J S O N Ncmi Pinc Mloi Drooidvlro Keypad Cable...
- Page 21 INSTALLATION INSTRUCTIONS (cont.) MICROSILK®-AIRMASSEUR® [MA] SYSTEM Additional Options Available: Standard Edition MS Pump Bluetooth Sound Immersion: (Included on Signature Edition) Optional Bluetooth Sound Immersion Keypad Transducers installed on bath. Bluetooth amp supplied [IDU-264] and field installed. TRANSDUCER J S O N...
- Page 22 INSTALLATION INSTRUCTIONS MICROSILK®-WHIRLPOOL [MW] SYSTEM Standard Edition Additional Options Available: Bluetooth Sound Immersion: WP Pump (Included on Signature Edition) Optional Bluetooth Sound Immersion Keypad Transducers installed on bath. Bluetooth amp supplied and field installed. [IDU-264] TRANSDUCER MS Pump J S O N Ncmi Pinc Mloi Drooidvlro Keypad Cable...
- Page 23 INSTALLATION INSTRUCTIONS (cont.) AIRMASSEUR®-WHIRLPOOL [AW] SYSTEM Standard Edition Additional Options Available: Bluetooth Sound Immersion: WP Pump (Included on Signature Edition) Cmrzis Optional Bluetooth Sound Immersion Keypad Transducers installed on bath. Bluetooth amp supplied [IDU-264] and field installed. Ncmi Pinc J S O N...
-
Page 24: Troubleshooting Guide
TROUBLE SHOOTING GUIDE If you believe the unit to be within the warranty period, you must contact Jason Customer Service: 1-800-255-5766 with the bath’s Product and Serial numbers before work is started. These numbers can be found on the label on the front page of this manual and also adhered to the underside of the bath above the equipment. - Page 25 TROUBLE SHOOTING GUIDE AIRMASSEUR [AM, MA or AW] BLOWER SYSTEM ® SYMPTOMS POSSIBLE CAUSES RECOMMENDED ACTION Air bath does not function properly a. Blower speed setting is set too low a. Change to a mid-range air speed while in Wave or Pulse mode.
