- Page 1 VESA Mount Adapter | Premium | Silver Actual product may vary from photos User Manual SKU#: APLVESAMNTP For the latest information and specifications visit www.startech.com/APLVESAMNTP Manual Revision: 10/21/2019...
-
Page 2: Compliance Statements
This manual may make reference to trademarks, registered trademarks, and other protected names and/or symbols of third-party companies not related in any way to StarTech.com. Where they occur these references are for illustrative purposes only and do not represent an endorsement of a product or service by StarTech.com, or an endorsement of the product(s) to which this manual... -
Page 3: Warning Statements
Il prodotto è in grado di supportare i seguenti pesi: 14 kg. • Il prodotto è destinato all’uso in ambienti interni. Se ne sconsiglia l’impiego in ambienti esterni. To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support... - Page 4 • Dit product is alleen bedoeld voor binnengebruik en mag niet buiten worden gebruikt. 注意 • 必ず取扱説明書に従って本製品の組み立てを行って下さい。 • 本製品で定められた最大積載重量を超えないようにして下さい。 最大積載重量をオーバーした 場合、 怪我をする恐れや器物破損の恐れがあります。 本製品は、 モニター1台あたり14kgまで支 持できます。 • 本製品は、 室内での使用を想定しています。 戸外では使用しないで下さい。 To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support...
-
Page 5: Table Of Contents
Table of Contents Compliance Statements ................1 Warning Statements ................2 Product Diagram ..................5 Product Information ................6 Specifications.............................. 6 Package Contents ............................. 8 Attaching a Monitor ................10 To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support... -
Page 6: Product Diagram
Product Diagram Plastic Caps (x 4) Mounting Point VESA Monitor Adapter To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support... -
Page 7: Product Information
Product Information Specifications Type of measurement Measurement 75x75 100x100 VESA Mounting Hole Pattern +900 to -150 Tilt Maximum 30 in. (762 mm) Screen Size 3600 Rotate To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support... - Page 8 3600 Swivel 30.8 lb. (14 kg) Weight/Load Capacity To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support...
-
Page 9: Package Contents
Package Contents Monitor Mount Flange Mount Qty: 1 Qty: 1 VESA Screws Torx Key Qty: 4 Qty: 1 To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support... - Page 10 3 mm Hex Key 4 mm Hex Key Qty: 1 Qty: 1 Access Card Monitor Mount Screws Qty: 1 Qty: 2 Plastic Caps Qty: 4 To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support...
-
Page 11: Attaching A Monitor
Only the Access Card should be used to disengage the lock- ing mechanism. Tilt the iMac Monitor and Insert the Access Card To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support... - Page 12 While sliding the Flange overtop of the Mounting Bracket, align the center hole and the eight holes in the Flange with the eight threaded holes and alignment pin on the Mounting Bracket. To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support...
- Page 13 Installing the Flange Slide the Plastic Caps (x 4) over the ends of the Monitor Mount, to protect the surface of the iMac Monitor. Installing the Plastic Caps To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support...
- Page 14 Insert the 2 Monitor Mount Screws through the Monitor Mount and into the Flange. Use the Hex Key (4 mm) to tighten the Monitor Mount Screws. Be careful not to over-tighten the Monitor Mount Screws. To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support...
- Page 15 Mounting Peg on the top Swivel Arm on the compatible Startech.com mount. Slide the Mounting Hole on the Monitor Mount over the Mounting Peg until it clicks into place. To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support...
- Page 16 Using the 4 mm Hex Key, adjust the swivel tension of the Monitor Mount by loosening or tightening the Hex Screw located on the Monitor Mount next to the Mounting Hole. To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support...
- Page 17 Limitation of Liability In no event shall the liability of StarTech.com Ltd. and StarTech.com USA LLP (or their officers, directors, employees or agents) for any damages (whether direct or indirect, special, punitive, incidental, consequential, or otherwise), loss of profits, loss of business, or any pecuniary loss, arising out of or related to the use of the product exceed the actual price paid for the product.
