A S S E M B LY I N S T R U C T I O N S
The 4x4 (122cm x 122cm)
Composite Garden Bed
Please read through before starting assembly.
Check Box for These Contents
In the event of missing or defective parts please call our customer service dept. at 1 800 282 9346 (Mon. to Fri. 8:00 AM to 4:00 PM EST).
(UK Tel: (44) 2038 687160 - Mon. to Fri. 1:00 PM to 10:00 PM GMT).
1. Posts (4) -
14063
2. Side Panels (8) -
14064
3. Post Caps (4) -
14065
General Information
• Read Instructions through carefully before beginning assembly.
• When assembling components, place on a non-abrasive surface
(i.e. shipping box) to avoid scratching.
• We recommend an area approx 4'x 8' (1.2m x 2.4m) for unobstructed assembling.
• You should not need to use excessive force when assembling components.
11" (28cm)
12" (30cm)
3
1
2
24"
(61cm)
(122cm)
42"
(107cm)
48"
(122cm)
www.newenglandarbors.com
www.newenglandarbors.co.uk
48"
(122cm)
45"
(114cm)
48"
45" (114cm)
Ver 2.1-100517
1
Advertisement
Table of Contents
Related Manuals for New England Arbors The 4x4 Composite Garden Bed
Summary of Contents for New England Arbors The 4x4 Composite Garden Bed
- Page 1 A S S E M B LY I N S T R U C T I O N S The 4x4 (122cm x 122cm) www.newenglandarbors.com Composite Garden Bed www.newenglandarbors.co.uk 48" (122cm) 11" (28cm) 24" 45" (61cm) (114cm) 12" (30cm) 48" 45"...
- Page 2 The 4x4 (122cm x 122cm)Composite Garden Bed S T E P O N E Raised Bed Assembly Insert boards into the posts as shown. The boards are tabbed and will lock into place once fully inserted into the routed holes on the posts.
