CAUTION
Electromagnetic compatibility
Electromagnetic influences in the surrounding area may interfere with the device resulting in false
readings. Only use probe cables and USB cables under 3 m in length to connect the device.
Do not operate the device with an external USB power supply.
NOTICE
Handling batteries
Remove the battery if the device will not be used for extended periods to prevent battery leakage.
Dispose of the used batteries in compliance with local regulations.
NOTICE
Operating the Gauge
Protect the device from dust and dirt.
Protect the device from moisture, chemicals and aggressive gases.
Avoid direct sunlight or extreme temperature fluctuations.
1.4 Transport and Storage
Always transport the gauge inside the case to ensure it is properly protected. If the device will not
be used for extended periods, remove the batteries and store the device inside the case.
1.5 Cleaning and Care
Clean the device with a damp, lint-free cloth. If very dirty, you may clean with acetone (Attention!
Do not use on soft rubber parts), cellulose thinner or ethanol.
1.6 Disposal
Dispose of used batteries and the device in compliance with local regulations. Do not dispose of
batteries or the device in the household waste.
8 8 / 48
1 General Information
QNix 9500 EN_ES_FR_IT_NL_PL
2 Device Overview
2 Device Overview
Key functions
Status LED
Power button / Menu/
Homebutton
Q button
programmable functions
Navigation
buttons
OK button
QNix 9500 EN_ES_FR_IT_NL_PL
Indicates USB connection
Switch device on or off, or switch between menu and
measurement display
Context-based or programmable function
QNix® 9500B: Start calibration
QNix® 9500P, 9500P+: Start calibration or advance
area
Navigation within the screen / menu
Confirm entry
