5.6 Set PIN

You can add a 4-digit PIN to lock certain device functions.
> Open the "Settings" menu, select "System" and press
> Press to confirm "PIN"
> Enter the 4-digit PIN with the and
> Press to apply the PIN
NOTICE
Impacts of using a PIN
Entering and confirming the PIN will lock ALL configured measurements options. You can still con-
figure the system settings. You will also still be able to add or edit jobs.
The PIN can be reset in the QN9 software or by entering it again.

5.7 Set Date/Time

The format for the date and time is YYYY-MM-DD-hh-mm.
> Open the "Settings" menu, select "System" and press
> Press to confirm "Date/Time"
> Set the date/time with the and buttons and press

5.8 Configure Softkey

The softkey can be programmed to two functions, "Calibrate" and "Advance area".
> Open the "Settings" menu, select "System" and press
> Select "Configure softkey" and press
> Select the desired setting and press

5.9 Format Memory

CAUTION
Format Memory
The "Format memory" function will erase all jobs, areas, measurements, all user settings, all lan-
guages except German/English, and the QN9 software on the device.
> Open the "Settings" menu, select "System" and press
> Select "Format memory"
A confirmation message will appear. If you actually want to reformat the memory, confirm the
message.
If an error occurs, repeat the formatting process. If you are still unable to format the memory,
please contact your retailer.
30 30 / 48
5 System Settings
to confirm
buttons
to confirm
to confirm
to confirm
to confirm
to confirm
to confirm
QNix 9500 EN_ES_FR_IT_NL_PL

6 Device Management via PC in QN9

6 Device Management via PC in QN9
You can use the QN9 software to manage your devices on a PC. Among other things, you will be able
to,
> rename jobs
> generate test reports
> perform live measurements
> configure device settings on the PC and copy to one or multiple hand-held units
> request help and support via remote maintenance
and much more. For more information, please see the help section in the QN9 software.
Index Software menu Function
1, 11 Jobs
Create job template
Manage jobs
Edit job
Create job
Specifications
Manage measurement memory
2, 14 Life measurement View
Settings
3 Create 3-click report
