Annex | Sensor Values, Data Format, Conversion
A 3.5 IFC2421, IFC2422, IFC2451, IFC2461, IFC2471
RS422 Up to 32 output values can be transmitted at the same time. The data are configured or selected via ASCII
commands or via the web interface.
Baud rate 115200 b/s ex factory
Ex factory, the controller is set for the Distance measurement measuring program. Please refer to the associated operating
instructions for descriptions of additional measuring programs. IFC24xx supplies 3 bytes per value at the output. These bytes are
coded by the IF2030/PNET into 4 bytes, see Chap. 5.3.
The linearized measuring values can be converted in µm using the following formula:
(d - 98232) * MR
x
= OUT
65536
IF2030/ENETIP
x = Displacement / Thickness in mm
dOUT = digital output value
MR = Measuring range in mm
131000 = Midrange for the displacement
measurement
Please refer to the operating instructions for the
confocal distance measuring system
- confocalDT 2421/2422
- confocalDT 2451/2461/2471
for more information, especially about possible
output values.
The current version is available at:
https://www.micro-epsilon.com/download/manu-
als/man--confocalDT-2421-2422--en.pdf
https://www.micro-epsilon.de/download/manuals/
man--confocalDT-2451-2461-2471--en.pdf
