Commissioning
If time synchronization has been enabled on the scanner (SPS), a synchronized signal can be tapped at the S+/S- terminal. Signal
timing can be configured by using Class 0x43, Instance 1, Attribute 300.
Parameter
Byte 0 - 3 Sync Intervall
Byte 4 - 7 Sync Offset
Byte 8 - 11 Res. Sync Interval
Byte 11 - 15 Res. Sync Offset
Byte 16 - 19 Pulse Length
Changes only take effect after IF2030/ENETIP has been restarted.
Please use Class 0xA0, Instance 1, Attribute 7 to configure the level (TTL/HTL).
IF2030/ENETIP
Unit Default Min
ns 500,000,000 10,000 500,000,000
ns 0 0
ns 500,000,000 10,000 500,000,000
ns 150 0
µs 4 1
Max Comments
Synchronization interval 10 µs ... 500 ms
Sync Interval -1
Res. Sync Interval - 1 |Sync Offset – Res. Sync Offset| > 150
Pulse length < min
500
(SyncOffset, Res.Sync Offset)
