Commissioning

5. Commissioning
5.1

Configuring the Sensors

The sensor used must be correctly configured to work with the IF2030. Micro-Epsilon recommends that the sensor's base configura-
tion be set by using its web interface. The configuration can later also be adjusted via fieldbus.
Please refer to the operating instructions of the corresponding sensor for detailed information on configuring the sensor.
5.2

Baud Rate and Sensor Interface

IF2030/ENETIP must be set for the interface used and the sensor's baud rate.
Sensor/
Baud rate [Baud] Bus address RS485 RS422
Controller
ACC5703 230400
ACS7000 230400
DT6120 230400
IFC24x1 115200
IFC242x 115200
ILD1320 921600
ILD1420 921600
Fig. 11 Baud rate (factory setting) of the sensors or controllers to be connected
The baud rate and sensor interface are transferred with Class 0xA0 (Object), see Chap. 5.4.
1) The ILD2300 is set for 691.2 kBaud ex factory. Increase the baud rate to 921.6 kBaud in the sensor.
IF2030/ENETIP
126 •
•
126 •
•
•
•
•
Sensor/
Baud rate [Baud] Bus address RS485 RS422
Controller
ILD1750 921600
ILD1900 921600
ILD2300
921600 1
INC5701 230400
MSC7602 256000
ODC2520 115200
•
•
•
126 •
•
•
Page 16
