Owner's manual
Notes:
• please be sure the battery has been charged fully before first use.
• Charging continues even if the speaker is turned off.
• A speaker battery indicator will be displayed when connected to iOS devices.

oPeration

Operation
power on
power off
Bluetooth pairing
AUX mode
Charging
Charging finished

SPeciFication

• Output power: 2x 5 W
• Impedance: 2 Ω
• Frequency response: 60 Hz ~ 20 kHz
• THd: ≤0.5%
LED Status
Blue LED is on
Red Led flashes 3 times and goes off
Blue Led & Red Led flash
Green LED is on
Red LED is on
Red Led is off
• S/N ratio: ≥95 dB
• Speaker diameter: 52 mm
• NFC
• ports: AUX-in (3,5 mm), headphone (3,5 mm), microUSB (charging)
• Bluetooth 4.0
• Microphone
• Music playback time: up to 12 hours
• Bluetooth range: up to 30 m
• Call management function
• Battery level indicator (iOS only)
• Battery: 4400 mAh
• Charging voltage: 5 V / 1 A
9
