Large Attendant Console
Refer to the small console
on the opposite page for in-
formation on this part of the
large console.
Each feature button has
three color bands. Use Auto
Intercom (preprogrammed
on all of the blue and 20 of
the white bands) to contact
people in your MERLIN
system. Program the re-
maining white and gray
bands with custom features.
Use these numbers to find
the horizontal row for each
intercom number. The 0 in-
dicates the row for intercom
numbers whose second
digit is 0 (10, 20,30,40, etc.).
The 1 indicates intercom
numbers ending in 1 (11, 21,
31, etc.), and so on.
Touch a Shift button to select
the blue, white, or gray band
on a feature button.
Use Message Status with
the Shift buttons to see
which voice terminals have
Message lights turned on.
