Table of Contents
Advertisement
Quick Links
. DESCRIPTION
2. TECHNICAL SPECIFICATIONS
3. PREPARATIONS
4. BOARD LAY-OUT
5. CONNECTION LAY-OUT
6. DESCRIPTION OF CONNECTIONS
6.. TERMINAL BOARD CN
6.2. TERMINAL BOARD CN2
6.3 MOTOR CONNECTION
6.4. BATTERY KIT
7. DIP-SWITCH ADJUSTMENT
7.. OPEN BEAM FUNCTION
8. MEMORY STORING THE RADIO CODE
8.. Memory storage of DS radio controls
8.2. Memory storage of SLH radio controls
8.3. Memory storage of LC radio controls
8.4. Deletion of radio codes
9. OBSTACLE DETECTION SENSITIVITY
0. PROGRAMMING
. CONTROL LEDs
2. FUNCTION LOGICS
Manufacturer:
FAAC S.p.A.
Via Benini, 1 - 40069 Zola Predosa BOLOGNA - ITALY
Address:
Declares that:
Control unit mod. E604 24V
• conforms to the essential safety requirements of the following EEC directives:
73/23/EEC and subsequent amendment 93/68/EEC.
89/336/EEC and subsequent amendment 92/31/EEC and 93/68/EEC
Additional information:
This product underwent a test in a typical uniform configuration (all products manufactured by FAAC S.p.A.).
Bologna, 10-10-2007
Read this installation manual to the full before you begin installing the product.
The symbol
indicates notes that are important for the safety of persons and for the good condition of the
The symbol
draws your attention to the notes on the characteristics and operation of the product.
INDEX
CE DECLARATION OF CONFORMITY
Notes on reading the instruction
automated system.
page.2
page.2
page.2
page.3
page.3
page.3
page.3
page.4
page.5
page.5
page.5
page.6
page.6
page.6
page.6
page.7
page.7
page.7
page.8
page.8
page.9
Managing Director
A. Bassi
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for FAAC E604
Summary of Contents for FAAC E604
- Page 1 • conforms to the essential safety requirements of the following EEC directives: 73/23/EEC and subsequent amendment 93/68/EEC. 89/336/EEC and subsequent amendment 92/31/EEC and 93/68/EEC Additional information: This product underwent a test in a typical uniform configuration (all products manufactured by FAAC S.p.A.). Bologna, 10-10-2007 Managing Director A. Bassi Notes on reading the instruction Read this installation manual to the full before you begin installing the product.
-
Page 2: Technical Specifications
CONTROL UNIT E604 . DESCRIPTION Thanks to its high powered microprocessor, this 24 Vdc control unit for automatic barriers offers a wide range of adjustments, including deceleration and motor control. Thanks to its integrated encoder, the control unit constantly controls rod position and movement, intervening as soon as a faulty situation is detected. -
Page 3: Board Layout
4. BOARD LAY-OUT COMPONENTS COMPONENTS Power supply terminal-board Power supply terminal-board Commands terminal-board Commands terminal-board Battery kit connector Battery kit connector Connector for receiver module Connector for receiver module Power supply to RH closing motor Power supply to RH closing motor Power supply to LH closing motor Power supply to LH closing motor Trimmer for adjusting obstacle detection... - Page 4 6.1.3. F AlsAFe Terminal “4 ”. Connect to this terminal, the negative terminal of the photocell transmitters. By making this connection, the control unit, before every manoeuvre, runs a test on the photocells, controlling correct operation. If you use photocells, this terminal must be connected to ensure the control unit operates correctly. 6.1.4.
-
Page 5: Motor Connection
6.2.8. s AFety devices Terminals “10 & 15”. Normally closed contact. Connect, to these terminals, any safety device (e.g. photocells) which, by opening the contact, acts on beam motion. They can be active only during closure, or active in both closing and opening, according to the position of dip-switch 6, see paragraph 7. -
Page 6: Memory Storing The Radio Code
7.. OPEN BEAM FUNCTION With this function, combined or not with the battery kit, the following beam behaviour patterns are possible: ithout bAttery kit Dip-switch 4=OFF: If there is a mains power cut, the beam stays stopped in the position it is in. When mains power returns, after 2 seconds the control unit automatically commands the beam to close, preparing itself for normal operation. - Page 7 • Put the two radio controls frontally into contact. On the memory stored radio control, press and hold down the push-button relating to the channel you wish to • transfer - the radio control LED lights up on steady beam. •...
-
Page 8: Control Leds
0. PROGRAMMING When the control unit is first powered up, a programming cycle must be performed. The board keeps all commands disabled, with the exception of programming push-button P, and of the pulse generators connected to the OPEN/CLOSE input When you have made the connections of all the accessories and generators, program the operating cycle. To program the control unit, follow the instructions below: Turn the differential switch of the control unit, to make sure that the automated system is not powered.
