- Page 2 Please clarify your application environment before deployment, in case the device can function well. The device is not intended to be used as a reference sensor, and Ursalink will not should responsibility for any damage which may result from inaccurate readings.
-
Page 3: Table Of Contents
6.2.1 Horizontal Installation....................19 6.2.2 Vertical Installation....................19 7. Payload Format..........................20 8.Sensor Management via Ursalink Cloud..................21 8.1 Ursalink Cloud Registration....................21 8.2 Add a Ursalink LoRaWAN Gateway..................21 8.3 Add EM500-SMT to Cloud....................23 Appendix............................23 Default LoRaWAN Parameters....................24 Default Uplink Channels......................24... -
Page 4: Overview
Sensor data are transmitted in real-time using standard LoRaWAN protocol. LoRaWAN enables encrypted radio transmissions over long distance while consuming very little power. The user can obtain sensor data and view the trend of data change through Ursalink Cloud or thr ough the user's own Network Server. -
Page 5: Hardware Introduction
1 × EM500-SMT 2 × Mounting 1 × Hose 1 × Warranty Card 1 × Quick Guide (Include sensor) Screws Clamp 1 × DIN Rail (Optional) If any of the above items is missing or damaged, please contact your Ursalink sales representative. -
Page 6: Transceiver Overview
EM500-SMT User Guide 2.2 Transceiver Overview Front View: ①LoRa Antenna (Internal) ②NFC Area ③Water-proof Connector Back View: ④Battery (Internal) ⑤Wall Mounting Holes ⑥Pole Mounting Holes 2.3 Dimensions(mm) 3. Assembly and Preparation 3.1 Sensor Assembly Follow the steps below to connect light sensor cable to EM500 transceiver if they are separated. - Page 7 EM500-SMT User Guide 2. Pass the cable through the cap, rubber seal 1. Take off the mounting bracket, remove the cap, and enclosure cover. rubber seal and the screws on the bottom of the device, and then take off the enclosure cover. 3.
-
Page 8: Insulating Sheet Disassembly
Check On/Off Status Quickly press the power button. Light Off: Device is off. 5. Sensor Configuration Ursalink EM500-SMT sensor can be monitored and configured via one of the following methods: Mobile APP (NFC); Windows software (NFC or Type-C port). -
Page 9: Configuration Via Smartphone App
EM500-SMT User Guide 5.1 Configuration via Smartphone APP Preparation: Smartphone (NFC supported) Toolbox APP: download and install from Google Play or Apple Store. 5.1.1 Read/Write Configuration via NFC 1. Enable NFC on the smartphone and open “Toolbox” APP. 2. -
Page 10: Template Configuration
EM500-SMT User Guide 5.1.2 Template Configuration Template settings are used for easy and quick device configuration in bulk. Note: Template function is allowed only for sensors with the same model and LoRa frequency band. 1. Go to “Template” page on the APP and save current settings as a template. 2. -
Page 11: Configuration Via Pc
4. Enter password of this device and keep the two devices close until the APP shows a successful prompt. 5. Slide the template item to the left to edit or delete the template. 5.2 Configuration via PC Preparation: Dedicated NFC Reader or Type-C USB cable PC (Windows 10) Toolbox: https://www.ursalink.com/en/software-download/ ... -
Page 12: Log In The Toolbox
EM500-SMT User Guide 5.2.1 Log in the Toolbox Make sure “Toolbox” is downloaded on your computer. Select one of the following methods to log in Toolbox. Type-C Connection 1. Connect the EM500-SMT to computer via type-C port. Type-C port is inside the transceiver of the EM500-SMT. 2. -
Page 13: Basic Configuration
EM500-SMT User Guide 5.2.2 Basic Configuration 1. Click “Read” to read current data of the sensor. 2. When you perform one of the following operations, enter the password and wait a few seconds until toolbox shows a successful prompt. (Password is not needed if you connect it via type-C port) Turn on/off the sensor ... -
Page 14: Template And Reset
EM500-SMT User Guide 5.2.3 Template and Reset 5.2.3.1 Template Configuration Note: Template function is allowed only for sensors with the same model and LoRa frequency band. 1. Go to “Maintenance -> Template and Reset” page in Toolbox. 2. Click “Export” to save the current settings as a template. 3. -
Page 15: Configuration Examples
EM500-SMT User Guide 5.3 Configuration Examples 5.3.1 LoRaWAN Channel Settings The configuration of LoRaWAN channel of EM500-SMT must match the LoRaWAN gateway’s. Refer to Appendix to check default channel settings of EM500-SMT. Mobile APP Configuration: Open Toolbox APP and go to “Device ->Setting -> LoRaWAN Settings”to change the frequency and channels. -
Page 16: Data Calibration Settings
EM500-SMT User Guide 5.3.2 Data Calibration Settings Mobile APP Configuration: Open Toolbox APP and go to “Device -> Setting -> Calibration Settings”to enable the calibration and input the calibration value. Software Configuration: Log in Toolbox and go to “Device Settings -> Basic -> Calibration Settings” to enable the calibration and type the calibration value. -
Page 17: Installation
EM500-SMT User Guide Software Configuration: Log in Toolbox and go to “Device Settings -> Basic -> Threshold Settings” to enable the calibration and input the calibration value. Installation 6.1 Transceiver Installation 6.1.1 Wall Mounting 1. Attach the mounting bracket to the wall and mark the two holes(around 16mm) on the wall. Note: The connecting line of two holes must be a horizontal line. -
Page 18: Pole Mounting
EM500-SMT User Guide 6.1.2 Pole Mounting 1.Loosen the hose clamp by turning the locking mechanism counter-clockwise. 1. Straighten out the hose clamp and slide it through the rectangular holes in the mounting bracket, wrap the hose clamp around the pole. 2. -
Page 19: Horizontal Installation
EM500-SMT User Guide When installing the sensor in a lightning prone area, please check your lightning protection. When removing the sensor from the soil, do not pull it out of the soil by the cable. Doing so may break internal connections and make the sensor unusable. 6.2.1 Horizontal Installation 1. -
Page 20: Payload Format
°C Hum=281*0.1=28.1 73 => 115 68 (Moisture) Moisture=115*0.5=57.5 7F(Electrical Conductivity) F0 00 => 00 F0 =240 µs/cm 01(Ursalink Protocol 01=> V1.0 Version) 09 (Hardware Version) 01 40=> V1.4 0a(Software Version) 01 14=> V1.14 0b(Power on Notification) 0c (Power off Notification) 0f(Device Type) 00 =>... -
Page 21: Sensor Management Via Ursalink Cloud
8.1 Ursalink Cloud Registration Register and log in Ursalink Cloud. Ursalink Cloud URL: https://cloud.ursalink.com/login.html 8.2 Add a Ursalink LoRaWAN Gateway 1. Enable “Ursalink” type network server and “Ursalink Cloud” mode in gateway web GUI. Note: Ensure gateway has accessed the Internet. - Page 22 EM500-SMT User Guide 2.Go to “My Devices->Gateway” of Ursalink Cloud and click “Add” to add gateway to Ursalink Cloud via SN. 3.Check if gateway is online in Ursalink Cloud.
-
Page 23: Add Em500-Smt To Cloud
8.3 Add EM500-SMT to Cloud 1. Go to “Device->My Devices” and click “Add Device”. Fill in the SN of EM500-SMT and select associated gateway. 2.After EM500-SMT is connected to Ursalink Cloud, Click or “History Data” to check the data on Ursalink cloud. -
Page 24: Appendix
EM500-SMT User Guide Appendix Default LoRaWAN Parameters 24E124 + 2 to 11 digits of SN DevEUI e.g. SN = 61 26 A1 01 84 96 00 41 Then Device EUI = 24E124126A101849 AppEUI 24E124C0002A0001 Appport 0x55 NetID 0x010203 The 5 to 12 digits of SN DevAddr...
