Ursalink AM100 Series LoRaWAN Sensor Configuration Guide
Hi there. In this video, I will show you how to configure Ursalink LoRaWAN
sensor.
1. Preparing Sensor
Unbox the sensor; Remove the battery cover and install two AA 1.5V batteries.
When the sensor is off，it displays device EUI and QR Code.
Press the power button on the back panel for 3s to 10s to turn it on. The
screen will flash,then start to work.
2. Sensor Configuration
There are two methods to configure the sensor.
Method 1: configuration via USB
Use Type-C cable to connect the sensor to a PC; Open toolbox of version V6.8
or above.
Select corresponding series port; log in with default user name and password.
Click POWER ON to turn on the sensor, then click READ to catch the sensor
info.
Then open LORAWAN SETTINS.
On BASIC tab, you can: view Device EUI and APP EUI; choose join type;
change APP key; turn on or off ADR.
On CHANNEL Tab, you can change frequency; choose a support frequency.
select a channel, and add the frequencies you need.
Click DEVICE SETTINGS
In the tab, you can set up reporting internal; change login password; calibrate
sensor; and set up threshold alarm.
Open MAINTENANCE
