1.2 Rear-panel Components
Figure 1.2 UPS Rear Panel with Terminal-block Battery Connectors
Item
1
2
3
4
5
6
7
8
9
10
11
12
4
Description
Liebert® IntelliSlot™ port
Dry-contact port
REPO port
RS-232 port
Multi-function port
Parallel/LBS ports
Ventilation holes
AC-output terminals
AC-input terminals
Ventilation holes
Battery-input terminals
USB port
Vertiv | Liebert® ITA2™ Installer/User Guide
