2. System Specifications

Factory Default Settings
Maximum motor run time
Courtesy light time
Obstruction force margin
Auto close time
Technical Specifications
Model
Input Voltage
Current (Max)
Transformer secondary output
Voltage
Motor type
Shuttle travel distance in the C-Rail
Maximum shuttle travel distance in
the C-Rail
Peak Short Term Pulling Force
Maximum door hanging weight
Receiver type
Receiver code storage capacity
Transmitter frequency
Coding type
Number of code combinations
Code generation
Remote control battery
Courtesy light
Control board fuse
NOTE:
Intermittent operations may occur in areas which experience very strong winds. The strong wind puts extra pressure on the
door and tracks which may in turn trigger the safety obstruction detection system intermittently.
Default Step
30 seconds -
3 Minutes approx. -
2 1
30 seconds -
AM800
120Vac / 60Hz
2.3A
24Vac
24Vdc geared motor with
permanent magnet
9.19ft (2.8m) approximately
(standard)
16.4ft (5m) (with extended C-Rail)
800N
386lbs (175kg)
UHF Multifrequency FM-Receiver
14 X 4 button transmitter codes
433.47MHz; 433.92MHz;
434.37MHz
TrioCode128™
Over 4.29 billion random codes
Nonlinear encryption algorithm
CR2032 3 Volts
2 LED Modules
10A (slow blow)
Maximum
-
-
14
-
AM808
120Vac / 60Hz
2.5A
24Vac
24Vdc geared motor with
permanent magnet
9.19ft (2.8m) approximately
(standard)
16.4ft (5m) (with extended C-Rail)
1000N
386lbs (175kg)
UHF Multifrequency FM-Receiver
14 X 4 button transmitter codes
433.47MHz; 433.92MHz;
434.37MHz
TrioCode128™
Over 4.29 billion random codes
Nonlinear encryption algorithm
CR2032 3 Volts
2 LED Modules
10A (slow blow)
Dominator Instruction Manual
© Copyright 2017
AM888
120Vac / 60Hz
3.0A
24Vac
24Vdc geared motor with
permanent magnet
9.19ft (2.8m) approximately
(standard)
16.4ft (5m) (with extended C-Rail)
1000N
441lbs (200kg)
UHF Multifrequency FM-Receiver
14 X 4 button transmitter codes
433.47MHz; 433.92MHz;
434.37MHz
TrioCode128™
Over 4.29 billion random codes
Nonlinear encryption algorithm
CR2032 3 Volts
2 LED Modules
10A (slow blow)
AM800, AM808 & AM888
