4 Components for DC IP 650-...

Interfaces, power supply

12
SIVS 610-0
System interface video server for
connection of the In-Home bus:
Video to IP video server. The
SII 650-... is required for connection.
Dimensions 144 x 130 x 55 mm
SII 650-0
The system interface In-Home
converts the signals from the In-
Home bus: Video for the SIVS 650-...
Dimensions 107 x 89 x 60 mm
VNG 602-...
Video line rectifier in a 10-grid
housing.
Primary: 230 V AC, 50/60 Hz
Secondary: 30 V DC, 1.1 A
stabilized.
For supply to the SIVS 610-... and
the connected interfaces.
BVNG 650-0
Bus video line rectifier in a 9-grid
housing.
Primary: 230 V AC, 50/60 Hz,
Door release contact 15 V AC,
30 V DC, 2 A, switching time fixed
at 3 seconds. Light contact 15 V AC,
30 V DC, 2 A, switching time
0.4 seconds, capable of being
changed with bus programming
software BPS 650-...
