Explo X2 Wave Flamer Manual page 25

4.3.1.3 Channel 3: Ignition (Starting adress +2)
The third channel (starting adress +2) activates the actual ignition. If the DMX value on this channel is
higher than 253, the projector will ignite. The DMX-value of this channel must fall below 254, before
an ignition can be made again with the values 254 and 255.
DMX-value
Ignition
4.3.1.4 Channel 4: Opening time (starting adress +3)
The fourth channel (starting adress +3) indicates how long the opening time should be. The opening
time can be selected in steps of 10ms, to 2540ms (2,54s) using the DMX-values from 0 to 254.
The DMX-value 255 allows a permanent ignition. This ignition ends if the value drops below 254, at
the latest after 2,5 seconds.
The following formula can be used to calculate the opening time t [ms]:
DMX-value
0
Opening time
0ms
4.3.1.5 Channel 5: Program (Starting adress +4)
The fifth channel (starting adress +4) allows you to ignite one of the predefined sequences. Three
DMX-values can be used for one of the ignition channels from the sequence list (see 4.2.1). The
values 0 to 2 are unused, the first sequence (Ignition channel 1) starts with the DMX values 3 to 5.
The following formula can be used:
DMX value = 2 + Channelnumber• (255/100)
The following formula can be used for the % value:
% value = Channelnumber
DMX-value
0 to 2
% value
0
Ign. channel
N/A
0 to 253
Device won't ignite
DMX value = t / 10
1 2
10ms 20ms
Program / Ignition channel
3 to 5 6 to 7
1 2
1 2
Ignition
254 and 255
Device ignites
Opening time
3
...
30ms
8 to 10 11 to 12
3 4
3 4
254 255
2540ms permanent
179 to 181
... 70
70
