Explo X2 Wave Flamer Manual page 24

4.3.1.2 Channel 2: Speed (Starting adress +1)
The second channel (starting adress +1) defines the speed of the device. It can be set anywhere from
DMX value 0 to 255. (standing still to full speed).
The speed is in raltion to time, and not power. This leads to a better synchronisation of the Flamers.
This setting is not affected by "Fading", since a synchronisation can only be measured from a distance
of about 8-9 DMX values (Channel1).
Example of a constant Wave
1. Drive to starting point(CH1 Angle = 0, CH2 Speed = 255, Ch3 Ignition = 0)
2. Once the starting point has been reached, set CH2, speed (Ch1 Angle = 0, CH2 Speed = 50,
Ch3 Ignition = 0)
3. Set end point and ignition (CH1 Angle = 255, CH2 Speed = 50, Ch3 Ignition = 255)
4. The device will now make a constant move to the end point and ignites.
If the Flamer should fade, you must set a DMX-value of 255.
DMX-value
Speed
24
0
stop Incremental of speed
Speed
1 to 254 255
Max. Speed
