RANGER 900 XP REAR
BRUSHGUARD KIT
P/N 2878840
Application
RANGER 900 XP
Before you begin, read these instructions twice and check to be sure all parts and tools are accounted for. Please
retain these installation instructions for future reference and parts ordering information.
3
Kit Contents
:
Ref
Qty
1
1
2
1
3
1
4*
4
5*
10
6*
2
1
Items marked (*) are included in Hardware Kit PN 2204789.
Tools Required:
Metric Socket Set
APPROXIMATE ASSEMBLY TIME: 10-15 minutes
IMPORTANT: Your Polaris RANGER 900 XP REAR BRUSHGUARD is exclusively designed for your
vehicle. Please read the installation instructions thoroughly before beginning. Installation is easier
if the vehicle is clean and free of debris. For your safety and to ensure a satisfactory installation,
perform all installation steps correctly and in the sequence shown.
4
5
Part Description
Rear Brushguard
Rear Weld Mount, LH, Brushguard, TTN
Rear Weld Mount, RH, Brushguard, TTN
Carriage Bolt-M8x1.25x20 mm
Nut-M8x1.25 mm, Hex Flange, Nyloc
Carriage Bolt-M8x1.25x85 mm
Instructions
1
2
6
Part Number
1018892
1018890
1018891
7518479
7547317
9924734
-1-
-
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Polaris 2878840
Summary of Contents for Polaris 2878840
- Page 1 Metric Socket Set APPROXIMATE ASSEMBLY TIME: 10-15 minutes IMPORTANT: Your Polaris RANGER 900 XP REAR BRUSHGUARD is exclusively designed for your vehicle. Please read the installation instructions thoroughly before beginning. Installation is easier if the vehicle is clean and free of debris. For your safety and to ensure a satisfactory installation,...
- Page 2 INSTALLATION INSTRUCTIONS: 1. Place the vehicle in “PARK” and turn the key to “OFF” position. Remove the key from the vehicle. 2. Unlatch the tailgate and disconnect the retaining cables. Remove the tailgate by opening the tailgate so that it is about 2” from the closed and latched position, then lifting up on the left (driver’s) side of the tailgate to disconnect it from the pivot.
