HEADACHE RACK KIT
P/N 2879976, 2881531
APPLICATION
Verify accessory fitment at Polaris.com.
BEFORE YOU BEGIN
Read these instructions and check to be sure all parts and tools are accounted for. Please retain these
Installation Instructions for future reference and parts ordering information.
KIT CONTENTS
This Kit includes:
Kit PN 2881531 shown; Kit PN 2879976 similar except as noted below.
REF
QTY
PART DESCRIPTION
1
1
Headache Rack Assembly (includes items 1.1–1.10)
1.1
1
- Headache Rack, Moveable
1.2
2
- Retainer Spacer - 25 mm
1.3
2
- Washer, Spring - M6
1.4
2
- Screw, Torx
1.5*
2
- Strap
1.6
4
- Bumper
1.7*
2
- Washer - 12.5 X 20 X 2
1.8*
2
- Screw, Shoulder - M10 X 1.5
1.9
1
- Headache Rack, Fixed
1.10
2
- Bushing
2
4
Expansion Anchor Kit, Lock & Ride
®
- M6 X 1.0 X 15
®
Instr 9926584
Rev 03 2018-05
NOTE
Page 1 of 3
PART NUMBER
-
-
-
-
-
-
-
-
-
-
-
2875250
Advertisement
Table of Contents
Related Manuals for Polaris 2879976
Summary of Contents for Polaris 2879976
- Page 1 KIT CONTENTS This Kit includes: NOTE Kit PN 2881531 shown; Kit PN 2879976 similar except as noted below. PART DESCRIPTION PART NUMBER Headache Rack Assembly (includes items 1.1–1.10) - Headache Rack, Moveable...
- Page 2 PART DESCRIPTION PART NUMBER Screw, Shoulder - M8 X 1.25 Washer - 8.4 X 16 X 1.5 Instructions 9926584 Items marked (*) are included in Hardware Kit PN 2206118. TOOLS REQUIRED • Safety Glasses • Socket Set, Hex Bit, Metric •...
- Page 3 5. Assemble and install LOCK & RIDE ® expansion 6. Ensure all expansion anchors are unlocked, anchor to each corner of fixed rack . Observe then install headache rack assembly into bed location of nylon washer and steel washer until anchors are fully seated. Depress levers to lock in place.
