RZR – CAB SYSTEM
KIT PN 2877466
Application:
Before you begin, read these instructions and check to be
sure all parts and tools are accounted for. Please retain
these installation instructions for future reference and parts
ordering information.
Installation Time:
Approximately
Minutes
If you leave the key in the ignition
switch, someone could accidentally
start the engine and seriously injure
you or other bystanders.
Remove the key from the ignition
switch before you do any
maintenance.
Carton Contents:
Rear Panel + Expanding Plugs (2)
Roof + Mudguard Kit
Left Door
Right Door + Hinge Kit + Hardware Kit
Kit Components:
QTY. Part Description
1
Hinge Base Block, (Left)
1
Hinge Base Block (Right)
2
7" D-Foam Strips
1
Latch Bracket (Left)
1
Latch Bracket (Right)
2
2" Foam Pads
2
Clamp (1")
2
Clamp (.75")
2
Spring Pin & Tether
4
Socket Hd Screw
4
Nylock Nut
4
2" Truss Hd Torx Screw (For pin latch
adjustment only)
4
.75" Truss Hd Torx Screw
4
Flat Washer
2
Lock & Ride expanding anchor kit
(Included in Rear Panel Kit)
Form #99552990
Rev Date 07.29.08
Polaris Ranger RZR
60
1
The Way Out
Printed in the USA.
