General

3 General
3.1

Authorized use

•
The machine is only designed for the use specified in this documentation.
•
Every other use is not authorized and is forbidden!
•
All relevant safety regulations, especially regulations of the declaration of conformity, and additional
local health and safety regulations have to be observed.
Prior to every operation the user must ensure that:
•
the machine is suited to the intended operation, the functioning and the working condition of the
equipment is examined and the loads are suitable to be handled.
Any doubts about instructions should be raised with the manufacturer prior to use.
•
The installation machine VM-301-PAVERMAX in connection with the hydraulic installation clamp HVZ/HVZ-UNI is used
for laying interlocking paving stones in connection with the kerb stone laying clamp VZ-H-UNI (for laying kerb stones),
in combination with the EB 240 sweeping broom for efficient sweeping of sand when laying interlocking paving stones
or in combination with the hydraulic vacuum laying unit HVE for laying or picking up large-format concrete or natural
stone elements.
•
Only attachment equipment from Probst may be attached to the installation machine VM-301-PAVERMAX, such as:
- VZ-H-UNI, HVZ-STANDARD, HVZ-UNI, HVZ-UNI-II, HVZ-LIGHT,
- and by retrofitting the hydraulic vacuum unit (HVE) also various vacuum attachments such as:
- PJ-1650-H, VPM-2500-H, SH-1000-MINI-H, SH-1000-SUPER-JET-H).
When using third-party attachment equipment on the Probst installation machine, the relevant safety
regulations and the technically necessary prerequisites (performance data) of the respective attachment
must be observed. In addition, all technical requirements of the Probst installation machine must
correspond to those of the third-party attachment equipment. The responsibility for this lies solely with
the operator of the installation machine!
•
The installation machine is no lifting equipment!
All instructions in the instructions handed over with the installation machine must be observed.
Danger to life!
Due to the diesel engine, the unit must not be used in closed rooms, explosion or fire danger areas.
For use in tunnels and multi-storey car parks, suitable ventilation must be provided. Otherwise there is a risk
of poisoning by exhaust gases!
It may be necessary to retrofit a diesel particle filter. The locally applicable exhaust gas regulations must
always be observed.
It is not allowed to use the installation machine in public traffic – only construction sites or private
ground!
