Emulex Fibre Channel Host Bus Adapters Installation Guide
2.5 Viewing the LEDs
You can view the green and yellow LEDs through openings in a stand-up HBA's mounting bracket. The yellow LED indicates
port activity or link speed, and the green LED indicates firmware operation. Each port has a corresponding set of yellow and
green LEDs.
Figure 10: Optical HBA LED Indicators
The following table summarizes POST conditions and results:
NOTE:
For the link rate conditions, a 1s pause occurs when the yellow LED is off between each group of fast blinks (2, 3,
4, or 5, depending on the HBA). Observe the LED sequence for several seconds to be sure you have correctly
identified the pattern.
Table 1: POST Conditions and Results
Yellow LED
Off
On
Slow blink
Flashing
Off
On
1 fast blink
2 fast blinks
3 fast blinks
4 fast blinks (LPe12002-M8
HBAs only)
4 fast blinks
5 fast blinks
Off
Fast blink
Broadcom
Green LED
Off
Off
Off
Off
On
On
On
On
On
On
On
Slow blink
Fast blink
No SFP module installed or a boot failure occurred (dead board)
POST failure (dead board)
Boot failure after POST
POST processing in progress
Failure in the common code module
Failure in the common code module
Normal (link up at 2GFC) (legacy compatibility only)
Normal (link up at 4GFC)
Normal (link up at 8GFC)
Normal (link up at 16GFC)
Normal (link up at 32GFC)
Normal (link down)
Beaconing
State
LPe-HBA-IG124-100-2CS
10
