Summary of Contents for Targa LT 4010
-
Page 3: Table Of Contents
LT 4010 Content Content Unpacking and Setup ................1 Scope of Supply ............1 Safety . - Page 4 Content LT 4010 Switching Off ............21 Stand-by .
- Page 5 LT 4010 Content Set On-Screen Display ..........40 Set Duration .
- Page 6 Content LT 4010 Cleaning and Troubleshooting ............51 Cleaning ............. 51 Troubleshooting .
-
Page 7: Unpacking And Setup
LT 4010 Unpacking and Setup Unpacking and Setup Scope of Supply Please check, that the delivery is complete. Unit Remote control Batteries Mains cable AV cable (red, white, yellow) Component cable (green, blue , red) SCART cable HDMI cable Stereo audio Adapter cable (red, white) -
Page 8: Safety
Unpacking and Setup LT 4010 Safety General • Read the following instructions carefully. • Keep the manual with the instructions carefully and pass it on, if you sell the unit or give it away otherwise. • Observe all warnings exactly and proceed exactly as described in the instructions. -
Page 9: Location
LT 4010 Unpacking and Setup Location • Avoid humid and/or dusty environments. • Place the unit on level, non-vibrating surfaces. • Do not place the unit close to the outlets of air conditioners or heaters. • Make sure the unit is easily accessible from all sides. -
Page 10: The Best Distance
Unpacking and Setup LT 4010 • Remove the batteries, if you will not use the unit for a longer period. This symbol indicates additional safety instructions in the text. This symbol indicates instructions to facilitate the operation. The Best Distance The distance when watching programs on a television of this size should be approximately 2.2 to 2.7 metres. -
Page 11: The Best Alignment
LT 4010 Unpacking and Setup The Best Alignment Choose a location that allows you to sit in a relaxed position. Otherwise, tension and further impairments to your health may be the consequence. Intended purpose This LCD television set is a unit for consumer electronics. It may only be used for private, not industrial or other commercial purposes. - Page 12 Unpacking and Setup LT 4010...
-
Page 13: Connections And Start Of Operation
LT 4010 Connections and Start of Operation Connections and Start of Operation Overview Controls Front Loudspeaker Sensor for remote control On/Off indicator Select source Select menu Volume Select channel Stand-by switch ON/OFF... -
Page 14: Rear
Connections and Start of Operation LT 4010 Rear 12 13 17 18 19 Input audio (left/right) VIDEO input S-VIDEO input Headphone output Loudspeaker right (4 Ohm/10 Watt) Analogue RGB input (PC) Audio input (PC) HDMI 1 (DVI) input HDMI 2 input... -
Page 15: Access To The Connections
LT 4010 Connections and Start of Operation Access to the Connections The connectors are on the rear of the unit. The unit is equipped with different inputs to allow the best possible signal transmission from the respective source. If your signal source (e.g. DVD-unit, satellite receiver etc.) is equipped with a digital output, you should uses this output... -
Page 16: Connecting To Scart
Connections and Start of Operation LT 4010 Plug the S-Video cable into the socket [S-VIDEO] and the output socket of the external device. Plug the audio cable into the socket [AUDIO R/L] and connect them with the output sockets of the external device. -
Page 17: Connecting To Component Video
LT 4010 Connections and Start of Operation If your external device provides RGB, S-Video and Video (CVBS), use the SCART 1 socket. If your external device provides only S-Video and Video (CVBS), use the SCART 2 socket. You can use both sockets parallel. -
Page 18: Connecting To Hdmi
Connections and Start of Operation LT 4010 Connecting to HDMI HDMI (High Definition Multimedia Interface) is an input for digital image and sound signals. This input also transmits the multi-channel sound for 5.1 audio systems to the digital audio output. -
Page 19: Connecting To Audio Output
LT 4010 Connections and Start of Operation Connecting to Audio Output Use this output to transmit analogue sound signals. Use this output to connect a home theatre system, wireless headphones or a suitable AV receiver/Stereo amplifier. Plug the audio cable into the socket [SOUND LINE OUT L/R] and the input socket of the external device. -
Page 20: Connecting To The Optical/Coaxial Digital Output
Connections and Start of Operation LT 4010 Connecting to the Optical/Coaxial Digital Output Use these outputs to transmit digital sound signals. Use these outputs to connect a suitable home theatre system or a suitable AV receiver/Stereo amplifier. Plug the optical cable (not included in the delivery) into the socket [OPTICAL] and into the input socket of the external device. -
Page 21: Use Of A Headphone With Cable
LT 4010 Connections and Start of Operation Use of a Headphone with Cable The output for the headphone is on the right side of the unit. If you connect a headphone to this output, the sound of the loudspeakers will be switched off. -
Page 22: Connection To Roof Aerial
Connections and Start of Operation LT 4010 Connection to Roof Aerial Ensure that the roof aerial is properly installed and grounded. If the roof aerial is not grounded properly, the unit may be damaged and can be charged with electro static charges. -
Page 23: Connecting Several Devices
LT 4010 Connections and Start of Operation Plug the cable (VGA or HDMI) into the output socket of the graphic board. Plug the other end of the cable into the corresponding socket ([RGB], [HDMI 1] or [HDMI 2]) on the television set. -
Page 24: Inserting The Batteries
Connections and Start of Operation LT 4010 Plug the other end of the power cable into a grounded wall outlet. Inserting the Batteries Two Type R 03 1.5 V Size AAA batteries are included in the delivery to operate the remote control. - Page 25 LT 4010 Connections and Start of Operation Disposal of batteries is clearly regulated by legal acts. Consumer quantities of batteries must be taken back by the dealer or by local public collectors. Never discharge batteries together with common waste. Make use of the free public collection system! Protect your...
- Page 26 Connections and Start of Operation LT 4010...
-
Page 27: Settings
LT 4010 Settings Settings Switching On Press the mains switch on the back of the unit. This switches the unit on and it can be operated using the remote control. Press [ ] on the remote control. If it is not explicitly stated otherwise, it will be assumed that the unit and the TV set are switched on and will be operated by the remote control. -
Page 28: Setting Up For Operation
Settings LT 4010 Setting up for Operation You can adjust various settings of the unit to adapt it to your requirements. Open, Select and Close Menus The settings of the unit are accessible via menus. To navigate in the menus... - Page 29 LT 4010 Settings Press [ ]. To return to the main menu, press [ ] several times. Press [ ] or [ ] and select INSTALLATION. Press [ ] or [ ] and select AUTO TUNING. Press [ Select the country where you want to operate the unit.
-
Page 30: Change Channel
Settings LT 4010 Change channel Use this function to set the channel for individual stations. Press [ ]. To return to the main menu, press [ ] several times. Press [ ] or [ ] and select INSTALLATION. Press [... -
Page 31: Set System
LT 4010 Settings Auto, PAL, SECAM, NTSC The automatic tuning function sets the unit automatically to the received signal. This is why the menu item AUTO cannot be selected. Set System Use this function to set the sound signal to your national television standard. -
Page 32: Manual Tuning
Settings LT 4010 Manual Tuning Use this function to tune the channels manually. Press [ ]. To return to the main menu, press [ ] several times. Press [ ] or [ ] and select INSTALLATION. Press [ ] or [ ], and select PROGRAMME. -
Page 33: Change Channel Name
LT 4010 Settings Change Channel Name The names of the channels are programmed into the receiver. You can change these names manually. Press [ ]. To return to the main menu, press [ ] several times. Press [ ] or [ ] and select INSTALLATION. -
Page 34: Improve Signal Quality
Settings LT 4010 Press [ ] to save the settings. This setting is only available if the tuner is receiving a signal from the roof aerial or the cable. If you have connected an external device, set the language on this device. -
Page 35: Set Channel
LT 4010 Settings Set Channel Use this function to set the settings for individual channels. Press [ ]. To return to the main menu, press [ ] several times. Press [ ] or [ ] and select INSTALLATION. Press [... -
Page 36: Channel Groups
Settings LT 4010 Channel Groups Use this function to store channels in the list of favourites with access by [ ]. Press [ ]. To return to the main menu, press [ ] several times. Press [ ] or [ ] and select SETUP. -
Page 37: Set Screen Language
LT 4010 Settings Set Screen Language By default, the unit is set to the language of your country. The screen display text can be displayed in several languages. Press [ ]. To return to the main menu, press [ ] several times. -
Page 38: Display If No Wide Screen Signal Is Received
Settings LT 4010 Zoom1: The format 16:09 is vertically spread. Zoom2: Like zoom1 but the whole picture is moved upwards so that text at the bottom of the display becomes visible. Panorama: The format 16:09 is displayed as broadcast. The format 4:3 is horizontally spread. -
Page 39: Set Picture Mode
LT 4010 Settings Set Picture Mode Use this function to adapt the picture optimally to the content.Use this function to adapt the picture optimally to the content. You can also adapt the sound modes for these settings. See “Adjust Individual Audio Frequencies” on page 35. -
Page 40: Additional Picture Settings
Settings LT 4010 Additional Picture Settings Use this functions to adjust the picture settings individually, if you have selected the picture mode Custom. Press [ ]. To return to the main menu, press [ ] several times. Press [ ] or [ ], and select PICTURE. -
Page 41: Sound Settings
LT 4010 Settings Red/Blue/Green Sound Settings Set Balance Press [ ]. To return to the main menu, press [ ] several times. Press [ ] or [ ] and select AUDIO. Press [ ] or [ ] and select BALANCE. -
Page 42: Surround Sound By Srs Wow
Settings LT 4010 Press [ ]. To return to the main menu, press [ ] several times. Press [ ] or [ ] and select AUDIO. Press [ ] or [ ] and select EQUALIZER. Press [ Press [ ] or [ ] to select the desired frequency. -
Page 43: Set Sound Source
LT 4010 Settings Set Sound Source Use this function to set which sound you will hear when watching picture-in- picture mode. Press [ ]. To return to the main menu, press [ ] several times. Press [ ] or [ ] and select AUDIO. -
Page 44: Set Time
Settings LT 4010 HDMI: You hear the sound of the HDMI input. You hear the sound of the AUDIO PC input. Set Time In order to set the correct times for switching on and off automatically, the clock in the receiver must be set correctly. By default, the unit receives the current time from the selected station. -
Page 45: Set Switch On Time
LT 4010 Settings Set Switch on Time Use this function to set a time when the unit turns on. Press [ ]. To return to the main menu, press [ ] several times. Press [ ] or [ ] and select TIMER. -
Page 46: Automatic Switch Off
Settings LT 4010 Automatic Switch off Automatic Switch off if no Signal is Received This function switches the unit automatically off, if no signal is received. (E.g. when a video tape was played completely and the video recorder turns off). -
Page 47: Set Transparency
LT 4010 Settings Press [ ]. To return to the main menu, press [ ] several times. Press [ ] or [ ] and select OPTION. Press [ ] or [ ], and select OSD SETTING. Press [ Press [... -
Page 48: Child Lock
Settings LT 4010 Child Lock You can lock the keys on the front panel of the unit. Then the operation is only possible by the remote control. In this case keep the remote control out of the reach of children. -
Page 49: Set Characters For Teletext
LT 4010 Settings Set Characters for Teletext Use this function to set the character set for teletext to your region. Press [ ]. To return to the main menu, press [ ] several times. Press [ ] or [ ] and select OPTION. -
Page 50: Settings For The Computer
Settings LT 4010 Settings for the Computer If you are using the unit as a monitor for your computer make the relevant settings according to the settings of the TV. If the signal of the graphic board corresponds to the standard setting the image is adjusted automatically. -
Page 51: Watching
LT 4010 Watching Watching Watch Television Program When you turn the unit on, the current television program will be displayed automatically. If you have connected an external device via SCART-cable and the external device is switched on the picture and sound of that device will be displayed. -
Page 52: Show Channel Information
Watching LT 4010 Show Channel Information Use this function to display the current station name and the channel. Press [ ]. Press [ ] again to hide the information. Recall a Favourite Channel Use this function to scroll through the channels or sources you have stored as your favourite stations. -
Page 53: Watch Two Programs At The Same Time (Pip )
LT 4010 Watching Watch Two Programs at the Same Time (PIP ) Use this function to display a second picture. This way you can watch two programs you are receiving by antenna or by the other inputs at the same time. -
Page 54: Set Picture-In-Picture Size
Watching LT 4010 This function is only available if you have selected a signal source for the main screen and the sub screen. Set Picture-in-Picture Size Use this function to set the size of the small picture. Press [ Press [... -
Page 55: Still Picture
LT 4010 Watching Increases/decreases the display. Press the key several times to scroll thorough the different sizes. Shows teletext on a transparent background. Shows the index page of teletext. Still Picture Use this function to hold the picture. Press [ During the display of the still picture the sound will continue to play. -
Page 56: Set Surround Sound While Watching
Watching LT 4010 For further information on the settings refer to: “Set Aspect Ratio” on page 31. Set Surround Sound while Watching Use this function to set the sound effects. Press [ Press [ ] again to switch the sound effect off. -
Page 57: Cleaning And Troubleshooting
LT 4010 Cleaning and Troubleshooting Cleaning and Troubleshooting Cleaning Use a dry cloth to clean the unit. Never use water, cleaning detergents or spray cleaners. Troubleshooting If there are problems with the receiver, please check the points below first, before contacting the service centre. -
Page 58: Picture Ok But No Sound
Cleaning and Troubleshooting LT 4010 Picture OK but no Sound Check whether the sound is set to mute or if it is turned down. See chapter “Set volume” on page 45. Check if the sound is ok on another channel. If this is the case, the program is broadcast improperly. -
Page 59: Remote Control Does Not Work
LT 4010 Cleaning and Troubleshooting Remote Control Does Not Work Make sure the unit is connected to the power supply and switched on. Check whether the batteries are inserted correctly and whether they are sufficiently charged. To do this, insert new batteries for testing. -
Page 60: Horizontal Or Vertical Bars
Adjust the settings of the computer. See chapter “Settings for the Computer” on page 44. Other Errors If the error cannot be solved, please contact your dealer or TARGA GmbH, Lange Wende 41, 59494 Soest, Germany; www.targa.co.uk. For the phone number of the competent hotline, refer to the warranty card. -
Page 61: Technical Specifications
LT 4010 Technical specifications Technical specifications General Input voltage AC 220-240 V~, 50/60 Hz Power consumption ON-Status max. 267 Watt Power consumption Stand-by < 3 Watt Dimensions 987 x 702 x 250 mm (W x H x D) incl. stand... -
Page 62: Component
Technical specifications LT 4010 Component Y/Pb/Pr, Component 1&2 480i/p 60 Hz, 576i/p 50 Hz, 720p 50Hz, 720p 60Hz, 1080i 50Hz, 1080i 60Hz SCART Socket 1 Full SCART (RGB, S-Video, CVBS) Socket 2 Half SCART (S-Video, CVBS) Synchronisation 30~61 kHz horizontal... -
Page 63: Glossary
LT 4010 Glossary Glossary DVI - Digital Visual Interface DVI is an interface to transmit analogous and digital video and graphic signals. For computers this type of interface has prevailed for flat screens. DVI is used to connect high quality graphic board to high resolution flat screens. The advantage... - Page 64 Glossary LT 4010 as FBAS or CVBS. It is produced by three source signals referred to as Y, U and V (together YUV). Y refers to the brightness of the picture. U and V carry the colour information. RGB colour space RGB refers to the method by which the individual colours are calculated for display on the screen.
- Page 65 LT 4010 Glossary DVB-S (DVB - Satellite) This is the satellite version of the DVB family of standards.This is the terrestrial version of the DVB family of standards.
- Page 66 Glossary LT 4010...
-
Page 67: Conformity
LT 4010 Conformity Conformity This product fulfils the EC guidelines 89/336/EEC (EMC guideline) with amendments 93/68 EEC and 92/31 EEC and the EC guideline 73/23/EEC (low voltage guideline) with amendments 93/68/EEC. Disposal This product is subject to the European guideline 2002/96/EC. - Page 68 Conformity LT 4010...
-
Page 69: Index
LT 4010 Index Index Brightness Change channel Colour Contrast Delete channel Equalizer Foreign language Key lock... - Page 70 Index LT 4010 Lock channel Move channel Picture format 16:9 31 Picture format 4:3 31 Power consumption RGB colour space Set volume 26, 34 Sharpness Skip channel 24, 29 Sort channel Sound effect 28, 29 Stereo Surround sound TV standard...
- Page 71 LT 4010 Index 30, 45 Watch favourites...
- Page 72 Index LT 4010...
