Technical data - EK3100

Technical data
Bus interface
Protocol
Data transfer rates
Interfaces
Web interface
Power supply
Power contacts
Electrical isolation
Max. power loss
I/O connection
Power supply for I/O terminals
I/O terminals
Number of EtherCAT devices
Dimensions (W x H x L)
Operating/storage temperature
horizontal mounting position
Operating/storage temperature
other mounting position
Relative humidity
Vibration/shock resistance
EMC immunity/emission
Protect. class / installation pos. IP 20/variable
Approvals
10
EK3100
1 x D-sub socket, 9-pin with shielding
PROFIBUS DP
up to max. 12 Mbaud (automatic recognition)
1 x USB (behind the front flap)
yes
24 V DC (-15 %/+20 %)
24 V DC max./10 A max.
500 V (power contact/supply voltage)
3 W
E-bus (EtherCAT Terminals)
max. 2 A
E-bus (EL, ES, EP), standard digital signals, standard analog signals. All
compatible EtherCAT devices are listed in the GSD file.
No gateway EC terminals, no EC terminals with XFC or DC function.
max. 255
65 mm x 100 mm x 73 mm
-25°C ... +60°C/-40°C ... +85°C
0...+55 °C/-25...+85 °C
95 % no condensation
Conforms to EN 60068-2-6/EN 60068-2-27
Conforms to EN 61000-6-2/EN 61000-6-4
CE,
cULus
ATEX [} 22]
