Itm HOLEMAKER HMSPECIAL 110 Operator's Manual

Portable magnetic drilling machine
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
HOLEMAKER PRO 50
HOLEMAKER PRO 50
Holemaker Portable Magnetic Drilling Machine
OPERATOR'S MANUAL
Holemaker Portable Magnetic Drilling Machine
OPERATOR'S MANUAL
BEFORE USE
BEFORE USE
EYE PROTECTION
REQUIRED
EYE PROTECTION
REQUIRED
S
r e
a i
# l
Ver: 1.10
14/08/2015
S
r e
a i
# l
Ver: 1.10
14/08/2015
WARNING!
,
OPERATOR'S MANUAL
ENSURE EVERYONE USING THIS MACHINE READS AND UNDERSTANDS
WARNING!
ALL SAFETY AND OPERATING INSTRUCTIONS IN THIS MANUAL
,
ENSURE EVERYONE USING THIS MACHINE READS AND UNDERSTANDS
ALL SAFETY AND OPERATING INSTRUCTIONS IN THIS MANUAL
DRILLING MACHINE
WITH ELECTROMAGNETIC BASE
HEARING PROTECTION
NEVER PLACE
REQUIRED
FINGERS NEAR
CUTTING AREA OR
P
MACHINE ARBOR
P
HEARING PROTECTION
NEVER PLACE
REQUIRED
FINGERS NEAR
CUTTING AREA OR
MACHINE ARBOR
ul. Elewatorska 23/1, 15-620 Białystok, Poland
Phone: +48 85 678-34-95, Fax: +48 85 662-78-77
www.promotech.eu
LINE VOLTAGE
PRESENT
R
O
1
1
2
T
R
O
1
1
2
T
LINE VOLTAGE
PRESENT
D
a
e t
f o
P
r u
h c
D
a
e t
f o
P
r u
h c
e-mail:
info@promotech.eu
.
.
BEWARE OF
ROTATING
MACHINE PARTS
BEWARE OF
ROTATING
MACHINE PARTS
a
e s
a
e s

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HOLEMAKER HMSPECIAL 110 and is the answer not in the manual?

Questions and answers

Related Manuals for Itm HOLEMAKER HMSPECIAL 110

Summary of Contents for Itm HOLEMAKER HMSPECIAL 110

  • Page 1 HOLEMAKER PRO 50 HOLEMAKER PRO 50 Holemaker Portable Magnetic Drilling Machine OPERATOR’S MANUAL Holemaker Portable Magnetic Drilling Machine OPERATOR’S MANUAL WARNING! OPERATOR’S MANUAL BEFORE USE ENSURE EVERYONE USING THIS MACHINE READS AND UNDERSTANDS WARNING! ALL SAFETY AND OPERATING INSTRUCTIONS IN THIS MANUAL BEFORE USE ENSURE EVERYONE USING THIS MACHINE READS AND UNDERSTANDS ALL SAFETY AND OPERATING INSTRUCTIONS IN THIS MANUAL...

  • Page 2: Table Of Contents

    Contents 1. GENERAL INFORMATION ....................3 1.1. Application ......................... 3 1.2. Technical data......................3 1.3. Equipment included ....................4 1.4. Dimensions ........................ 5 1.5. Design ........................6 2. SAFETY PRECAUTIONS ....................7 3. STARTUP AND OPERATION ................... 9 3.1. Installing the handles ....................9 3.2.

  • Page 3: General Information

    PRO 112T 1. GENERAL INFORMATION 1.1. Application The HMSPECIAL110 is a drilling machine designed to drill holes with diameters of up to 110 mm by using annular cutters. The machine can also drill holes with diameters of up to 31.75 mm by using twist drill bits. The machine can change the direction of rotation.

  • Page 5: Dimensions

    PRO 112T 1.4. Dimensions 405 mm (16″) 305 mm (12″) This document is protected by copyrights. Copying, using, or distributing without permission of PROMOTECH is prohibited.

  • Page 7: Safety Precautions

    PRO 112T 2. SAFETY PRECAUTIONS 1. Before use, read this Operator’s Manual and complete a training in occupational safety and health. 2. Use only in applications specified in this Operator’s Manual. 3. Make sure that the machine has all parts and they are genuine and not damaged. 4.
  • Page 8 PRO 112T 21. Do not use on surfaces that are rough, not flat, not rigid, or have rust, paint, chips, or dirt. 22. Do not use if the gibs are adjusted incorrectly. 23. Do not use if there is no grease on the gibs. 24.

  • Page 9: Startup And Operation

    PRO 112T 3. STARTUP AND OPERATION 3.1. Installing the handles Attach the handles to the feed shaft. You can install the shaft so that the handles are on the opposite side of the machine. To do this, lift the motor to the maximum and continue in the sequence that follows.

  • Page 13: Installing And Removing The Screw Tap

    PRO 112T 3.4. Installing and removing the screw tap Install the tap chuck as described before. Next, put the screw tap into the correct adapter (1). Install the adapter into the tap chuck (2). To remove the screw tap, unlock it and remove from the adapter. This document is protected by copyrights.

  • Page 15: Preparing

    PRO 112T 3.6. Preparing Before use, clean steel parts, including the MT3 socket, from anti-corrosion material used to preserve the machine for storage and transport. Attach the handles to the feed shaft. You can install the shaft so that the handles are on the opposite side of the machine.

  • Page 22: Replacing The Motor Brushes

    PRO 112T 3.10. Replacing the motor brushes Every 100 work hours, check the condition of the brushes. To do this, unplug the power cord and remove the cover (1). Lift the spring (2) and remove the brush. If the brush is shorter than 5 mm (0.2″), replace the two brushes with new ones. Install in reverse sequence.

  • Page 24: Pipe Attachment Dmp 501

    Parts list PRO 112T v.0.04 ITEM PART NUMBER DESCRIPTION Q-TY UKL-0563-07-00-00-0 COOLANT SYSTEM ASSY DZW-0178-09-00-00-0 SPOKE HANDLE ASSY PAS-000008 SAFETY STRAP 500 KLC-000037 5 MM HEX WRENCH WITH HANDLE KLC-000005 2.5 MM HEX WRENCH KLC-000008 5 MM HEX WRENCH KLC-000003 8 MM COMBINATION WRENCH KLN-0103-00-00-00-0 WEDGE MT3...

  • Page 25: Mt3 Tap Chuck × 19 Mm With Adapter

    ITEM PART NUMBER DESCRIPTION Q-TY UKL-0563-07-00-00-0 COOLANT SYSTEM ASSY DZW-0178-09-00-00-0 SPOKE HANDLE ASSY PAS-000008 SAFETY STRAP 500 KLC-000037 5 MM HEX WRENCH WITH HANDLE KLC-000005 2.5 MM HEX WRENCH KLC-000008 5 MM HEX WRENCH KLC-000003 8 MM COMBINATION WRENCH KLN-0103-00-00-00-0 WEDGE MT3 OPK-000001 TOOL CAN...

  • Page 26: Mt3 Tap Chuck × 31 Mm With Adapter

    Parts list PRO 112T v.0.04 ITEM PART NUMBER DESCRIPTION Q-TY SLN-0563-01-00-00-0 MOTOR - 115V SLN-0563-01-00-00-1 MOTOR - 230V SRB-000114 HEX SOCKET HEAD CAP SCREW M6x20 PDK-000046 SPRING WASHER 6.1 This document is protected by copyrights. Copying, using, or distributing without permission of PROMOTECH is prohibited.
  • Page 27 Parts list PRO 112T v.0.04 ITEM PART NUMBER DESCRIPTION Q-TY PDK-000136 SMALL ROUND WASHER 6.4 WKR-000193 CROSS RECESSED PAN HEAD SCREW M4x8 NKD-0563-06-00-00-0 COOLANT BOOTLE BRACKET WKR-000531 HEX SOCKET ROUND HEAD SCREW WITH FLANGE M5x35 PDK-000151 NYLON WASHER 8.1x14x3 OSL-0563-05-00-00-0 GUARD SPR-000030 PUSH SPRING...

  • Page 28: Mt3 Tap Chuck × 48 Mm With Adapter

    Parts list PRO 112T v.0.04 ITEM PART NUMBER DESCRIPTION Q-TY WKR-000529 TORX PAN HEAD SCREW 4x50 PKR-0563-01-06-00-0 STATOR COVER ASSY PKT-0563-01-06-04-0 POTENTIOMETER KNOB PTN-000039 POTENTIOMETER ASSY OSL-0563-01-06-02-0 BUTTON COVER This document is protected by copyrights. Copying, using, or distributing without permission of PROMOTECH is prohibited.
  • Page 29 Parts list PRO 112T v.0.04 ITEM PART NUMBER DESCRIPTION Q-TY PKR-0563-01-06-01-0 STATOR COVER MDL-0563-80-05-00-0 KEYBOARD MODULE (OB1) TLJ-000151 INSULATION SLEEVE 2.6x3.9 WKR-000458 SCREW FOR PLASTIC 2.2x8 PRS-000238 EXTERNAL RETAINING RING 16z SYG-0563-01-05-01-0 SIGNALLER MDL-0563-80-04-00-0 SIGNALING MODULE (LB1) WKR-000506 SCREW FOR PLASTIC 3x10 ZSP-0563-23-00-00-0 ELECTRONIC CONTROL UNIT ASSY (MB1) - 115V ZSP-0563-23-00-00-1...
  • Page 30 Parts list PRO 112T v.0.04 This document is protected by copyrights. Copying, using, or distributing without permission of PROMOTECH is prohibited.

  • Page 31: Declaration Of Conformity

    Parts list PRO 112T v.0.04 ITEM PART NUMBER DESCRIPTION Q-TY USZ-0563-02-17-00-0 BODY SEAL KLK-000045 DOWEL PIN 5n6x12 PRS-000003 EXTERNAL RETAINING RING 12z KOL-0563-02-03-02-0 GEAR z29 WPS-000082 PARALLEL KEY 4x4x8 WLK-0563-02-02-00-0 CLUTCH SHAFT ASSY LOZ-000161 BALL BEARING 10x26x8 KOL-0563-02-07-00-0 GEAR z32, z32 WPS-0563-02-19-00-1 PARALLEL KEY 6x6x40 WLK-0563-02-06-00-0 PINION SHAFT z12 PDK-0563-02-22-00-0 WASHER 14x22x0.5...
