- Page 1 PRO 35 AUTO OPERATOR’S MANUAL PRO 35 AUTO MAGNETIC BASE DRILLING MACHINE OPERATOR’S MANUAL Part No. HMPRO35AUTO Ver: 2.0 www.itmtools.com.au...
-
Page 2: Table Of Contents
PRO 35 AUTO OPERATOR’S MANUAL LIMITED WARRANTY Industrial Tool & Machinery Sales (hereinafter referred to as ITMS) will, within twelve (12) months from the original date of purchase, repair or replace any goods found to be defective in materials or workmanship. This warranty is void if the item has been damaged by accident, neglect, improper service or other causes not arising out of defects in materials or workmanship. -
Page 3: General Information
PRO 35 AUTO OPERATOR’S MANUAL PRO 36 AUTO 1. GENERAL INFORMATION 1.1. Application The PRO 35 AUTO is a drilling machine designed to drill holes with diameters of up to 35 mm by using annular cutters. The machine can also drill holes with diameters of up to 16 mm by using twist drill bits. -
Page 4: Equipment Included
PRO 35 AUTO OPERATOR’S MANUAL PRO 36 AUTO 1.3. Equipment included Drilling machine 1 unit Metal box 1 unit Safety strap 1 unit 4 mm hex wrench 1 unit – Operator’s Manual 1 unit This document is protected by copyrights. www.itmtools.com.au Copying, using, or distributing without permission of PROMOTECH is prohibited. -
Page 5: Dimensions
PRO 35 AUTO OPERATOR’S MANUAL PRO 36 AUTO 1.4. Dimensions 221 mm (8.7″) 307 mm (12.1″) www.itmtools.com.au This document is protected by copyrights. Copying, using, or distributing without permission of PROMOTECH is prohibited. -
Page 6: Design
PRO 35 AUTO OPERATOR’S MANUAL PRO 36 AUTO 1.5. Design Cooling system bottle Carrying handle Handle Bottle valve lever Chip guard Hole for a safety strap Spindle with arbor Electromagnetic base Signal LED Motor START Electromagnetic base (MAGNET) switch Motor STOP www.itmtools.com.au This document is protected by copyrights. -
Page 7: Safety Precautions
PRO 35 AUTO OPERATOR’S MANUAL PRO 36 AUTO 2. SAFETY PRECAUTIONS 1. Before use, read this Operator’s Manual and complete a training in occupational safety and health. 2. Use only in applications specified in this Operator’s Manual. 3. Make sure that the machine has all parts and they are genuine and not damaged. 4. - Page 8 PRO 35 AUTO OPERATOR’S MANUAL PRO 36 AUTO 20. Do not use on surfaces that are rough, not flat, not rigid, or have rust, paint, chips, or dirt. 21. Use the safety strap to attach the machine to a stable structure. Put the strap through the hole in the machine body.
-
Page 9: Startup And Operation
PRO 35 AUTO OPERATOR’S MANUAL PRO 36 AUTO 3. STARTUP AND OPERATION 3.1. Installing the tools Unplug the power cord. Set the handles to position (1), and turn them to the right (2) to lift the motor. Use gloves to put the correct pilot pin into the annular cutter (3). Use a dry cloth to clean the cutter. -
Page 10: Installing The Cooling System Bottle
PRO 35 AUTO OPERATOR’S MANUAL PRO 36 AUTO 3.2. Installing the cooling system bottle Put the cooling system bottle on the screws (1). Attach the hose to the fitting (2). 3.3. Monitoring system of the clamping force The drilling machine has a system that monitors the clamping force of the electro- magnetic base. -
Page 11: Preparing
PRO 35 AUTO OPERATOR’S MANUAL PRO 36 AUTO 3.4. Preparing Before use, clean steel parts, including the spindle, from anti-corrosion material used to preserve the machine for storage and transport. Select the tool that matches the required hole diameter. Use a dry cloth to clean the spindle and the tool. -
Page 12: Drilling
PRO 35 AUTO OPERATOR’S MANUAL PRO 36 AUTO When you use an annular cutter, install the cooling system and fill it with coolant. Do not use only water as the coolant. But you can mix water and drilling oil. Then, make sure that the cooling system works correctly. - Page 13 PRO 35 AUTO OPERATOR’S MANUAL PRO 36 AUTO To drill in the automatic mode, press the green START button to start the motor. Then, set the handles as shown in the right figure. Then, the drilling machine starts putting the tool into the workpiece. In the automatic mode, do not press the levers. If you press the levers, the machine will work incorrectly.
- Page 14 PRO 35 AUTO OPERATOR’S MANUAL PRO 36 AUTO Flash code Meaning Description Emergency stop. Retract the tool from the workpiece, and press the green START button Spindle motor overload. to start the drilling again. Use coolant. Make sure that the tool is sharp.
-
Page 15: Replacing The Motor Brushes
PRO 35 AUTO OPERATOR’S MANUAL PRO 36 AUTO 3.6. Replacing the motor brushes Every 100 work hours, check the condition of the brushes. To do this, unplug the power cord and remove the cover (1). Next, remove the pressing plate (2), and then remove the brush holder (3) and the brush (4). - Page 16 PRO 35 AUTO OPERATOR’S MANUAL Parts list PRO 36 auto v.0.08 www.itmtools.com.au...
- Page 17 PRO 35 AUTO OPERATOR’S MANUAL Parts list PRO 36 auto v.0.08 ITEM PART NUMBER DESCRIPTION Q-TY ZSP-0672-02-00-00-0 LEVERS ASSY WKR-000091 HEX SOCKET BUTTON HEAD SCREW M4x8 PKR-0672-02-02-00-0 COVER WLK-0502-05-05-00-1 SWITCHING SHAFT KLK-000015 SPRING PIN 4x26 WASP-B10/1050 HEX SOCKET SET SCREW WITH CONE POINT M8x12 SPPRO35A/HANDLE SPOKE HANDLE INCLUDING KNOB (ASSY) KUL-000003...
- Page 18 PRO 35 AUTO OPERATOR’S MANUAL Parts list PRO 36 auto v.0.08 ITEM PART NUMBER DESCRIPTION Q-TY PDK-000046 SPRING WASHER 6.1 RDK-0440-02-00-00-5 GEARBOX ASSEMBLY SRB-000111 HEX SOCKET HEAD CAP SCREW M6x18 SPPRO350212 GEAR RACK SPPRO350207 GUIDE LOZ-000072 BALL BEARING 9x26x8 SPPRO35023 PINION ASSY LOZ-000053 BALL BEARING 8x22x7...
- Page 19 PRO 35 AUTO OPERATOR’S MANUAL Parts list PRO 36 auto v.0.08 ITEM PART NUMBER DESCRIPTION Q-TY NKR-000013 HEX NUT M4 PDK-000016 ROUND WASHER 4.3 PDK-000166 EXTERNAL TOOTH LOCK WASHER 4.3 CROSS RECESSED OVAL COUNTERSUNK HEAD WKR-000113 SCREW M4x16 CROSS RECESSED OVAL COUNTERSUNK HEAD WKR-000183 SCREW M4x10 SPPRO35A009...
- Page 20 PRO 35 AUTO OPERATOR’S MANUAL Cutter Type Features Diameter Available Cut Depth Available Applications Silver Series Metric • M2AL High speed steel • Universal shank • 12 to 65mm Metric • 25mm & 50mm • General purpose • Multi-cut geometry •...
