Installation and
Operation Manual
BISTRO LINE
Stone Hearth Oven
Wood-Fired Models
BISTRO 4343 WS-BL-4343-W
BISTRO 4355 WS-BL-4355-W
WOOD STONE CORPORATION
1801 W. Bakerview Rd.
Bellingham, WA 98226 USA
www.woodstone-corp.com
Toll Free 800.988.8103
Tel 360.650.1111
Fax 360.650.1166
DOC NO M0026.08
REVISED JANUARY 2020
Advertisement
Table of Contents
Related Manuals for Wood Stone BISTRO Series
Summary of Contents for Wood Stone BISTRO Series
- Page 1 Installation and Operation Manual BISTRO LINE Stone Hearth Oven Wood-Fired Models BISTRO 4343 WS-BL-4343-W BISTRO 4355 WS-BL-4355-W WOOD STONE CORPORATION Toll Free 800.988.8103 1801 W. Bakerview Rd. Tel 360.650.1111 Bellingham, WA 98226 USA Fax 360.650.1166 www.woodstone-corp.com DOC NO M0026.08 REVISED JANUARY 2020...
-
Page 2: Table Of Contents
240 VAC Electrical Diagram � � � � � � � � � � 33 Limited Warranty � � � � � � � � � � � � � � � � � � 34 M0026.08 JANUARY 2020 WOOD STONE CORPORATION 800.988.8103 info@woodstone-corp.com... -
Page 3: Bistro Line
BISTRO LINE Wood-Fired Bistro Line Installation and Operation Manual INSTALLATION AND OPERATION MANUAL FOR THE WOOD STONE WOOD-FIRED BISTRO LINE WOOD-FIRED STONE HEARTH COOKING EQUIPMENT COMMERCIAL INTERNAL TRANSITION MODELS WS-BL-4343-W AND WS-BL-4355-W ADDITIONAL COPIES AVAILABLE UPON REQUEST Shown: WS-BL-4343-W M0026.08 JANUARY 2020 WOOD STONE CORPORATION 800.988.8103... -
Page 4: Cautions & Warnings
Wood-Fired Bistro Line Installation and Operation Manual INSTALLATION AND OPERATION MANUAL FOR THE WOOD STONE BISTRO OVEN WOOD-FIRED STONE HEARTH OVEN RETAIN THIS MANUAL FOR FUTURE REFERENCE Additional copies of this manual at woodstone-corp�com� For prompt responses to service/maintenance questions, call us at @ 1-800-988-8103�... - Page 5 Always keep the area under and around this appliance free and clear of any and all combustible materials. SAVE THE INSTRUCTIONS Wood Stone ovens have been tested and approved by Intertek Testing Services and conform to UL 2162 and UL 737;...
-
Page 6: Specifications
DUCTION OR USE IN PART OR AS A WHOLE EQUIRE US TO CHANGE SPECIFICATIONS RE US TO CHANGE SPECIFICATIONS 90mm LEGEND: LEGEND: E WRITTEN PERMISSION OF WOOD STONE IS WITHOUT NOTICE. WITHOUT NOTICE. M0026.08 JANUARY 2020 PROHIBITED WOOD STONE CORPORATION 800.988.8103... - Page 7 IMPORTANT: This model must be vented as a solid fuel appliance� 510mm 1200mm 8" 27 1/4" 200mm 690mm AIR INTAKE 4 1/4" M0026.08 JANUARY 2020 WOOD STONE CORPORATION 800.988.8103 info@woodstone-corp.com E-MAIL TOLL FREE 110mm 1801 W. Bakerview Rd. 360.650.1111 woodstone-corp.com An ongoing program of product improvement may Bellingham, WA 98226 USA 360.650.1166...
-
Page 8: Moving & Placing The Oven
CRANE. fig. 1 The oven arrives with Pickeyes attached� When craning a Wood Stone oven, use a Spreader Bar with a two-legged sling rigged on each end� The spreader bar should be of a sufficient length to keep the sling from contacting the oven, and oriented as shown in fig 1�... -
Page 9: Installation Clearances
CLEARANCES 1. The Wood Stone Bistro oven must have a minimum 1-inch clearance to combustibles from all sides, and 6-inch clearance to combustibles from the top� If building materials will contact the oven, they must be completely non-combustible� Please note that standard Drywall (or Sheetrock) is considered a combustible�... -
Page 10: Venting
300 °F, 450 °F for units burning solid fuel� Use a stack or curb mounted fan� Wood Stone does not recommend the use of an in-line fan�... - Page 11 Wood-Fired Bistro Line Installation and Operation Manual 10" Flue collar Wood Stone ovens should be vented in accordance with NFPA 96 and/or all pertinent national, regional and local codes concerning such appliances; check venting plans with the authority having jurisdiction before proceeding with installation�...
-
Page 12: Flue Adapter Installation
Then fasten with the Underside of Flue Adapter showing supplied screws� where Ceramic Sealing Compound should be applied M0026.08 JANUARY 2020 WOOD STONE CORPORATION 800.988.8103 info@woodstone-corp.com E-MAIL TOLL FREE 1801 W. Bakerview Rd. 360.650.1111 woodstone-corp.com... -
Page 13: Hood Specifications
HOOD SPECIFICATIONS Wood-Fired Bistro Line Installation and Operation Manual BL-4343, 4355 HOOD SPECIFICATIONS Wood Stone Hoods by Gaylord Required CFM - 625 CFM Static Pressure - 0.80" W.C. Duct Collar - 7" x 7" I.D. M0026.08 JANUARY 2020 WOOD STONE CORPORATION 800.988.8103... -
Page 14: Disassembly
If the oven has the optional door assembly installed, remove the door assembly� Washer Bolt Carriage bolt Washer & nut not shown M0026.08 JANUARY 2020 WOOD STONE CORPORATION 800.988.8103 info@woodstone-corp.com E-MAIL TOLL FREE 1801 W. Bakerview Rd. 360.650.1111 woodstone-corp.com... - Page 15 Disassemble the stand if necessary� Follow the assembly instructions in the ASSEMBLY section to reassemble the oven� M0026.08 JANUARY 2020 WOOD STONE CORPORATION 800.988.8103 info@woodstone-corp.com E-MAIL TOLL FREE 1801 W. Bakerview Rd.
-
Page 16: Lifting The Oven
USING THE OPTIONAL LIFTING SYSTEM An optional Lifting System is available from Wood Stone to facilitate tipping the oven body onto its back or side (as shown below)� When turned on its side, the upper oven portion of Bistro or Phoenix models 4343, 4355 will be approximately 32 inches wide� This will allow for easier access through small passages�... - Page 17 LIFTING THE OVEN Wood-Fired Bistro Line Installation and Operation Manual 10. Once the oven is on the other side of the passageway, attach strap to the clevises at the Lifting Holes on the Crosspiece and, with a gantry crane, lift the oven straight up�...
-
Page 18: Exploded Parts View
Rear Panel Control Box Side Panel Front Access Panel Side Panel Toe Kick M0026.08 JANUARY 2020 WOOD STONE CORPORATION 800.988.8103 info@woodstone-corp.com E-MAIL TOLL FREE 1801 W. Bakerview Rd. 360.650.1111 woodstone-corp.com An ongoing program of product improvement may Bellingham, WA 98226 USA 360.650.1166... -
Page 19: Assembly
2. Use the 3/8" x 1" carriage bolts to assemble the stand� Be sure to use the washers provided and to tighten nuts and bolts securely� Carriage bolts 3/8 x 1" M0026.08 JANUARY 2020 WOOD STONE CORPORATION 800.988.8103 info@woodstone-corp.com E-MAIL TOLL FREE 1801 W. Bakerview Rd. - Page 20 M0026.08 JANUARY 2020 WOOD STONE CORPORATION 800.988.8103 info@woodstone-corp.com E-MAIL TOLL FREE 1801 W. Bakerview Rd. 360.650.1111 woodstone-corp.com...
- Page 21 6. Attach the control box to the oven using (4) 1/4-20 screws� The control box should be oriented so temperature readout is reading right side up� (4) 1/4-20 screws M0026.08 JANUARY 2020 WOOD STONE CORPORATION 800.988.8103 info@woodstone-corp.com E-MAIL TOLL FREE 1801 W. Bakerview Rd.
- Page 22 Washer Bolt Carriage bolt Washer & nut not shown M0026.08 JANUARY 2020 WOOD STONE CORPORATION 800.988.8103 info@woodstone-corp.com E-MAIL TOLL FREE 1801 W. Bakerview Rd. 360.650.1111 woodstone-corp.com An ongoing program of product improvement may Bellingham, WA 98226 USA 360.650.1166...
- Page 23 Oven Arches DO NOT REMOVE Removal will affect structural integrity, heat retention, operation and void the Warranty� M0026.08 JANUARY 2020 WOOD STONE CORPORATION 800.988.8103 info@woodstone-corp.com E-MAIL TOLL FREE 1801 W. Bakerview Rd. 360.650.1111 woodstone-corp.com An ongoing program of product improvement may Bellingham, WA 98226 USA 360.650.1166...
-
Page 24: Utility Connections
The oven should be bolted to the floor using the holes provided at the base of the stand� NOTE: Rear panel MUST be installed. M0026.08 JANUARY 2020 WOOD STONE CORPORATION 800.988.8103 info@woodstone-corp.com E-MAIL TOLL FREE 1801 W. -
Page 25: Storage Box Installation
Storage Box� Fasten using (2) provided 1/4-20 screws (c)� 3 Storage Box Connector 2 Storage Box 1 Toe kick (w/ perforations) M0026.08 JANUARY 2020 WOOD STONE CORPORATION 800.988.8103 info@woodstone-corp.com E-MAIL TOLL FREE 1801 W. Bakerview Rd. -
Page 26: Controller
1" below hearth display on and surface� Display will off� read “LO” when the temperature is below 100 °F� M0026.08 JANUARY 2020 WOOD STONE CORPORATION 800.988.8103 info@woodstone-corp.com E-MAIL TOLL FREE 1801 W. Bakerview Rd. 360.650.1111 woodstone-corp.com An ongoing program of product improvement may Bellingham, WA 98226 USA 360.650.1166... -
Page 27: Initial Start-Up
Never use any type of flammable liquid or fuel to start a fire in a Wood Stone oven. Doing so could cause a dangerous situation and/or damage to the oven ceramic. -
Page 28: Daily Operation
They should be retained in the closed container until all cinders have thoroughly cooled� Wood Stone’s stainless steel ash shovel and Double Compartment Ash Dolly disposal system is a safe and convenient way to dispose of ash� See specifications in the Tools and Accessories section on woodstone-corp.com or call your dealer or Wood Stone for details�... -
Page 29: Daily Maintenance
MUST BE CLEANED AT LEAST MONTHLY. DO NOT POUR OR SPRAY LIQUIDS ONTO THE OVEN DECK OR THE OVEN INTERIOR AS THIS CAN DAMAGE THE CERAMIC AND WILL VOID THE WARRANTY. M0026.08 JANUARY 2020 WOOD STONE CORPORATION 800.988.8103 info@woodstone-corp.com E-MAIL TOLL FREE 1801 W. -
Page 30: Wood Burning
The frequency of inspection and cleaning will depend on hours of use and type and quality of wood used as fuel� Only use hardwood species dried to a moisture content of 20% or less� See Wood Stone’s FUELWOOD FACTS section in this manual�... -
Page 31: Fuelwood Facts
Wet wood is the most common operational difficulty associated with wood-fired cooking equipment� Wood Stone’s optional Mini-Ligno E Wood Moisture Meter can save you from paying for water when you thought you were paying for wood (see the Tools &... -
Page 32: 120 Vac Electrical Diagram
120 VAC ELECTRICAL DIAGRAM Wood-Fired Bistro Line Installation and Operation Manual BISTRO 120 VAC MODELS WOOD ONLY MODELS Solid Fuel XFMR Junction CB 4A Blue Solid Fuel Yellow 110-120 VAC 50/60Hz wired by others Temperature Controller Thermo Couple Control Panel Type 4 Yellow Bellingham, WA +1(360)650-1111 www.woodstone-corp.com DIAG #:... -
Page 33: 240 Vac Electrical Diagram
240 VAC ELECTRICAL DIAGRAM Wood-Fired Bistro Line Installation and Operation Manual BISTRO 240 VAC MODELS EXPORT MODELS Solid Fuel Only EM-2V Thermocouple Readout 12 VAC Yellow + Red - XFMR TB-A 220-240 VAC Type K 50-60Hz Thermocouple wired by others Probe DIAG #: WD052 Rev. -
Page 34: Limited Warranty
LIMITATIONS OF LIABILITY In the event of warranty claim or otherwise, the sole obligation of Wood Stone shall be the repair and/or replacement, at the option of Wood Stone, of the appliance or component or part thereof� Such repair or replacement shall be at the expense of Wood Stone with the exception of travel over 100 miles or two hours, overtime, and holiday charges which shall be at the expense of the purchaser�... - Page 35 Blank page M0026.08 JANUARY 2020...
- Page 36 WOOD STONE CORPORATION Toll Free 800.988.8103 1801 W. Bakerview Rd. Tel 360.650.1111 Bellingham, WA 98226 USA Fax 360.650.1166 www.woodstone-corp.com An ongoing program of product improvement may require us to change specifications without notice. M0026.08 JANUARY 2020...
