Installation and
Operation Manual
BISTRO LINE
Stone Hearth Oven
Dual Radiant Flame Burners, Gas-Fired Models
BISTRO 4343 PITA OVEN WS-BL-4343-RFG-LR
BISTRO 4355 PITA OVEN WS-BL-4355-RFG-LR
BISTRO 4836 PITA OVEN WS-BL-4836-RFG-LR
WOOD STONE CORPORATION
1801 W. Bakerview Rd.
Bellingham, WA 98226 USA
www.woodstone-corp.com
Toll Free 800.988.8103
Tel 360.650.1111
Fax 360.650.1166
DOC NO M0028.09
REVISED SEPTEMBER 2017
Advertisement
Table of Contents
Related Manuals for Wood Stone BISTRO Series
Summary of Contents for Wood Stone BISTRO Series
- Page 1 Stone Hearth Oven Dual Radiant Flame Burners, Gas-Fired Models BISTRO 4343 PITA OVEN WS-BL-4343-RFG-LR BISTRO 4355 PITA OVEN WS-BL-4355-RFG-LR BISTRO 4836 PITA OVEN WS-BL-4836-RFG-LR WOOD STONE CORPORATION Toll Free 800.988.8103 1801 W. Bakerview Rd. Tel 360.650.1111 Bellingham, WA 98226 USA Fax 360.650.1166...
-
Page 2: Table Of Contents
� � � � � � � � � � � � � � � � � Interlock Diagram � � � � � � � � � � � � � � � � � � Limited Warranty M0028.09 SEPTEMBER 2017 WOOD STONE CORPORATION 800.988.8103 info@woodstone-corp.com E-MAIL TOLL FREE 1801 W. - Page 3 DUAL BURNER BISTRO Dual Burner Bistro Line Installation and Operation Manual INSTALLATION AND OPERATION MANUAL FOR THE WOOD STONE DUAL BURNER BISTRO NATURAL GAS OR PROPANE FUELED DUAL BURNER STONE HEARTH OVEN WS-BL-4343-RFG-LR-(NG OR LP) WS-BL-4355-RFG-LR-(NG OR LP) WS-BL-4836-RFG-LR-(NG OR LP)
- Page 4 CAUTIONS & WARNINGS Dual Burner Bistro Line Installation and Operation Manual INSTALLATION AND OPERATION MANUAL FOR THE WOOD STONE DUAL BURNER BISTRO NATURAL GAS (NG) OR PROPANE (LP) FUELED DUAL BURNER STONE HEARTH OVEN WS-BL-4343-RFG-LR-(NG OR LP), WS-BL-4355-RFG-LR-(NG OR LP),...
- Page 5 12 months, or sooner if heavy use is expected. SAVE THE INSTRUCTIONS Wood Stone’s Gas-Fired Bistro Dual Burner ovens have been tested and approved by Intertek Testing Services and are ETL listed to ANSI Z83.11:2016 Ed. 4 / CSA 1.8:2016 Ed. 4 and to NSF/ANSI 4:2016.
- Page 6 TOLL FREE 68,000 BTU, LP E INFORMATION CONTAINED IN THIS DRAWING IS THE ATION CONTAINED IN THIS DRAWING IS THE 80,500 BTU, NG THOUT THE WRITTEN PERMISSION OF WOOD STONE IS PROHIBITED 1801 W. Bakerview Rd. 360.650.1111 woodstone-corp.com 68,000 BTU, LP...
- Page 7 GAS INLET: 3/4" NPT LEGEND: LEGEND: WITHOUT NOTICE. WITHOUT NOTICE. 80,500 BTU, NG OUT THE WRITTEN PERMISSION OF WOOD STONE IS ANY REPRODUCTION OR USE IN PART OR AS A WHOLE GAS INLET: 3/4" NPT M0028.09 SEPTEMBER 2017 WOOD STONE CORPORATION 800.988.8103 info@woodstone-corp.com...
- Page 8 120VAC, 2A 360.650.1111 woodstone-corp.com 80,500 BTU, NG WITHOUT THE WRITTEN PERMISSION OF WOOD STONE IS MATION CONTAINED IN THIS DRAWING IS THE THE INFORMATION CONTAINED IN THIS DRAWING IS THE An ongoing program of product improvement may 68,000 BTU, LP...
-
Page 9: Bl-4343-Lr
CRANE. BL-4343-LR The oven arrives with Pickeyes attached� When craning a Wood Stone oven, use a Spreader Bar with a fig. 1 two-legged sling rigged on each end� The spreader bar should be of a sufficient length to keep the sling from contacting the oven, and oriented as shown in fig 1�... -
Page 10: Installation Clearances
Contact your local building or fire officials about restrictions and installation inspection in your area. CLEARANCES 1. The Wood Stone Bistro oven should have a minimum 1-inch clearance to combustibles from all sides, 6-inch clearance to combustibles from the top, and 6-inch clearance from the exhaust transition and flue collar. Any facade wall built 6 inches to either side of the doorway and above must be of non-combustible construction�... -
Page 11: Venting
The following are the manufacturer’s recommendations for venting Wood Stone Dual Burner Bistro model ovens� It is never appropriate to use “B vent” in any part of an exhaust system connected to a Wood Stone oven� All duct material must be manufactured to the specifications of a grease duct�... -
Page 12: Hood Specifications
HOOD SPECIFICATIONS Dual Burner Bistro Line Installation and Operation Manual BL-4343, 4355 HOOD SPECIFICATIONS Wood Stone Hoods by Gaylord Specs Required CFM - 625 CFM Static Pressure - 0.80" W.C. Duct Collar - 7" x 7" I.D. M0028.09 SEPTEMBER 2017 WOOD STONE CORPORATION 800.988.8103... -
Page 13: Disassembly
Mantle in place, and remove the mantle� It may be necessary to cut the silicone at the joint between the Mantle and the oven� Mantle Faceplate Cover Screws M0028.09 SEPTEMBER 2017 WOOD STONE CORPORATION 800.988.8103 info@woodstone-corp.com E-MAIL TOLL FREE 1801 W. Bakerview Rd. - Page 14 Disassemble the stand if necessary� Follow the assembly instructions in the ASSEMBLY section to reassemble the oven� M0028.09 SEPTEMBER 2017 WOOD STONE CORPORATION 800.988.8103 info@woodstone-corp.com E-MAIL TOLL FREE 1801 W. Bakerview Rd.
-
Page 15: Lifting The Oven
USING THE OPTIONAL LIFTING SYSTEM An optional Lifting System is available from Wood Stone to facilitate tipping the oven body onto its back and lifting it� When turned on its back, the upper oven portion of Bistro 4343, 4355 and 4836 (REC-(8, 9, 11) will be approximately 32 inches wide� This will allow for easier access through small passages�... - Page 16 LIFTING THE OVEN Dual Burner Bistro Line Installation and Operation Manual 10. Once the oven is on the other side of the passageway, attach strap to the clevises at the Lifting Holes on the Crosspiece and, with a gantry crane, lift the oven straight up�...
-
Page 17: Exploded Parts Diagram
Flame Guards Discard once removed.) Rear Panel Control Box Front Panel Side Panel Toe Kick M0028.09 SEPTEMBER 2017 WOOD STONE CORPORATION 800.988.8103 info@woodstone-corp.com E-MAIL TOLL FREE 1801 W. Bakerview Rd. 360.650.1111 woodstone-corp.com An ongoing program of product improvement may Bellingham, WA 98226 USA 360.650.1166... -
Page 18: Assembly
LOWER forklift pockets� If the oven is to be installed against a wall, leave access to the back of the oven until the assembly is completed� See CAUTIONS on next page� M0028.09 SEPTEMBER 2017 WOOD STONE CORPORATION 800.988.8103 info@woodstone-corp.com... - Page 19 Wire here. SV-2 & SV-3 Gas Valves and left & right provided to connect the Burners. Tighten the fitting firmly. Burner, left and right. M0028.09 SEPTEMBER 2017 WOOD STONE CORPORATION 800.988.8103 info@woodstone-corp.com E-MAIL TOLL FREE 1801 W. Bakerview Rd. 360.650.1111 woodstone-corp.com...
- Page 20 10. Reinstall the Burner Guards� The lower tab of the guard fits into the front of the burner opening� Lower tab of Burner Guard fits into the front of the burner opening M0028.09 SEPTEMBER 2017 WOOD STONE CORPORATION 800.988.8103 info@woodstone-corp.com E-MAIL TOLL FREE 1801 W. Bakerview Rd. 360.650.1111 woodstone-corp.com...
- Page 21 National Electrical Code, ANSI/NFPA 70, or the Canadian Electrical Code, CSA C22.2, as applicable. An Electrical Diagram is provided inside the bottom cover of the Control Box, and at the end of this manual� M0028.09 SEPTEMBER 2017 WOOD STONE CORPORATION 800.988.8103 info@woodstone-corp.com...
-
Page 22: Gas Specifications
Wood Stone recommends that the Bistro be equipped with a manual, individual shutoff valve, located between the oven and the main gas supply, and that this shutoff valve (supplied by others) be left readily accessible� Wood Stone also recommends that inspection and maintenance of the burners and gas piping connections of this appliance be performed at regularly scheduled intervals and only by professional gas appliance service agencies�... - Page 23 The oven should be bolted to the floor using the holes provided at the base of the stand� NOTE: Rear panel must be installed for the proper functioning of the oven. M0028.09 SEPTEMBER 2017 WOOD STONE CORPORATION 800.988.8103 info@woodstone-corp.com E-MAIL TOLL FREE 1801 W.
-
Page 24: Storage Box Installation
DWN BY: bena DATE: 6/11/2013 Bistro Commercial Series - 4343 General Arrangement File Location: \\woodstone.net\dfs\CAD\0_Ovens\z_Be nA_Prelim\Bistro_Box\WS-BL-4343.dft M0028.09 SEPTEMBER 2017 WOOD STONE CORPORATION 800.988.8103 info@woodstone-corp.com E-MAIL TOLL FREE 1801 W. Bakerview Rd. 360.650.1111 woodstone-corp.com An ongoing program of product improvement may Bellingham, WA 98226 USA 360.650.1166... -
Page 25: Controller
(see Burner Disable Switch Use this switch to disable one of the at right)� burners (specify which burner will be disabled at time of order)� M0028.09 SEPTEMBER 2017 WOOD STONE CORPORATION 800.988.8103 info@woodstone-corp.com E-MAIL TOLL FREE 1801 W. Bakerview Rd. -
Page 26: Initial Start-Up
(optional) stainless steel Night Heat Retention Door in place� This option is for heat retention only, and should only be used when the appliance is turned off� M0028.09 SEPTEMBER 2017 WOOD STONE CORPORATION 800.988.8103 info@woodstone-corp.com E-MAIL TOLL FREE 1801 W. Bakerview Rd. -
Page 27: Oven Operation
2 hours� Use the Flame Height Control Knob to control the amount of heat in the oven� See woodstone-corp.com for detailed information on cooking in your Wood Stone oven� CLEANING THE OVEN 1. As needed (twice per hour), use the floor brush to sweep stray food debris to the doorway, where it can be easily removed with a dough cutter or spatula�... -
Page 28: Daily Maintenance
THERMAL CLEANING If a Wood Stone gas-fired oven is operated at low temperatures (below 525 °F), you may notice a buildup on the oven floor� Note that this floor buildup may be perceived as the floor flaking away� If you operate the oven below 450 °F you may also notice some buildup on the interior walls and/or ceiling of the oven�... -
Page 29: Troubleshooting Guide
2. Damaged thermocouple� Contact Wood Stone for assistance� Please contact Wood Stone at 1-800-988-8103 should service be necessary, or if you have any questions about your oven. Our service hours are 8am to 5pm Pacific tme. Follow the recorded instructions for Emergency Service if you require assistance during non-business hours. -
Page 30: Electrical Diagrams
ELECTRICAL DIAGRAMS 120 VAC ELECTRICAL DIAGRAM Dual Burner Bistro Line Installation and Operation Manual DUAL BURNER BISTRO - ALL MODELS See equipment data plate for correct voltage of your oven. Dual RFG 120 VAC XFMR Blue CB 4A Yellow Left Radiant White 100-120 VAC... -
Page 31: Interlock Diagram
For additional interlock options, see the Wood Stone Interlock Options supplement in the Manuals section on the website, woodstone-corp.com, or contact Wood Stone for additional information�... -
Page 32: Limited Warranty
LIMITATIONS OF LIABILITY In the event of warranty claim or otherwise, the sole obligation of Wood Stone shall be the repair and/or replacement, at the option of Wood Stone, of the appliance or component or part thereof� Such repair or replacement shall be at the expense of Wood Stone with the exception of travel over 100 miles or two hours, overtime, and holiday charges which shall be at the expense of the purchaser�...
