Bistro Home
Stone Hearth Cooking Appliance
Gas-Fired Residential Models
Jet Style Burner
enhance your
food, home & lifestyle
An ongoing program of product improvement may require us to change specifications without notice.
Wood Stone Corporation
1801 W. Bakerview Rd.
tf. 800.578.6836
Bellingham, WA 98226 U.S.A.
f. 360.734.0223

Installation and Operation Manual

with a Wood Stone Home Oven
Doc no: M0003.06
woodstonehome.com
Rev. July 2015
info@woodstonehome.com
BISTRO HOME 3030
WS-BH-3030-RFG
BISTRO HOME 4343
WS-BH-4343-RFG
WS-BH-4343-RFG-W
BISTRO 4355
WS-BH-4355-RFG
WS-BH-4355-RFG-W
BISTRO HOME 4836
WS-BH-4836-RFG

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BISTRO HOME 3030 and is the answer not in the manual?

Questions and answers

Related Manuals for Wood Stone BISTRO HOME 3030

Summary of Contents for Wood Stone BISTRO HOME 3030

  • Page 1: Installation And Operation Manual

    BISTRO HOME 4836 WS-BH-4836-RFG enhance your food, home & lifestyle with a Wood Stone Home Oven An ongoing program of product improvement may require us to change specifications without notice. Wood Stone Corporation Doc no: M0003.06 1801 W. Bakerview Rd.

  • Page 2: Table Of Contents

    Cautions and Warnings ..... . . 3 Bistro Home 3030 Specs ..... . . 5 Bistro Home 4343 Specs .

  • Page 3: Cautions And Warnings

    Cautions and Warnings Bistro Home Oven Installation and Operation Manual INSTALLATION AND OPERATION MANUAL FOR THE WOOD STONE HOME BISTRO STONE HEARTH COOKING APPLIANCE WS-BH-3030-RFG-(NG OR LP) • • WS-BH-4343-RFG-(NG OR LP) • WS-BH-4343-RFG-W-(NG OR LP) WS-BH-4355-RFG-(NG OR LP) •...
  • Page 4 Commonwealth of Massachusetts. DO NOT THROW AWAY THIS MANUAL. RETAIN THIS MANUAL FOR FUTURE REFERENCE. Additional copies of this manual and prompt responses to service/maintenance questions are available from Wood Stone at (800) 578-6836 or visit woodstonehome.com ANSI Z21.1-2010 CSA 22.2 No.3-M1998,R2009 CAN1-1.1-M81,R2006...

  • Page 5: Bistro Home 3030 Specs

    Bistro Home 3030 Specs Bistro Home Oven Installation and Operation Manual plan view rear view 29 1/4" 29 1/4" 740mm 29 1/4" 29 1/4" 740mm 740mm 740mm 11 1/4" 11 1/4" 280mm 4" 11 1/4" 11 1/4" 280mm 4" 100mm...

  • Page 6: Bistro Home 4343 Specs

    An ongoing program of product improvement may require us to change specifications without notice. bena Bellingham, WA 360/650-1111 www.woodstone-corp.com ngham, WA 360/650-1111 www.woodstone-corp.com ngham, WA 360/650-1111 www.woodstone-corp.com Wood Stone Corporation DATE: DWN BY: 10/9/2014 4343 Bistro Oven 4343 Bistro Ove 1801 W.

  • Page 7: Bistro Home 4355 Specs

    LEGEND: LEGEND: THE INFORMATION CONTAINED IN THIS DRAWING IS THE WITHOUT NOTICE. WITHOUT NOTICE. SOLE PROPERTY OF WOOD STONE CORPORATION SOLE PROPERTY OF WOOD STONE CORPORATION 120VAC, 2A 120VAC, 2A THE INFORMATION CONTAINED IN THIS DRAWING IS THE THE INFORMATION CONTAINED IN THIS DRAWING IS THE GAS INLET: 3/4"...

  • Page 8: Bistro Home 4836 Specs

    120VAC, 4A LEGEND: LEGEND: ANY REPRODUCTION OR USE IN PART OR AS A WHOLE GAS INLET: 3/4" NPT THE INFORMATION CONTAINED IN THIS DRAWING IS THE WITHOUT NOTICE. WITHOUT NOTICE. 225,000 BTU, NG WITHOUT THE WRITTEN PERMISSION OF WOOD STONE IS...

  • Page 9: Installation Clearances

    Non-combustible floor SEE FOLLOWING PAGE FOR EXAMPLES OF NON-COMBUSTIBLE AND COMBUSTIBLE WALL CONSTRUCTION. An ongoing program of product improvement may require us to change specifications without notice. Wood Stone Corporation woodstonehome.com 1801 W. Bakerview Rd. tf. 800.578.6836 M0003.06 Bellingham, WA 98226 U.S.A.
  • Page 10 Wood studs faced with with cement board Drywall or fire-rated Drywall Drywall or fire-rated Drywall An ongoing program of product improvement may require us to change specifications without notice. Wood Stone Corporation 1801 W. Bakerview Rd. tf. 800.578.6836 woodstonehome.com M0003.06 Bellingham, WA 98226 U.S.A.

  • Page 11: Venting

    The following are the manufacturer’s recommendations for venting the Wood Stone Bistro. It is never appropriate to use “B vent” in any part of an exhaust system connected to a Wood Stone appliance. All duct material must be manufactured to the specifications of a grease duct. Use either option 1 or option 2 below: 1.

  • Page 12: Moving The Bistro

    ONCE YOU HAVE MOVED THE APPLIANCE TO WHERE IT WILL BE INSTALLED, PLEASE SEE THE ASSEMBLY CONNECTIONS SECTION FOR INSTRUCTIONS REGARDING ELECTRICAL AND GAS CONNECTIONS. An ongoing program of product improvement may require us to change specifications without notice. Wood Stone Corporation woodstonehome.com 1801 W. Bakerview Rd.

  • Page 13: Disassembly

    An ongoing program of product improvement may require us to change specifications without notice. Wood Stone Corporation woodstonehome.com 1801 W. Bakerview Rd. tf. 800.578.6836 M0003.06 Bellingham, WA 98226 U.S.A.
  • Page 14 Bistro section for tilting and moving the appli- ance body. See the Assembly section for instruc- tions on how to reassemble the appliance. An ongoing program of product improvement may require us to change specifications without notice. Wood Stone Corporation woodstonehome.com 1801 W. Bakerview Rd. tf. 800.578.6836 M0003.06...

  • Page 15: Lifting The Bistro

    An optional Lifting System is available from Wood Stone to facilitate tipping the oven body onto its back and lifting it. When turned on its back, the upper oven portion of Bistro or Phoenix models 4343, 4355 and 4836 will be approximately 32 inches wide.
  • Page 16 9. The oven can now be moved through a narrow doorway or passageway. An ongoing program of product improvement may require us to change specifications without notice. Wood Stone Corporation 1801 W. Bakerview Rd. tf. 800.578.6836 woodstonehome.com M0003.06 Bellingham, WA 98226 U.S.A.

  • Page 17: Exploded Parts View

    Note: If the appliance came with temporary shipping panel (not shown—see Assembly section, step 5), discard after removing. An ongoing program of product improvement may require us to change specifications without notice. Wood Stone Corporation 1801 W. Bakerview Rd. tf. 800.578.6836 woodstonehome.com...

  • Page 18: Assembly

    Use 3/8" x 3/4" carriage bolts to attach the sides instead of the 3/8" x 1" long carriage bolts. An ongoing program of product improvement may require us to change specifications without notice. Wood Stone Corporation 1801 W. Bakerview Rd.
  • Page 19 An ongoing program of product improvement may require us to change specifications without notice. Wood Stone Corporation woodstonehome.com 1801 W. Bakerview Rd. tf. 800.578.6836 M0003.06 Bellingham, WA 98226 U.S.A.
  • Page 20 Flame Height Control Knob is on the left side of the control box. An ongoing program of product improvement may require us to change specifications without notice. Wood Stone Corporation 1801 W. Bakerview Rd. tf. 800.578.6836 woodstonehome.com M0003.06...
  • Page 21 Tighten the fitting here. firmly. An ongoing program of product improvement may require us to change specifications without notice. Wood Stone Corporation 1801 W. Bakerview Rd. tf. 800.578.6836 woodstonehome.com M0003.06 Bellingham, WA 98226 U.S.A. f. 360.734.0223 info@woodstonehome.com...
  • Page 22 An ongoing program of product improvement may require us to change specifications without notice. Wood Stone Corporation woodstonehome.com 1801 W. Bakerview Rd. tf. 800.578.6836 M0003.06 info@woodstonehome.com...
  • Page 23 Continued on following page. An ongoing program of product improvement may require us to change specifications without notice. Wood Stone Corporation woodstonehome.com 1801 W. Bakerview Rd.

  • Page 24: Utility Connections

    An electrical diagram is provided inside the bottom cover of the control box, and at the end of this manual. An ongoing program of product improvement may require us to change specifications without notice. Wood Stone Corporation woodstonehome.com 1801 W. Bakerview Rd.
  • Page 25 1" away from the service panel. The appliance should be bolted to the floor using the holes provided at the base of the stand. An ongoing program of product improvement may require us to change specifications without notice. Wood Stone Corporation woodstonehome.com 1801 W. Bakerview Rd.
  • Page 26 Fan / oven interlock relay instructions The interlock relay system is an option available from Wood Stone. With the interlock relay option, when the oven is turned on, the interlock relay is energized, allowing power to flow to the exhaust fan serving the oven. The fan will turn on with the oven.

  • Page 27: Storage Box Installation

    Bistro Commercial Series - 4343 General Arrangement File Location: \\woodstone.net\dfs\CAD\0_Ovens\z_Be nA_Prelim\Bistro_Box\WS-BL-4343.dft An ongoing program of product improvement may require us to change specifications without notice. Wood Stone Corporation 1801 W. Bakerview Rd. tf. 800.578.6836 woodstonehome.com M0003.06 Bellingham, WA 98226 U.S.A.

  • Page 28: Outdoor Installation

    The appliance is available with an optional collapsible chimney assembly with rain cap or optional fixed chimney (both shown below). These options are for use with freestanding outdoor installations without a roof structure above the oven. Contact your dealer or Wood Stone for more information. Fixed chimney option Collapsible outdoor chimney assembly with rain cap option Extended and locked.

  • Page 29: Mantle Stone Installation

    Mantle Stone Installation Bistro Home Oven Installation and Operation Manual On-site installation of mantle stone Bistro Home ovens can be ordered with the optional Mantle Bracket to facilitate the installation of a custom granite (or similiar stone) mantle on-site. The installation process is described below. mantle bracket mantle bracket faceplate...
  • Page 30 Brass Flange. Tighten Mantle Bracket to oven. Reinstall Mantle Faceplate Cover. Reinstall Swinging Doors. An ongoing program of product improvement may require us to change specifications without notice. Wood Stone Corporation 1801 W. Bakerview Rd. tf. 800.578.6836 woodstonehome.com M0003.06 Bellingham, WA 98226 U.S.A.

  • Page 31: Mantle Stone Dimensions

    THE INFORMATION CONTAINED IN THIS DRAWING IS THE SOLE PROPERTY OF WOOD STONE CORPORATION DWN BY: 3/4" UNLESS NOTED OTHERWISE ANY REPRODUCTION OR USE IN PART OR AS A WHOLE WITHOUT THE WRITTEN PERMISSION OF WOOD STONE IS PROHIBITED 19mm 7.5" Granite - Swing Door - Curved PART #:...

  • Page 32: Controller

    Use this knob to raise/lower the flame section for details. to control the appliance temperature. An ongoing program of product improvement may require us to change specifications without notice. Wood Stone Corporation 1801 W. Bakerview Rd. tf. 800.578.6836 woodstonehome.com M0003.06 Bellingham, WA 98226 U.S.A.

  • Page 33: Operation

    Bistro Home Oven Installation and Operation Manual NOTE: The ceramic materials used in the construction of your Wood Stone oven will absorb moisture if exposed to high humidity or damp conditions during shipment from the factory or extended periods of storage before instal- lation.
  • Page 34 I/O button and turn the radiant flame to its highest setting (#5). The appliance should reach 500–550 °F within 1-1/2 to 2 hours. See woodstonehome.com for recipes and additional detailed information on cooking in your Wood Stone Bistro. The optional perforated stainless steel Heat Efficiency Door may be used to speed the heat-up process. To use the Heat Efficiency Door, open the glass doors (if equipped), and place it into the doorway so it is right up against the oven arches, making sure to leave the glass doors (if equipped) open.
  • Page 35 This appliance requires electrical power to operate. Do not attempt to operate this appliance during a power outage or power failure. An ongoing program of product improvement may require us to change specifications without notice. Wood Stone Corporation woodstonehome.com 1801 W. Bakerview Rd.

  • Page 36: Maintenance

    Thermal Cleaning Gas-Fired Appliance - If a Wood Stone gas-fired appliance is operated at low temperatures (below 525 °F), you may notice a buildup on the appliance floor. Note that this floor buildup may be perceived as the floor flaking away.

  • Page 37: Wood Burning

    4. Retain the ashes in the closed container until all the cinders have thoroughly cooled. Ashes can then be disposed of safely. NOTE: Wood Stone's stainless steel Ash Shovel and double compartment Ash Dolly offer a safe and convenient way to dispose of ash. See the Tools and Accessories section of woodstonehome.com for details.

  • Page 38: Troubleshooting Guide

    Unit will not turn back turn the controller back on. Please contact Wood Stone at (800) 578-6836 should service be necessary, or if you have any questions about your appliance. Our office hours are 8AM to 5PM (PST), with service hours until 4:30PM.

  • Page 39: Programming

    The ON and OFF settings can be reviewed by holding the respective button for 5 seconds. The time will be displayed for 5 seconds and then revert back to the current time of day. An ongoing program of product improvement may require us to change specifications without notice. Wood Stone Corporation woodstonehome.com 1801 W. Bakerview Rd.
  • Page 40 Flame Height Control Knob set to 3. An ongoing program of product improvement may require us to change specifications without notice. Wood Stone Corporation 1801 W. Bakerview Rd.

  • Page 41: Fuelwood Facts

    (low weight, low-med heat, poor coaling, high sparking and high residual creosote). Do not use pressed wood products in Wood Stone food service equip- ment, they may damage the ceramics.

  • Page 42: Electrical Diagram

    DIAG #: WD084 Rev. 0 Bellingham, WA +1(360)650-1111 www.woodstone-corp.com DATE: 11/17/2014 An ongoing program of product improvement may require us to change specifications without notice. Wood Stone Corporation woodstonehome.com 1801 W. Bakerview Rd. tf. 800.578.6836 M0003.06 info@woodstonehome.com Bellingham, WA 98226 U.S.A.

  • Page 43: Limited Warranty

    In the event of warranty claim or otherwise, the sole obligation of Wood Stone shall be the repair and/or replacement, at the option of Wood Stone, of the appliance or component or part thereof. Such repair or replacement shall be at the expense of Wood Stone with the exception of travel over 100 miles or two hours, overtime, and holiday charges which shall be at the expense of the purchaser.
