Installation and
Operation Manual
TANDOOR
Speciality Ovens
Gas-Fired, Round, Square, Octagonal,
Barrel Models
TANDOOR 31" WS-GFT-31
TANDOOR 35" WS-GFT-35
BARREL TANDOOR WS-GFT-35-CUS
WOOD STONE CORPORATION
1801 W. Bakerview Rd.
Bellingham, WA 98226 USA
www.woodstone-corp.com
Toll Free 800.988.8103
Tel 360.650.1111
Fax 360.650.1166
DOC NO M0053.05
REVISED April 2017

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TANDOOR 31 and is the answer not in the manual?

Questions and answers

Summary of Contents for Wood Stone TANDOOR 31

  • Page 1 Installation and Operation Manual TANDOOR Speciality Ovens Gas-Fired, Round, Square, Octagonal, Barrel Models TANDOOR 31" WS-GFT-31 TANDOOR 35" WS-GFT-35 BARREL TANDOOR WS-GFT-35-CUS WOOD STONE CORPORATION Toll Free 800.988.8103 1801 W. Bakerview Rd. Tel 360.650.1111 Bellingham, WA 98226 USA Fax 360.650.1166 www.woodstone-corp.com...
  • Page 2: Table Of Contents

    OPERATION � � � � � � � � � � � � � � � � � � � � � � � �11 LIMITED WARRANTY � � � � � � � � � � � � � � � � �14 WOOD STONE CORPORATION info@woodstone-corp.com M0053.05 APRIL 2017...
  • Page 3: Tandoor

    TANDOOR Tandoor Installation and Operation Manual INSTALLATION AND OPERATION MANUAL FOR THE WOOD STONE TANDOOR GAS-FIRED TANDOOR OVEN WS-GFT-31 (ROUND, SQUARE AND OCTAGONAL), WS-GFT-35 (ROUND, SQUARE, OCTAGONAL) AND WS-GFT-35-CUS (BARREL) MODELS ADDITIONAL COPIES AVAILABLE UPON REQUEST Square model (shown with...
  • Page 4: Cautions And Warnings

    DO NOT THROW THIS MANUAL AWAY Wood Stone's Gas-Fired Tandoor ovens have been tested and approved by Intertek Testing Services, and are ETL listed to ANSI Z83.11:2016 Ed. 4, CSA 1.8:2016 Ed. 4, and to NSF/ANSI Standard 4.
  • Page 5: Gft-31 Specifications

    SOLE PROPERTY OF WOOD STONE CORPORATION GAS INLET: 1/2" NPT ANY REPRODUCTION OR USE IN PART OR AS A WHOLE 40,000 BTU, NG WITHOUT THE WRITTEN PERMISSION OF WOOD STONE IS 40,000 BTU, LP PROHIBITED Plan view (Octagonal) \\woodstone.net\dfs\CAD\0 Pn\WS Top Level\WS-GFT-31_General_Arrangement-1.dft 21"...
  • Page 6: Gft-35 Specifications

    SOLE PROPERTY OF WOOD STONE CORPORATION Opening GAS INLET: 1/2" NPT ANY REPRODUCTION OR USE IN PART OR AS A WHOLE 40,000 BTU, NG WITHOUT THE WRITTEN PERMISSION OF WOOD STONE IS 40,000 BTU, LP PROHIBITED Plan view (Octagonal) 24 3/4"...
  • Page 7: Gft-35-Cus (Barrel) Specs

    ANY REPRODUCTION OR USE IN PART OR AS A WHOLE ANY REPRODUCTION OR USE IN PART OR AS A WHOLE 40,000 BTU, NG WITHOUT THE WRITTEN PERMISSION OF WOOD STONE IS 40,000 BTU, NG 40,000 BTU, NG 40,000 BTU, LP...
  • Page 8: Clearances & Venting

    VENTING The Wood Stone gas-fired Tandoor must be installed under an appropriate NFPA 96 approved Type 1 exhaust hood� Refer to local and/or national codes for hood specification requirements� The hood must be designed for the removal of the combustion products of gas, as well as the cooking vapors related to the intended use of the oven�...
  • Page 9: Lower Flashing Install (Barrel)

    LOWER FLASHING INSTALL (BARREL) Tandoor Installation and Operation Manual DO NOT LOWER STRIP FLASHING UNTIL TANDOOR IS LOCATED IN ITS FINAL INSTALLED POSITION Leveling the Tandoor Position Tandoor in its final installed position� With the Flashing still in the UP position, level the Tandoor using the four adjustable feet�...
  • Page 10: Gas Specifications

    The Wood Stone gas-fired Tandoor is equipped with a 1/2-inch FNPT connection, located on the underside of the rear of the unit� Anchor points for the restraining means are provided on the underside of the Tandoor; these are holes punched in the rear portion of the drip/debris pan rails�...
  • Page 11: Operation

    You may notice some small “crazing” cracks in the ceramic chamber after a few heat-ups and cool-downs� Don't be alarmed as this is normal and will not affect the longevity or performance of the Tandoor� First firing setting WOOD STONE CORPORATION info@woodstone-corp.com M0053.05 APRIL 2017 800.988.8103...
  • Page 12: Daily Operation

    Once the chamber is at the desired temperature, typically 620 °F–650 °F, remove the lid completely for the cooking day� Temperature can be determined using the optional Fluke Hand Held IR Thermometer (see the Tools and Accessories section of the Wood Stone website)� Set the Temperature Control Knob to the cooking temperature range: Temperature 1.3–1.5�...
  • Page 13 To remove debris from the chamber walls, first brush the walls with the optional In-Line Floor Brush (see the Tools and Accessories section of the Wood Stone website)� Use a moist towel (water only) to swirl around the chamber� Any debris which falls to the bottom of the chamber can be removed as described above�...
  • Page 14: Limited Warranty

    LIMITATIONS OF LIABILITY In the event of warranty claim or otherwise, the sole obligation of Wood Stone shall be the repair and/or replacement, at the option of Wood Stone, of the appliance or component or part thereof� Such repair or replacement shall be at the expense of Wood Stone with the exception of travel over 100 miles or two hours, overtime, and holiday charges which shall be at the expense of the purchaser�...
  • Page 15 LOWER STRIP FLASHING INSTALLATION M0053.05 APRIL 2017...
  • Page 16 WOOD STONE CORPORATION Toll Free 800.988.8103 1801 W. Bakerview Rd. Tel 360.650.1111 Bellingham, WA 98226 USA Fax 360.650.1166 www.woodstone-corp.com An ongoing program of product improvement may require us to change specifications without notice. M0053.05 APRIL 2017...
