Manual Datafox PZE-MasterIV Basic
Advantages:
No permanent staff lists have to be transmitted to the terminal.
Disadvantages:
Overlappings might be possible, if the firm code is not well-defined. That can happen, if you forget to
set the setup for the project or if another producer uses the same method. Different accounting programs
use different formats for the customer ID. The setup has to be set customer-specific.
¦
Under Transponder the project number/customer ID has to be input.
¦
The format check has to be set in each input chain.
Each card has to be programmed.
Example 2.
PZE-MasterIV Basic setup for Hitag 2 with card number in segment 0 and check on lists.
Operation:
Only the well-defined serial number (already programmed by the producer) in segment 0 is used.
Security is created by a check of the permanent staff lists (as standard with Unique).
Advantages:
The process is absolute safe because the well-defined serial number is used.
The setup does not need to be adjusted to each costumer, i.e. the same setup can be used for various
projects/costumers.
The cards do not need to be programmed.
All free fields are available for other uses (canteen, drinks dispenser, firm equipment etc.).
While bookings are carried out, the name of the person can be displayed.
Disadvantages:
You have to load the lists, that should be controlled on the device compulsorily. (Alternative: This can
also be done via an online check with the server application.)
Note:
£
Datafox offers a desktop reader with USB-connection to read the serial numbers
into the PZE-software. By the keyboard emulation software the reader reacts like a
keyboard. The cursor is put to the field Card number and the transponder is read.
The number in the set segment is read and written to the position of the cursor.
