Installation and Assembly:
Paramount™ Projector Ceiling Mount
Models: ACC-EXC, ACC-EXC-S, ACC-EXC-W
WARNING: Not to be used in wall applications.
Before you begin, make sure all parts shown are included with your product.

Parts List

Description
A inner channel
B extension clamp
C cable cover
D nut plate
E M6 x 12 mm socket pin screw
F M5 x 10 mm socket pin screw
G 4 mm security driver
