  • Page 1 Glencoe ® CP40 CULTIPACKER 4’ - 16’ MODELS OPERATOR’S MANUAL Form number 1PD780598 May, 1998...

  • Page 3: Table Of Contents

    Table of Contents INTRODUCTION DEALER/CUSTOMER INFORMATION TO THE DEALER: ....... . 2 TO THE CUSTOMER: .
  • Page 4 NOTES...

  • Page 5: Introduction

    INTRODUCTION This manual is written purposely to acquaint new owners of the Glencoe® CP40 Cultipacker with the functions of the various component parts of the machine as well as the service and safe operation which is vital to long life and optimum performance. Read this manual completely before you begin operating your CP40 Cultipacker.

  • Page 6: Dealer/Customer Information

    DEALER/CUSTOMER INFORMATION TO THE DEALER: TO THE CUSTOMER: Warranty Registration Warranty Registration A warranty registration form must be completed for Be sure to sign the registration form and keep your each serial-numbered unit by the dealer and signed copy. by both the dealer and the customer before or upon Know Your Equipment delivery.

  • Page 7: Specifications

    SPECIFICATIONS CP40 CULTIPACKER (NON-FOLDING) Machine Type Rolling Transport Quantity Approx. Width Width Wheels Weight (Lbs.) Machine with 17” Smooth Rollers 4’-2” 4’-10” 5’-11” 6’-6” 8’-6” 9’-3” 1030 9’-11” 10’-7” 1250 12’-0” 12’-7” 1470 14’-3” 14’-10” 1695 16’-4” 16’-11” 1920 Machine with 19” Smooth Rollers 4’-2”...

  • Page 8: Safety Decals

    SAFETY DECALS The following decals are installed to alert operators to hazards in specific machine areas. The decals are for personal safety... READ AND UNDERSTAND THE DECALS! • Keep decals clean by wiping off regularly. Use a cleaning solution if necessary. •...

  • Page 9: Safety Precautions

    Without immediate medical treatment, serious do not understand, contact your local infection can occur. authorized Glencoe® dealer, or AGCO® Corporation. • Always shut off tractor, shift to “Park” position (or shift to neutral), set brakes and before dismounting tractor or working around the machine.
  • Page 10 SAFETY PRECAUTIONS Before Operating: During Operation: • Give the machine a “once-over” for any loose • Do not allow others to be careless near this bolts, worn parts, cracked welds, hydraulic equipment. leaks, frayed hoses, etc., and make necessary • Keep hands and clothing clear of moving parts. repairs.
  • Page 11 SAFETY PRECAUTIONS Following Operation: Performing Maintenance: • Following operation, or when unhitching your • Good maintenance is your responsibility. A machine, stop the tractor, set the brakes, poorly maintained machine is an invitation to disengage the PTO and all power drives, shut trouble.

  • Page 12: Torque Chart

    TORQUE CHART BOLT TORQUE CHART - COARSE THREAD Do not replace bolts with a grade other than the grade specified. GRADE 1 GRADE 2 GRADE 5 GRADE 8 Metric Torque Ft-Lbs for - Rd Hd Sq No Marks 3 Lines on 6 Lines on Size Grade...

  • Page 13: Operation

    OPERATION Knowing how to operate this machine is important from the standpoint of performance as well as safety. The length of service you receive from this machine depends on proper machine operation, lubrication and preventive maintenance. Knowing how the machine works will also help you trouble shoot any problems that may occur.

  • Page 14: Procedure For Hitching

    OPERATION GNC0079 PROCEDURE FOR HITCHING PROCEDURE FOR UNHITCHING With the Packer on a level surface and the transport 1. Position the tractor and the Packer on a level wheels blocked: surface. 1. Back the tractor so that the drawbar and the 2.

  • Page 15: Maintenance & Service

    MAINTENANCE & SERVICE Warning! Never use your hands to locate a hydraulic leak. Use a piece of wood or cardboard. Hydraulic fluid escaping under pressure can penetrate the skin causing serious injury. Warning! Openings in the skin and minor cuts are susceptible to infection from hydraulic fluid.

  • Page 16: Transport & Storage

    TRANSPORT & STORAGE TRANSPORT • Make sure the light harness is properly Warning! Comply with your state and local laws connected and all the lights are visible and working. governing highway safety, lighting & marking, and the movement of farm •...

  • Page 17: Transport & Storage

    TRANSPORT & STORAGE SMV EMBLEM Always have the SMV emblem clean and in full view of a vehicle approaching from the rear. The SMV (Slow Moving Vehicle) emblem must be on the implement if it is to be transported on public roadways.
  • Page 18 Notes...

  • Page 19: Assembly Instructions

    ASSEMBLY INSTRUCTIONS The terms “right” and “left”, “front” and “rear”, refer to Warning! Keep clear of parts which may move or the machine by facing in the direction of forward drop when removing shipping straps travel. or brackets. Use hoists or blocks to move or support heavy pieces of the machine.
  • Page 20 ASSEMBLY INSTRUCTIONS 5. Install reflector mounts as shown. Bend vertical. 6. Attach transport chain to the lug on the R. H. Install amber reflector on the front of the left side of the hitch using 3/4" bolt, flatwasher and hand reflector mount. Install red reflectors on locknut.

  • Page 21: Light Kit Assembly 12', 14' And 16' Machines

    ASSEMBLY LIGHT KIT ASSEMBLY 12’, 14’ and 16’ Machines Tail Lights Position the tail light brackets and lights (red) on the main bar symmetrically between 2 feet to 5 feet of the centerline of the machine. Be sure the lights can be seen from the rear. Flasher Lights Position the flasher lights (amber) on the main frame within 16"...
  • Page 22 ASSEMBLY...
  • Page 23 ASSEMBLY 4’, 6’, 8’ SMOOTH ROLLER GANG ASSEMBLIES - FIGURE 2 Item Part No. Description Qty. Qty. Qty. 4’ 6’ 8’ ----- Hanger Assembly 40-0013 Special Pin 40-0028 Lock Spacer 40-0014 Axle, 4’ 40-0015 Axle, 6’ 40-0016 Axle, 8’ 41-0017 17”...
  • Page 24 ASSEMBLY 10’, 12’ SMOOTH ROLLER GANG ASSEMBLIES - FIGURE 3 Item Part No. Description Qty. Qty. 10’ 12’ ----- Hanger Assembly 40-0013 Special Pin 40-0028 Lock Spacer 40-0017 Axle, 10’ 40-0018 Axle, 12’ 41-0017 17” Roller or 41-0019 19” Roller 40-0024 Gang Tube, 10’...
  • Page 25 ASSEMBLY 14’, 16’ SMOOTH ROLLER GANG ASSEMBLIES - FIGURE 4 Item Part No. Description Qty. Qty. 14’ 16’ ----- Hanger Assembly 40-0013 Special Pin 40-0028 Lock Spacer 40-0019 Axle, 14’ 40-0020 Axle, 16’ 41-0017 17” Roller or 41-0019 19” Roller 40-0026 Gang Tube, 14’...
  • Page 26 ASSEMBLY 4’, 6’, 8’ CROWFOOT GANG ASSEMBLIES - FIGURE 5 Item Part No. Description Qty. Qty. Qty. 4’ 6’ 8’ ----- Hanger Assembly 40-0013 Special Pin 40-0028 Lock Spacer 40-0014 Axle, 4’ 40-0015 Axle, 6’ 40-0016 Axle, 8’ 21-0117 17” Crowfoot Roller or 21-0120 20”...
  • Page 27 ASSEMBLY 10’, 12’ CROWFOOT ROLLER GANG ASSEMBLIES - FIGURE 6 Item Part No. Description Qty. Qty. 10’ 12’ ----- Hanger Assembly 40-0013 Special Pin 40-0028 Lock Spacer 40-0017 Axle, 10’ 40-0018 Axle, 12’ 21-0117 17” Crowfoot Roller or 21-0120 20” Crowfoot Roller 40-0024 Gang Tube, 10’...
  • Page 28 ASSEMBLY 14’, 16’ CROWFOOT ROLLER GANG ASSEMBLIES - FIGURE 7 Item Part No. Description Qty. Qty. 14’ 16’ ----- Hanger Assembly 40-0013 Special Pin 40-0028 Lock Spacer 40-0019 Axle, 14’ 40-0020 Axle, 16’ 21-0117 17” Crowfoot Roller or 21-0120 20” Crowfoot Roller 40-0026 Gang Tube, 14’...

  • Page 29: Optional Equipment

    OPTIONAL EQUIPMENT TRANSPORT KIT Transport Kits are available for all CP40 models. The transport kit on the 4’-10", 6’-6" and 9’-3" machines can be equipped with a hydraulic cylinder or equipped with a ratchet jack for manual operation. The transport kit on the 10’-7", 12’-7", 14’-10" and 16’-11" machines is operated hydraulically. A tongue jack is also required.
  • Page 30 OPTIONAL EQUIPMENT 10’-7", 12’-7", 14’-10" and 16’-11" Machines Only Attach cylinder lug to the tongue using two u-bolts, lockwashers and nuts. Attach cylinder as shown. Install flow restrictors and 90 elbows in to both cylinder ports. Attach hoses to the elbows. Clamp hoses to the tongue.

  • Page 31: Scrapers

    OPTIONAL EQUIPMENT SCRAPERS Assemble the scraper mounting bracket at each bearing hanger as shown, using 5/8" x 1-3/4" bolt, lockwasher and nut at each hanger. U-bolts should be towards the center of the machine. Use the top holes for the 17" rollers. Use the bottom holes for the 19"...

  • Page 32: Predelivery Inspection & Service Report

    PREDELIVERY INSPECTION & SERVICE REPORT GLENCOE ® CP40 Cultipacker Serial No._____________________ Model____________ Date____________________ Serviced By_____________________________________________________________________ Sold To_____________________________________________________________________________ (Name, Address, Telephone) INSTRUCTIONS: All items listed below must be inspected and serviced as explained in the Operator’s Manual and this form. As each task is completed, place a ( ) in the adjoining box. Retain a copy of the completed form in dealership files for future customer, dealer, and/or company reference.
  • Page 36 Glencoe ® AGCO CORPORATION 4205 River Green Parkway Duluth, Georgia 30096 Printed in U.S.A.
