EL-42S
4-Way HDMI Switcher with 2 Identical Outputs
OPERATION MANUAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EL-42S and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for CYP EL-42S

  • Page 1 EL-42S 4-Way HDMI Switcher with 2 Identical Outputs OPERATION MANUAL...
  • Page 3 DISCLAIMERS The information in this manual has been carefully checked and is believed to be accurate. CYP (UK) Ltd assumes no responsibility for any infringements of patents or other rights of third parties which may result from its use. CYP (UK) Ltd assumes no responsibility for any inaccuracies that may be contained in this document.
  • Page 4 SAFETY PRECAUTIONS Please read all instructions before attempting to unpack, install or operate this equipment and before connecting the power supply. Please keep the following in mind as you unpack and install this equipment: • Always follow basic safety precautions to reduce the risk of fire, electrical shock and injury to persons.
  • Page 5: Table Of Contents

    CONTENTS 1. Introduction ...........6 2. Applications ...........6 3. Package Contents ........6 4. System Requirements ......6 5. Features ..........7 6. Operation Controls and Functions ..8 6.1 Front Panel ........... 8 6.2 Rear Panel ............. 8 6.3 Remote Control .......... 9 6.4 RS-232 Remote Control Protocol ..9 6.5 RS-232 Commands ........
  • Page 6: Introduction

    1. INTRODUCTION The EL-42S switcher allows the user to input four HDMI sources and switch between these sources to display HD content on 2 displays. This switcher can be controlled via the supplied remote control, RS-232, or by using the input switching button on the front of the device.
  • Page 7: Features

    5. FEATURES  v1.3 HDMI, HDCP 1.1 and DVI 1.0 compliant  HDMI 4 Way Switcher with 2 Identical Outputs  Resolutions Supported: PC - VGA, SVGA, XGA, SXGA, UXGA & WUXGA (1920x1200). HDTV - 480i, 576i, 480p, 576p, 720p, 1080i, 1080p and 1080p24fps  High Definition Audio supported - Dolby TrueHD, Dolby Digital Plus and DTS-HD Master Audio plus LPCM...
  • Page 8: Operation Controls And Functions

    6. OPERATION CONTROLS AND FUNCTIONS 6.1 Front Panel INPUT POWER IR Window: This IR Receiver receives the remote control signal from the included remote control HDMI input Select/Indicator: Press the "Input" button sequentially to switch to your desired input (HDMI 1 to HDMI 4), the LED will illuminate to indicate which input source is selected POWER Switch/Indicator: Press the "POWER"...
  • Page 9: Remote Control

    6.3 Remote Control Power: Press the button to turn on/off the unit. Direct input selector: Press 1, 2, 3 or 4 to select the desired input source. 6.4 RS-232 Remote Control Protocol Splitter Remote Controller Definition Definition Baud Rate: 9600 bps Data bit: 8 Bits Parity: None Stop Bit: 1 bit...
  • Page 10: Connection Diagram

    7. CONNECTION DIAGRAM Set-top Box Games Console Satellite Receiver Blu-ray Player HDMI Inputs RS-232 RS-232 DC 5V HDMI OUT HDMI OUT HDMI IN HDMI IN HDMI IN HDMI IN RS-232 Control System HDMI Outputs HDTV Projector...
  • Page 11: Technical Specifications

    8.TECHNICAL SPECIFICATIONS Frequency Bandwidth 2.25Gbps (single link) Input Port 4x HDMI female ports Output Port 2 x HDMI female ports Power Supply 5VDC/2.6A (US/EU standards, CE/FCC/UL certified) Remote Control Discrete IR remote Dimensions (mm) 240(W) x 104(D) x 44(H) Weight(g) Chassis Material Metal Silkscreen Colour...
  • Page 12 CYP (UK) Ltd., Unit 7, Shepperton Business Park, Govett Avenue, Shepperton, Middlesex, TW17 8BA Tel: +44 (0) 20 3137 9180 | Fax: +44 (0) 20 3137 6279 Email: sales@cypeurope.com www.cypeurope.com v2.00...
