EL-42HEAC
4 Way HDMI Switcher with
2 Identical Outputs
(Including HEAC function)
OPERATION MANUAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EL-42HEAC and is the answer not in the manual?

Questions and answers

Related Manuals for CYP EL-42HEAC

Summary of Contents for CYP EL-42HEAC

  • Page 1 All manuals and user guides at all-guides.com EL-42HEAC 4 Way HDMI Switcher with 2 Identical Outputs (Including HEAC function) OPERATION MANUAL...
  • Page 2 All manuals and user guides at all-guides.com SAFETY PRECAUTIONS Please read all instructions before attempting to unpack, install or operate this equipment and before connecting the power supply. Please keep the following in mind as you unpack and install this equipment: ‡...

  • Page 3: Table Of Contents

    All manuals and user guides at all-guides.com CONTENTS 1. Introduction ..........1 2. Applications ........... 1 3. Package Contents ........ 1 4. System Requirements ......1 5. Features ..........2 6. Operation Controls and Functions ..3 6.1 Front Panel ........3 6.2 Rear Panel .........4 6.3 Remote Control ........5 6.4 RS232 Protocol and Command ..6...

  • Page 4: Introduction

    All manuals and user guides at all-guides.com 1. INTRODUCTION This is a high performance HDMI™ Switcher with four HDMI inputs & two outputs HDMI™ Switcher, the output ports support Audio Return Channel (ARC) from a compaitble ARC TV and HDMI Ethernet &KDQQHO +(& IROORZLQJ WKH +'0, Y VSHFLÀFDWLRQ The HDMI Switcher provides an S/PDIF link from the HDMI signal and RXWSXW WKURXJK WKH $5&...

  • Page 5: Features

    All manuals and user guides at all-guides.com 5. FEATURES ‡ 6XSSRUWV PXOWLSOH[HG +'0, LQSXW DQG RXWSXW ‡ Two output ports supporting Ethernet Channel (HEC) and Audio 5HWXUQ &KDQQHO $5& IROORZLQJ WKH +'0, Y VSHFLÀFDWLRQ ‡ HDMI v1.4 supports:  Audio Return Channel (ARC)  3D  +'0, (WKHUQHW &KDQQHO +(&  HQDEOLQJ KLJKVSHHG ELGLUHFWLRQDO networking at up to 100 Mb/sec...

  • Page 6: Operation Controls And Functions

    All manuals and user guides at all-guides.com 6. OPERATION CONTROLS AND FUNCTIONS 6.1 Front Panel BITSTREAM LPCM 5.1/7.1 LOCK EDID POWER INPUT IR Remote Control Sensor Audio/3D Content Indicator The system will automatically detect incoming audio/video signal type and the green LEDs will illuminate accordingly. Input Selection Press input button to select input source, the Blue LED will illuminate accordingly.

  • Page 7: Rear Panel

    All manuals and user guides at all-guides.com 6.2 Rear Panel RS-232 DC 5V HDMI OUT HDMI IN RS-232 7KLV VORW LV WR FRQQHFW ZLWK D 3& RU FRQWURO V\VWHP ZLWK 'VXE SLQ FDEOH IRU 56 FRQWURO )RU GHWDLO 56 FRPPDQGV SOHDVH UHIHU to Section 6.4.

  • Page 8: Remote Control

    All manuals and user guides at all-guides.com Note 2: When the HDMI output has both Audio and ARC at the same time the ARC will be the prioritized. HDMI INPUT 1~4 Connect to HDMI or DVI sources equipment such as DVD player or VHWWRSER[ IRU LQSXW YLGHR DQG DXGLR VHQGLQJ Note A: This system was tested with 24 AWG cables.

  • Page 9: Rs232 Protocol And Command

    All manuals and user guides at all-guides.com 6.4 RS232 Protocol and Command CPRO-3D42S Remote Control Console 'HÀQLWLRQ 'HÀQLWLRQ Baud Rate: 9600 bps 'DWD ELW ELWV Parity: None 6WRS ELW ELW Flow Control: None Command Action POWER 00 Power Off (standby) POWER 01 Power On PORT 11...

  • Page 10: Connection Diagram

    Note: In this example, Blu-ray Player DVD Player HDMI In 1 is selected. Audio Loop Out Audio Loop Out Speakers AV Amplifier RS-232 HDMI OUT EL-42HEAC RS-232 DC 5V HDMI OUT HDMI IN Speakers TV/Monitor with ARC Internet Hub/ & HEC...

  • Page 11: 6Shflàfdwlrqv

    All manuals and user guides at all-guides.com 8. SPECIFICATIONS Video Bandwidth 0+] *ESV Input Ports 4 × HDMI (Female type) Output Ports 2 × HDMI (Female type) 2 × Ethernet 2 × ARC Output Resolution 480i ~1080p50/60, 1080p24, VGA~UXGA HDMI Cable In SELWV RU ELWV P HDMI Cable Out SELWV RU ELWV P ...

  • Page 12: Acronyms

    All manuals and user guides at all-guides.com 9. ACRONYMS ACRONYM COMPLETE TERM Audio Return Channel Consumer Electronics Control EDID ([WHQGHG 'LVSOD\ ,GHQWLÀFDWLRQ 'DWD HEAC HDMI Ethernet & Audio Return Channel HDMI Ethernet Channel HDCP +LJKEDQGZLGWK 'LJLWDO FRQWHQW SURWHFWLRQ HDMI +LJK'HÀQLWLRQ 0XOWLPHGLD ,QWHUIDFH...
  • Page 13 All manuals and user guides at all-guides.com...
