Drop with change
of direction
T i p :
The next flex-rail must be correctly
aligned with the previous flex-rail so
that the ball is caught after it falls
and can continue to roll.

Rotary funnel

T i p :
Make sure that all components
for the rotary funnel mount as
well as the subsequent cross-over
sub-frame and flex-rail are aligned
correctly so that the ball can drop
through the hole directly onto the
next members.
T i p :
Make sure that the cross-over
sub-frame is correctly aligned to
the funnel installed above. If a ball
becomes stuck in the funnel tube
and does not continue rolling, the
cross-over sub-frame may have
shifted. In this case, move the
cross-over sub-frame outward in
the direction of the arrow.
The ball rolls through the obstacle course - but then the flex-
rail stops suddenly and the ball falls downward. The next rail
catches the ball and immediately lets it continue to roll down
in the opposite direction.
The rotary funnel is installed in two places in obstacle course 3.
In the rotary funnel the balls from the routes again merge on
the subsequent cross-over sub-frame and the flex-rail.
